Tivo SerialapterĘble
Tivo Serial Adapter Cable:
(TD) (RD) (GND)
2 connector 1/8” stereo mini pług
(GND) (DTR) (TD) (RO) (DCD)
5 4 3 2 1
T77771
9 8 7 6
(Rl) (CTS) (RTS) (DSR)
PC DB9 Serial/F
Tivo Serial Cable
Parts needed:
1 - DB9 Female 1 - 1/8" Stereo Mini PĹ‚ug
1-1 3-conductor cable wire (or stereo pług with attached wire)
