PLIK CPP


//-------------------------------------------------------------------



#include <vcl.h>
#pragma hdrstop
#include "Unit1.h"

//------------------------------------------------------------------



#pragma package(smart_init)
#pragma resource "*.dfm"
TForm1 *Form1;

//=====blok definiowania danych=====



int luk=85, wskazowka=85, lewo=90, gora=51;
float PI=3.14;
int x,y;
int wektorDanych[30]; //tworzenie wektora danych
int c;

//-------------------------------------------------------------------



__fastcall TForm1::TForm1(TComponent* Owner)


: TForm(Owner)

{
skala();

//===wczytywanie danych===





fstream dane("parametry.txt",std::ios::in);



for (int t=0; t < 30; t++) {



   dane>>wektorDanych[t];



}



dane.close();

}

//-------------------------------------------------------------------




void TForm1::skala()
{


Image1->Canvas->Font->Color=RGB(0,0,0);

//=== tło

===





Image1->Canvas->TextOut(100,190,"0");



Image1->Canvas->TextOut(65,110,"150");



Image1->Canvas->TextOut(105,50,"260");



Image1->Canvas->TextOut(165,30,"350");



Image1->Canvas->TextOut(225,50,"450");



Image1->Canvas->TextOut(265,110,"575");



Image1->Canvas->TextOut(245,190,"700");



Image1->Canvas->Font->Color=clRed;



Image1->Canvas->TextOut(170,140,"W");

Image1->Canvas->Pen->Color=clBlack;

//=== wskazowka ===



Image1->Canvas->Pen->Width=3;
Image1->Canvas->MoveTo(lewo + luk, gora + luk);


Image1->Canvas->Pen->Color=RGB(0,180,0);



x=floor(cos(PI*(0*270/700+135)/180)



* (wskazowka - (wskazowka/100*10))+lewo+luk);



y=floor(sin(PI*(0*270/700+135)/180)



* (wskazowka - (wskazowka/100*10))+gora+luk);



Image1->Canvas->LineTo(x,y);

}

//cz2 na nast stronie







PLIK H


//---------------------------------------------------------------------------


#ifndef Unit1H
#define Unit1H

//---------------------------------------------------------------------------

#include <Classes.hpp>
#include <Controls.hpp>
#include <StdCtrls.hpp>
#include <Forms.hpp>

#include <iostream.h>
#include <ExtCtrls.hpp>

//floor

#include <cmath>

//matematyka



#include <fstream.h>

//---------------------------------------------------------------------------

class TForm1 : public TForm
{
__published:  // IDE-managed Components


TImage *Image1;



TTimer *Timer1;



TLabel *Label1;



TEdit *Edit1;



TButton *Button1;



void __fastcall Timer1Timer(TObject *Sender);



void __fastcall Button1Click(TObject *Sender);

private:

// User declarations



public:

// User declarations





__fastcall TForm1(TComponent* Owner);



void skala();

};

//---------------------------------------------------------------------------

extern PACKAGE TForm1 *Form1;

//---------------------------------------------------------------------------

#endif






void __fastcall TForm1::Timer1Timer(TObject *Sender)
{
Image1->Picture=NULL;
skala();

//======wczytywanie danych========



Edit1->Text=wektorDanych[c];
if(c>=30)
{


Timer1->Enabled=0;



c=0;



Edit1->Text="";

}


//=======ruch wskazowki======================



Image1->Canvas->Pen->Width=3;
Image1->Canvas->MoveTo(lewo+luk, gora+luk);
Image1->Canvas->Pen->Color=RGB(0,180,0);
x=floor(cos(PI*((wektorDanych[c]*270/700)+135)/180)
*(wskazowka-(wskazowka/100*10))+gora+luk);
y=floor(sin(PI*((wektorDanych[c]*270/700)+135)/180)
*(wskazowka-(wskazowka/100*10))+gora+luk);
Image1->Canvas->LineTo(x,y);
c++; //inkrementacja parametru Timera
}

//---------------------------------------------------------------------------



void __fastcall TForm1::Button1Click(TObject *Sender)
{
Timer1->Enabled=true;
}

//---------------------------------------------------------------------------
