DIMENSIONS

REF.

mm

inch

TYP.

MIN. MAX. TYP.

MIN.

MAX.

A

11.00 13.10

0.433 0.516

B

0.97

1.15

0.038 0.045

C

1.50

1.65

0.059 0.065

D

8.32

8.92

0.328 0.351

E

19.00 20.00

0.748 0.787

G

10.70 11.10

0.421 0.437

N

16.50 17.20

0.650 0.677

P

25.00 26.00

0.984 1.024

R

4.00

4.09

0.157 0.161

U

38.50 39.30

1.516 1.547

V

30.00 30.30

1.181 1.193

TO-3

P G

N

V

U

C

B

A

D

E

R

September 2002 (Rev. 2)

1/2

PACKAGE AND

PACKING INFORMATION

1

2

TO-3 PACKAGE & PACKING INFORMATION

2/2

TUBE MECHANICAL DATA

mm.

inch

A

25.00

0.984

B

17.00

0.669

C

10.00

0.394

D

0.60

0.024

E

2.50

0.098

F

17.40

0.685

G

7.00

0.276

H

0.60

0.024

I

3.50

0.138

J

0.60

0.024

K

8.00

0.315

L

4.50

0.177

M

3.00

0.118

N

23.00

0.906

O

43.00 (±0.20)

1.693 (±0.008)

P

3.00

0.118

R

0.50

0.020

R1

15°

15°

R2

10°

10°

BASE QUANTITY

20 pcs.

A

B

C

D

E

F

G

H

I

J

R1

K

R1

R

L

M

R2

N

O

P

R2

R1

R

TUBE SHIPMENT INFORMATION
