	Lp.	f	U1	U2	U1 / U2	ZO = ZC
		Hz	V	V	V	Ω
	1	20	5	2,964	1,687	158
	2	30		2,907	1,720								Dolnoprzepustowy LC PI
	3	40		2,828	1,768
	4	46		2,748	1,820
	5	50		2,678	1,867
	6	56		2,566	1,949
	7	60		2,485	2,012
	8	65		2,349	2,129
	9	70		2,261	2,211
	10	80		1,990	2,513
	11	90		1,736	2,880
	12	100		1,509	3,313
	13	120		1,140	4,386
	14	140		0,873	5,727
	15	160		0,687	7,278
	16	180		0,546	9,158
	17	200		0,443	11,287

---

Sheet 2: Arkusz1 (3)

	Lp.	f	U1	U2	U1 / U2	ZO = ZC
		Hz	V	V	V	Ω					Górnoprzepustowy LC T
	1	20	5	0,495	10,101	316
	2	25		0,802	6,234
	3	27		0,940	5,319
	4	30		1,196	4,181
	5	36		1,775	2,817
	6	40		2,195	2,278
	7	42		2,435	2,053
	8	44		2,648	1,888
	9	46		2,865	1,745
	10	48		3,090	1,618
	11	50		3,317	1,507
	12	54		3,665	1,364
	13	60		4,061	1,231
	14	70		4,524	1,105
	15	100		5,047	0,991
	16	200		5,214	0,959

---

Sheet 3: Arkusz1 (5)

	Lp.	f	U1	U2	U1 / U2	ZO
		Hz	V	V	V	Ω					Górnoprzepustowy RC T
	1	20	5	0,077	64,935	150
	2	40		0,260	19,231
	3	50		0,385	12,987
	4	60		0,505	9,901
	5	70		0,630	7,937
	6	80		0,766	6,527
	7	100		1,024	4,883
	8	130		1,404	3,561
	9	150		1,651	3,028
	10	170		1,899	2,633
	11	200		2,205	2,268
	12	250		2,662	1,878
	13	300		3,046	1,641
	14	360		3,439	1,454
	15	420		3,740	1,337
	16	500		4,086	1,224
	17	600		4,372	1,144
	18	800		4,730	1,057
	19	1000		4,928	1,015
	20	1500		5,146	0,972

---

Sheet 4: Arkusz1 (6)

	Lp.	f	U1	U2	U1 / U2	ZO
		Hz	V	V	V	Ω					Dolnoprzepustowy RC T
	1	20	5	3,254	1,537	150
	2	40		3,264	1,532
	3	80		3,212	1,557
	4	120		3,138	1,593
	5	160		3,027	1,652
	6	200		2,905	1,721
	7	220		2,842	1,759
	8	250		2,739	1,825
	9	300		2,570	1,946
	10	340		2,444	2,046
	11	380		2,318	2,157
	12	420		2,205	2,268
	13	460		2,082	2,402
	14	500		1,969	2,539
	15	540		1,866	2,680
	16	600		1,747	2,862
	17	650		1,644	3,041
	18	700		1,566	3,193
	19	800		1,395	3,584
	20	900		1,264	3,956
	21	1000		1,160	4,310
	22	1400		0,844	5,924
	23	1700		0,697	7,174
	24	2000		0,593	8,432

---

Sheet 5: Arkusz1

	Lp.	f	I	URL	UC	XL	XC	Z	UZ	R	L	C		w 0	372,988949993049
		Hz	mA	V	V	Ω	Ω	Ω	V	Ω	H	μF		f 0	59,3630351100495
	1	25	17,0	5,00	9,30	94,1	530,5	464,8	9,4	160	0,599	12		Q	1,39637738153648
	2	30	20,0	6,03	9,18	112,9	442,1	366,0						b	42,5121717774679
	3	35	23,0	7,07	8,98	131,7	378,9	294,5
	4	40	25,0	8,05	8,68	150,5	331,6	241,6
	5	45	27,5	8,93	8,28	169,4	294,7	203,3
	6	50	28,8	9,73	7,74	188,2	265,3	177,6
	7	60	29,0	10,56	6,56	225,8	221,0	160,1
	8	65	28,8	10,87	5,93	244,6	204,0	165,1
	9	70	28,5	11,00	5,53	263,5	189,5	176,3
	10	80	27,0	11,15	4,48	301,1	165,8	209,5
	11	90	25,0	11,11	3,70	338,7	147,4	249,4
	12	100	23,0	11,00	3,08	376,4	132,6	291,6
	13	120	19,5	10,72	2,16	451,6	110,5	376,8
	14	150	16,0	10,36	1,35	564,5	88,4	502,3
