EN SC DS400 C VW POLO A 05 XX

background image

87A

87

30

85

86

additional starter killer

antenna

12

11

13

14

15

17

18

19

20

4

5

6

7

8

9

10

16

1

2

3

PAGER

PAGER

Rev. 00

Ds400

Parameter: 1 Level: 4

firmware >= 1.9

Pic No.

110h

Manufacture: VW

bonnet switch

left direction indicator

right direction indicator

5A

15A

anti-hijack button

Green - siren

Red +12V

Black - ground

yellow-green

power supply of the siren

STARTER KILLER

LED

Digital

Tilt Sensor

additional sensors

NC

black

red

pink

grey

green

yellow

yellow

blue

violet

grey-blue

Model: POLO

Year: 05 >

violet

black-white

black-green

orange-green

orange-brown

yellow

white

orange

pager output

ultrasonictransmitter

ultrasonicreceiver

yellow-white

brown

yellow-brown

NC NC

NC

NC

NC

CANH

CANL

Ignintion key

the main control unit

located underneath the dashboard

to the left of the steering column

BLACK CONNECTOR

XS6

BLACK CONNECTOR

XS6

BLACK CONNECTOR

XS2

BLACK CONNECTOR

XS2

16

16

14

14

12

12

9

background image

Rev. 00

Ds400

The main control unit located underneatch the dashboard to the left of the steering column

Black connector XS2

Black connector XS6

CAN_H orange - green pin 12

right direction indicator black - white pin 16

right direction indicator black - green pin 14

CAN_L orange - brown pin 9

Parameter: 1 Level: 4

firmware >= 1.9

Pic No.

110h

Manufacture: VW

Model: POLO

Year: 05 >
