Lens Compatibility Chart

The following charts give an overview of the compatibility between Sony / Konica Minolta

Lens and Sony / Konica Minolta cameras.

Please select your brand:

Sony

Please select your model:

D-SLR A300

Please select your lens:

Sony Lens

Lens Type

Product

Code

Compatibility

Non-zoom lens

16mm F2.8 Fisheye

SAL16F28

OK

20mm F2.8

SAL20F28

OK

28mm F2.8

SAL28F28

OK

35mm F1.4 G

SAL35F14G

OK (ADI)

50mm F1.4

SAL50F14

OK (ADI)

Planar T* 85mm F1.4 ZA

SAL85F14Z

OK (ADI)

Sonnar T* 135mm F1.8 ZA

SAL135F18Z OK (ADI)

135mm F2.8 [T4.5] STF (*9)

SAL135F28

OK

300mm F2.8 G

SAL300F28G OK (ADI)

500mm F8 Reflex

SAL500F80

OK (*7)

Macro lens

50mm F2.8 Macro

SAL50M28

OK (ADI)

100mm F2.8 Macro

SAL100M28

OK (ADI)

Zoom lens

Vario-Sonnar T* 16-35mm F2.8
ZA SSM

SAL1635Z

OK (ADI)

Vario-Sonnar T* 24-70mm F2.8
ZA SSM

SAL2470Z

OK (ADI)

24-105mm F3.5-4.5

SAL24105

OK (ADI)

70-200mm F2.8 G

SAL70200G

OK (ADI)

70-300mm F4.5-5.6 G SSM

SAL70300G

OK (ADI)

70-400mm F4-5.6 G SSM

SAL70400G

OK (ADI)

75-300mm F4.5-5.6

SAL75300

OK (ADI)

DT lens

DT 11-18mm F4.5-5.6

SAL1118

OK (ADI)

Vario-Sonnar T* DT 16-80mm
F3.5-4.5 ZA

SAL1680Z

OK (ADI)

DT 16-105mm F3.5-5.6

SAL16105

OK (ADI)

DT 18-70mm F3.5-5.6

SAL1870

OK (ADI)

DT 18-200mm F3.5-6.3

SAL18200

OK (ADI)

DT 18-250mm F3.5-6.3

SAL18205

OK (ADI)

DT 55-200mm F4-5.6

SAL55200

OK (ADI)

Tele Converter

1.4X Teleconverter

SAL14TC

OK

2X Teleconverter

SAL20TC

OK

background image

OK:

Available

(ADI):

ADI Flash metering is available in combination with HVL-F56AM, F36AM, KONICA
MINOLTA 5600HS(D), 3600HS(D) and 2500(D).

(*1):

When focus range is limited for finite distances, which mean focus does not to reach
infinity, Anti-Shake effect lowers.
Using with setting the focus limiter to FULL is recommended.
* Focus limiter : Function to set the drive range of a focus ring.

(*2):

In macro range by using the macro switch, Anti-Shake effect lowers.

(*3):

Please turn off the Anti-Shake function.

(*4):

Autofocus cannot be used.

(*5):

The Auto Focus function can be used for Dynax/Maxxum 9/9Ti updated to use SSM
lenses.

(*6) :

Automatic zoom functions (APZ, ASZ; wide view mode, image size lock): not supported.

(*7) :

Local-focus frame except center position (Spot AF frame) cannot be choosed.

(*9) :

The lens is dedicated for manual focus.

(*10):

Using a DT lens is not guaranteed because the camera does not meet the primary AE
performance standard.

background image

Konica Minolta Lens

Lens Type

Product

Code

Compatibilit
y

Non-zoom lens

AF 16/2.8 FISH-EYE

2578

OK

AF 20/2.8

2579

OK

AF 20/2.8 NEW

2641

OK

AF 24/2.8

2566

OK

AF 24/2.8 NEW

2642

OK

AF 28/2

2596

OK

AF 28/2 NEW

2668

OK

AF 28/2.8

2557

OK

AF 35/1.4 G

2591

OK

AF 35/1.4 G NEW

2666

OK

AF 35/2

2597

OK

AF 35/2 NEW

2667

OK

AF 50/1.4

2562

OK

AF 50/1.4 NEW

2662

OK

AF 50/1.7

2550

OK

AF 50/1.7 NEW

2613

OK

AF 85/1.4

2592

OK

AF 85/1.4 G

2629

OK

AF 85/1.4 G (D)

2677

OK (ADI)

AF 85/1.4 G (D) Limited

2689

OK (ADI)

AF 100/2

2598

OK

AF 100/2.8 SOFT

2648

OK

AF 135/2.8

2556

OK

STF135/2.8 [T4.5] (*9)

2656

OK

AF APO 200/2.8

2593

OK (*1)

High Speed AF APO 200/2.8 G

2612

OK (*1)

AF APO 300/2.8

2563

OK (*1)

High Speed AF APO 300/2.8 G

2608

OK (*1)

AF APO 300/2.8 G(D) SSM

2674

OK (ADI)

AF APO 300/4 G

2640

OK (*1)

AF APO 400/4.5 G

2651

OK (*1)

AF REFLEX 500/8

2572

OK (*7)

AF APO 600/4

2565

OK (*1)

High Speed AF APO 600/4 G

2609

OK (*1)

Macro lens

AF MACRO 50/2.8

2564

OK

AF MACRO 50/2.8 NEW

2638

OK (*1)

AF MACRO 50/2.8 (D)

2675

OK (ADI)

background image

AF MACRO 50/3.5

2646

OK

AF MACRO 100/2.8

2581

OK (*1)

AF MACRO 100/2.8 NEW

2639

OK (*1)

AF MACRO 100/2.8 (D)

2676

OK (ADI)

AF APO TELE MACRO 200/4 G

2658

OK (*1)

AF MACRO ZOOM 3x-1x /F1.7-2.8 2594

OK (*3)

Zoom lens

AF 17-35/2.8-4 (D)

2695

OK (ADI)

AF 17-35/3.5 G

2654

OK

AF 20-35/3.5-4.5

2657

OK

AF 24-50/4

2558

OK

AF 24-50/4 NEW

2632

OK

AF 24-85/3.5-4.5

2636

OK

AF 24-85/3.5-4.5 NEW

2660

OK

AF 24-105/3.5-4.5 (D)

2672

OK (ADI)

AF 28-70/2.8 G

2620

OK

AF 28-75/2.8 (D)

2696

OK (ADI)

AF 28-80/3.5-5.6

2659

OK

AF 28-80/3.5-5.6 II

2670

OK

AF 28-80/3.5-5.6 (D)

2683

OK (ADI)

AF 28-80/4-5.6

2633

OK (*2)

AF 28-85/3.5-4.5

2552

OK (*2)

AF 28-85/3.5-4.5 NEW

2586

OK (*2)

AF 28-100/3.5-5.6 (D)

2692

OK (ADI)

AF 28-105/3.5-4.5

2635

OK

AF 28-105/3.5-4.5 NEW

2661

OK

AF 28-135/4-4.5

2553

OK (*2)

AF 35-70/3.5-4.5

2643

OK

AF 35-70/3.5-4.5 NEW

2652

OK

AF 35-70/4

2551

OK (*2)

AF 35-80/4-5.6

2605

OK

AF 35-80/4.5-5.6 II

2671

OK

AF 35-105/3.5-4.5

2554

OK (*2)

AF 35-105/3.5-4.5

2585

OK

AF APO 70-200/2.8 G (D) SSM

2682

OK (ADI)

AF 70-210/3.5-4.5

2588

OK

AF 70-210/4

2555

OK

AF 70-210/4.5-5.6 NEW

2634

OK

AF 70-210/4.5-5.6 II

2669

OK

AF 75-300/4.5-5.6

2561

OK (*1)

AF 75-300/4.5-5.6 NEW

2649

OK

AF 75-300/4.5-5.6 II

2665

OK

background image

AF 75-300/4.5-5.6 (D)

2684

OK (ADI)

AF APO 80-200/2.8

2589

OK

High Speed AF APO 80-200/2.8 G

2628

OK

AF 80-200/4.5-5.6

2604

OK

AF 100-200/4.5

2560

OK

AF 100-300/4.5-5.6

2606

OK

AF APO 100-300/4.5-5.6

2631

OK

AF APO 100-300/4.5-5.6 (D)

2681

OK (ADI)

AF APO 100-400/4.5-6.7

2644

OK

Xi lens

AF Xi 28-80/4-5.6

2618

OK (*6)

AF Xi 28-105/3.5-4.5

2615

OK (*6)

AF PZ 35-80/4-5.6

2624

OK (*6) (*7)

AF Xi 35-200/4.5-5.6

2616

OK (*6)

AF Xi 80-200/4.5-5.6

2619

OK (*6)

AF Xi 100-300/4.5-5.6

2621

OK (*6)

DT lens

AF DT 11-18/4.5-5.6 (D)

2698

OK (ADI)

AF DT 18-70/3.5-5.6 (D)

2697

OK (ADI)

AF DT 18-200/3.5-6.3 (D)

2699

OK (ADI)

Tele converter

1.4x TELE CONVERTER APO

2590

OK

2x TELE CONVERTER APO

2601

OK

1.4x TELE CONVERTER APO II

2610

OK

2x TELE CONVERTER APO II

2611

OK

1.4x TELE CONVERTER APO (D)

2687

OK

2x TELE CONVERTER APO (D)

2688

OK

Vectis Lens

V LENS 22-80MM F4-5.6

2301

N/A

V LENS 80-240MM/F4.5-5.6 APO

2302

N/A

V LENS 28-56MM F4-5.6

2303

N/A

V LENS 56-170MM/F4.5-5.6

2304

N/A

V LENS 50MM/F3.5 MACRO

2305

N/A

V REFLEX LENS 400MM/F8

2307

N/A

V LENS 25-150MM F4.5-6.3

2309

N/A

V LENS 17mm F3.5 RD (This lens is
for exclusive use with Konica
Minolta RD-3000).

2764

N/A

© 2004 - 2009 Sony- Terms and Conditions

|
