Samsung GT I9100 Galaxy S II 04 2 Cellular phone parts list

background image

Exploded View and Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

4-2

Design LOC

Description

SEC CODE

QCR12

SCREW-MACHINE

6001-001530

QCR03

SCREW-MACHINE

6001-001811

QCR96

SCREW-MACHINE

6001-002259

QVK02

KEY FPCB-POWER KEY(GT_9100)

GH59-10916A

QSP01

MODULE-SPK+INT(GT_I9100)

GH59-10917A

QVK01

KEY FPCB-VOLUME KEY(GT_9100)

GH59-10921A

QMP01

A/S ASSY-PBA MAIN(COMM)GT_I9100

GH82-05732A

QCA01

ASSY CAMERA-MODULE,8M (GT_I9100)

GH96-05139A

QBC00

ASSY COVER-BATT

GH98-19595A

QFR01

MEA FRONT-OCTA LCD ASSY(OPEN)

GH97-12175A

QCB01

CBF COAXIAL CABLE-75.5MM (GT_I9100)

GH39-01475A

QAR01

MODULE-RCV+MOT+MIC+E/JACK FPCB(GT_I9100)

GH59-10935A

QME02

ASSY ETC-SUB FPCB(GT_I9100)

GH59-10949A

QCA02

CAMERA MODULE-GT-I9100_2M CAM

GH59-10986A

QRE01

ASSY CASE-REAR

GH98-19594A

QVO01

ASSY KEY-VOL

GH98-19806A

QCK01

ASSY KEY-PWR

GH98-19807A

4-2. Cellular phone Parts list
