6. MAIN Electrical Parts List

Design LOG

SEC CODE

Discription

ZD400

0403-001547

DIODE-ZENER

D701

0404-001153

DIODE-SCHOTTKY

D301

0404-001250

DIODE-SCHOTTKY

D302

0404-001250

DIODE-SCHOTTKY

ZD703

0406-001237

DIODE-TVS

VR401

0406-001254

DIODE-TVS

ZD701

0406-001254

DIODE-TVS

ZD702

0406-001254

DIODE-TVS

ZD704

0406-001254

DIODE-TVS

ZD705

0406-001254

DIODE-TVS

ZD600

0406-001267

DIODE-TVS

VR702

0406-001279

DIODE-TVS

ZD602

0406-001330

DIODE-TVS

D401

0407-001002

DIODE-ARRAY

D700

0407-001002

DIODE-ARRAY

Q400

0504-001113

TR-DIGITAL

U200

0504-001151

TR-DIGITAL

U201

0504-001151

TR-DIGITAL

LED600

0601-002696

LED

U300

0801-003265

IC-CMOS LOGIC

U700

1001-001488

IC-ANALOG SWITCH

U601

1001-001586

IC-ANALOG SWITCH

UME300

1108-000237

IC-MCP

PAM100

1201-002740

IC-POWER AMP

F207

1201-002774

IC-RF AMP

PAM201

1201-002775

IC-POWER AMP

PAM200

1201-002821

IC-POWER AMP

U400

1203-005299

IC-POWER SUPERVISOR

U604

1203-005409

IC-POWER SUPERVISOR

U603

1203-005503

IC-DC/DC CONVERTER

U602

1203-005522

IC-DC/DC CONVERTER

U100

1204-002746

IC-TUNER

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

6-2

This Document can not be used without Samsung's authorization

Design LOG

SEC CODE

Discription

U202

1205-003297

IC-TRANSCEIVER

UCP300

1205-003498

IC-MODEM

U101

1205-003517

IC-BLUETOOTH

U600

1209-001831

IC-SENSOR

VR300

1404-001224

THERMISTOR-NTC

R200

2007-000138

R-CHIP

R703

2007-000138

R-CHIP

R708

2007-000138

R-CHIP

R109

2007-000139

R-CHIP

R111

2007-000139

R-CHIP

R219

2007-000140

R-CHIP

R323

2007-000141

R-CHIP

R324

2007-000141

R-CHIP

R510

2007-000141

R-CHIP

R601

2007-000141

R-CHIP

R602

2007-000141

R-CHIP

R619

2007-000141

R-CHIP

R620

2007-000141

R-CHIP

R103

2007-000143

R-CHIP

R104

2007-000143

R-CHIP

R409

2007-000144

R-CHIP

R117

2007-000148

R-CHIP

R305

2007-000148

R-CHIP

R306

2007-000148

R-CHIP

R307

2007-000148

R-CHIP

R309

2007-000148

R-CHIP

R314

2007-000148

R-CHIP

R411

2007-000148

R-CHIP

R425

2007-000148

R-CHIP

R427

2007-000148

R-CHIP

R428

2007-000148

R-CHIP

R429

2007-000148

R-CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

This Document can not be used without Samsung's authorization

6-3

Design LOG

SEC CODE

Discription

R430

2007-000148

R-CHIP

R431

2007-000148

R-CHIP

R432

2007-000148

R-CHIP

R107

2007-000157

R-CHIP

R100

2007-000162

R-CHIP

R101

2007-000162

R-CHIP

R433

2007-000162

R-CHIP

R617

2007-000164

R-CHIP

R634

2007-000164

R-CHIP

R414

2007-000165

R-CHIP

R415

2007-000165

R-CHIP

R704

2007-000165

R-CHIP

R413

2007-000168

R-CHIP

R320

2007-000170

R-CHIP

R623

2007-000170

R-CHIP

R635

2007-000170

R-CHIP

R206

2007-000172

R-CHIP

R420

2007-000174

R-CHIP

R421

2007-000174

R-CHIP

R508

2007-000174

R-CHIP

R418

2007-000242

R-CHIP

R419

2007-000242

R-CHIP

R505

2007-000242

R-CHIP

R507

2007-000242

R-CHIP

R313

2007-000932

R-CHIP

R504

2007-001119

R-CHIP

R210

2007-001285

R-CHIP

R212

2007-001285

R-CHIP

R110

2007-001290

R-CHIP

R632

2007-001290

R-CHIP

R633

2007-001290

R-CHIP

R115

2007-001291

R-CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

6-4

This Document can not be used without Samsung's authorization

Design LOG

SEC CODE

Discription

R311

2007-001291

R-CHIP

R201

2007-001298

R-CHIP

R322

2007-001298

R-CHIP

R439

2007-001298

R-CHIP

R114

2007-001307

R-CHIP

R116

2007-001307

R-CHIP

R416

2007-002965

R-CHIP

R417

2007-002965

R-CHIP

R202

2007-003004

R-CHIP

R203

2007-003004

R-CHIP

R105

2007-003015

R-CHIP

R205

2007-003015

R-CHIP

R621

2007-007008

R-CHIP

R315

2007-007014

R-CHIP

R316

2007-007014

R-CHIP

R317

2007-007014

R-CHIP

R318

2007-007014

R-CHIP

R319

2007-007014

R-CHIP

R603

2007-007136

R-CHIP

R604

2007-007136

R-CHIP

R300

2007-007142

R-CHIP

R204

2007-007309

R-CHIP

R121

2007-007317

R-CHIP

R405

2007-007334

R-CHIP

R426

2007-007334

R-CHIP

R404

2007-007538

R-CHIP

R402

2007-007573

R-CHIP

R624

2007-007875

R-CHIP

R401

2007-008167

R-CHIP

R438

2007-008780

R-CHIP

C210

2203-000138

C-CER,CHIP

C201

2203-000233

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

This Document can not be used without Samsung's authorization

6-5

Design LOG

SEC CODE

Discription

C240

2203-000233

C-CER,CHIP

C241

2203-000233

C-CER,CHIP

C246

2203-000233

C-CER,CHIP

C247

2203-000233

C-CER,CHIP

C249

2203-000233

C-CER,CHIP

C256

2203-000233

C-CER,CHIP

C257

2203-000233

C-CER,CHIP

C266

2203-000233

C-CER,CHIP

C269

2203-000233

C-CER,CHIP

C278

2203-000233

C-CER,CHIP

C290

2203-000233

C-CER,CHIP

C297

2203-000233

C-CER,CHIP

C456

2203-000233

C-CER,CHIP

C610

2203-000233

C-CER,CHIP

C136

2203-000254

C-CER,CHIP

C200

2203-000254

C-CER,CHIP

C205

2203-000254

C-CER,CHIP

C282

2203-000254

C-CER,CHIP

C293

2203-000254

C-CER,CHIP

C302

2203-000254

C-CER,CHIP

C325

2203-000254

C-CER,CHIP

C326

2203-000254

C-CER,CHIP

C343

2203-000254

C-CER,CHIP

C352

2203-000254

C-CER,CHIP

C515

2203-000278

C-CER,CHIP

C516

2203-000278

C-CER,CHIP

C518

2203-000278

C-CER,CHIP

C401

2203-000311

C-CER,CHIP

C298

2203-000330

C-CER,CHIP

C400

2203-000359

C-CER,CHIP

C140

2203-000386

C-CER,CHIP

C223

2203-000386

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

6-6

This Document can not be used without Samsung's authorization

Design LOG

SEC CODE

Discription

C419

2203-000386

C-CER,CHIP

C430

2203-000386

C-CER,CHIP

C441

2203-000386

C-CER,CHIP

C443

2203-000386

C-CER,CHIP

C202

2203-000438

C-CER,CHIP

C206

2203-000438

C-CER,CHIP

C222

2203-000438

C-CER,CHIP

C239

2203-000438

C-CER,CHIP

C259

2203-000438

C-CER,CHIP

C319

2203-000438

C-CER,CHIP

C361

2203-000438

C-CER,CHIP

C220

2203-000489

C-CER,CHIP

C221

2203-000489

C-CER,CHIP

C307

2203-000489

C-CER,CHIP

C243

2203-000585

C-CER,CHIP

C248

2203-000627

C-CER,CHIP

C252

2203-000627

C-CER,CHIP

C260

2203-000627

C-CER,CHIP

C261

2203-000627

C-CER,CHIP

C263

2203-000627

C-CER,CHIP

C264

2203-000627

C-CER,CHIP

C265

2203-000627

C-CER,CHIP

C272

2203-000627

C-CER,CHIP

C273

2203-000627

C-CER,CHIP

C276

2203-000627

C-CER,CHIP

C288

2203-000627

C-CER,CHIP

C289

2203-000627

C-CER,CHIP

C236

2203-000643

C-CER,CHIP

C237

2203-000643

C-CER,CHIP

C242

2203-000643

C-CER,CHIP

C613

2203-000679

C-CER,CHIP

C213

2203-000696

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

This Document can not be used without Samsung's authorization

6-7

Design LOG

SEC CODE

Discription

C129

2203-000725

C-CER,CHIP

C110

2203-000812

C-CER,CHIP

C211

2203-000812

C-CER,CHIP

C251

2203-000812

C-CER,CHIP

C299

2203-000812

C-CER,CHIP

C309

2203-000812

C-CER,CHIP

C444

2203-000812

C-CER,CHIP

C446

2203-000812

C-CER,CHIP

C448

2203-000812

C-CER,CHIP

C449

2203-000812

C-CER,CHIP

C450

2203-000812

C-CER,CHIP

C451

2203-000812

C-CER,CHIP

C452

2203-000812

C-CER,CHIP

C510

2203-000812

C-CER,CHIP

C511

2203-000812

C-CER,CHIP

C519

2203-000812

C-CER,CHIP

C522

2203-000812

C-CER,CHIP

C513

2203-000854

C-CER,CHIP

C524

2203-000854

C-CER,CHIP

C360

2203-000995

C-CER,CHIP

C445

2203-000995

C-CER,CHIP

C523

2203-000995

C-CER,CHIP

C725

2203-000995

C-CER,CHIP

C208

2203-001153

C-CER,CHIP

C215

2203-001153

C-CER,CHIP

C227

2203-001153

C-CER,CHIP

C228

2203-001153

C-CER,CHIP

C268

2203-001239

C-CER,CHIP

C271

2203-001239

C-CER,CHIP

C274

2203-001239

C-CER,CHIP

C520

2203-001259

C-CER,CHIP

C119

2203-001383

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

6-8

This Document can not be used without Samsung's authorization

Design LOG

SEC CODE

Discription

C602

2203-002487

C-CER,CHIP

C144

2203-002677

C-CER,CHIP

C258

2203-002709

C-CER,CHIP

C267

2203-002709

C-CER,CHIP

C438

2203-002709

C-CER,CHIP

C603

2203-002709

C-CER,CHIP

C207

2203-005050

C-CER,CHIP

C214

2203-005050

C-CER,CHIP

C216

2203-005234

C-CER,CHIP

C131

2203-005281

C-CER,CHIP

C126

2203-005288

C-CER,CHIP

C111

2203-005395

C-CER,CHIP

C112

2203-005395

C-CER,CHIP

C113

2203-005395

C-CER,CHIP

C118

2203-005395

C-CER,CHIP

C143

2203-005395

C-CER,CHIP

C139

2203-005450

C-CER,CHIP

C296

2203-005552

C-CER,CHIP

C114

2203-005682

C-CER,CHIP

C115

2203-005682

C-CER,CHIP

C116

2203-005682

C-CER,CHIP

C117

2203-005682

C-CER,CHIP

C294

2203-005682

C-CER,CHIP

C100

2203-005736

C-CER,CHIP

C291

2203-005736

C-CER,CHIP

C435

2203-006047

C-CER,CHIP

C436

2203-006047

C-CER,CHIP

C300

2203-006048

C-CER,CHIP

C308

2203-006048

C-CER,CHIP

C328

2203-006048

C-CER,CHIP

C329

2203-006048

C-CER,CHIP

C340

2203-006048

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

This Document can not be used without Samsung's authorization

6-9

Design LOG

SEC CODE

Discription

C341

2203-006048

C-CER,CHIP

C348

2203-006048

C-CER,CHIP

C351

2203-006048

C-CER,CHIP

C353

2203-006048

C-CER,CHIP

C355

2203-006048

C-CER,CHIP

C512

2203-006048

C-CER,CHIP

C514

2203-006048

C-CER,CHIP

C517

2203-006048

C-CER,CHIP

C521

2203-006048

C-CER,CHIP

C722

2203-006048

C-CER,CHIP

C330

2203-006090

C-CER,CHIP

C358

2203-006090

C-CER,CHIP

C122

2203-006137

C-CER,CHIP

C292

2203-006305

C-CER,CHIP

C612

2203-006324

C-CER,CHIP

C615

2203-006324

C-CER,CHIP

C409

2203-006377

C-CER,CHIP

C101

2203-006399

C-CER,CHIP

C102

2203-006399

C-CER,CHIP

C109

2203-006399

C-CER,CHIP

C453

2203-006399

C-CER,CHIP

C454

2203-006399

C-CER,CHIP

C405

2203-006474

C-CER,CHIP

C407

2203-006562

C-CER,CHIP

C421

2203-006562

C-CER,CHIP

C422

2203-006562

C-CER,CHIP

C423

2203-006562

C-CER,CHIP

C424

2203-006562

C-CER,CHIP

C425

2203-006562

C-CER,CHIP

C433

2203-006562

C-CER,CHIP

C434

2203-006562

C-CER,CHIP

C614

2203-006562

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

6-10

This Document can not be used without Samsung's authorization

Design LOG

SEC CODE

Discription

C295

2203-006665

C-CER,CHIP

C275

2203-006668

C-CER,CHIP

C106

2203-006681

C-CER,CHIP

C209

2203-006681

C-CER,CHIP

C233

2203-006681

C-CER,CHIP

C245

2203-006681

C-CER,CHIP

C250

2203-006681

C-CER,CHIP

C255

2203-006681

C-CER,CHIP

C262

2203-006681

C-CER,CHIP

C270

2203-006681

C-CER,CHIP

C277

2203-006681

C-CER,CHIP

C285

2203-006681

C-CER,CHIP

C286

2203-006681

C-CER,CHIP

C306

2203-006681

C-CER,CHIP

C312

2203-006681

C-CER,CHIP

C313

2203-006681

C-CER,CHIP

C314

2203-006681

C-CER,CHIP

C315

2203-006681

C-CER,CHIP

C316

2203-006681

C-CER,CHIP

C317

2203-006681

C-CER,CHIP

C413

2203-006681

C-CER,CHIP

C416

2203-006681

C-CER,CHIP

C623

2203-006681

C-CER,CHIP

C219

2203-006824

C-CER,CHIP

C238

2203-006824

C-CER,CHIP

C403

2203-006824

C-CER,CHIP

C408

2203-006824

C-CER,CHIP

C609

2203-006824

C-CER,CHIP

C611

2203-006824

C-CER,CHIP

C616

2203-006824

C-CER,CHIP

C525

2203-006838

C-CER,CHIP

C726

2203-006838

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

This Document can not be used without Samsung's authorization

6-11

Design LOG

SEC CODE

Discription

C336

2203-006841

C-CER,CHIP

C412

2203-006841

C-CER,CHIP

C415

2203-006841

C-CER,CHIP

C418

2203-006841

C-CER,CHIP

C431

2203-006841

C-CER,CHIP

C432

2203-006841

C-CER,CHIP

C439

2203-006841

C-CER,CHIP

C440

2203-006841

C-CER,CHIP

C600

2203-006841

C-CER,CHIP

C601

2203-006841

C-CER,CHIP

C606

2203-006841

C-CER,CHIP

C617

2203-006841

C-CER,CHIP

C618

2203-006841

C-CER,CHIP

C619

2203-006841

C-CER,CHIP

C128

2203-006872

C-CER,CHIP

C130

2203-006872

C-CER,CHIP

C305

2203-006872

C-CER,CHIP

C420

2203-006872

C-CER,CHIP

C426

2203-006872

C-CER,CHIP

C427

2203-006872

C-CER,CHIP

C428

2203-006872

C-CER,CHIP

C429

2203-006872

C-CER,CHIP

C620

2203-006872

C-CER,CHIP

C621

2203-006872

C-CER,CHIP

C718

2203-006872

C-CER,CHIP

C719

2203-006872

C-CER,CHIP

C301

2203-007271

C-CER,CHIP

C404

2203-007279

C-CER,CHIP

C410

2203-007279

C-CER,CHIP

C411

2203-007279

C-CER,CHIP

C414

2203-007279

C-CER,CHIP

C607

2203-007279

C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

6-12

This Document can not be used without Samsung's authorization

Design LOG

SEC CODE

Discription

C721

2203-007279

C-CER,CHIP

C622

2203-007317

C-CER,CHIP

TA200

2404-001339

C-TA,CHIP

TA501

2404-001377

C-TA,CHIP

TA601

2404-001474

C-TA,CHIP

TA100

2404-001506

C-TA,CHIP

TA400

2404-001506

C-TA,CHIP

L101

2703-001726

INDUCTOR-SMD

L103

2703-001726

INDUCTOR-SMD

L211

2703-001747

INDUCTOR-SMD

L114

2703-001749

INDUCTOR-SMD

L122

2703-001749

INDUCTOR-SMD

L232

2703-001750

INDUCTOR-SMD

L112

2703-001751

INDUCTOR-SMD

L235

2703-001786

INDUCTOR-SMD

L108

2703-001938

INDUCTOR-SMD

L105

2703-001990

INDUCTOR-SMD

L107

2703-001990

INDUCTOR-SMD

L229

2703-002176

INDUCTOR-SMD

L210

2703-002198

INDUCTOR-SMD

L124

2703-002199

INDUCTOR-SMD

L201

2703-002199

INDUCTOR-SMD

L203

2703-002200

INDUCTOR-SMD

L219

2703-002201

INDUCTOR-SMD

L117

2703-002204

INDUCTOR-SMD

L110

2703-002205

INDUCTOR-SMD

L115

2703-002207

INDUCTOR-SMD

L233

2703-002207

INDUCTOR-SMD

L231

2703-002268

INDUCTOR-SMD

L234

2703-002268

INDUCTOR-SMD

L223

2703-002308

INDUCTOR-SMD

L215

2703-002313

INDUCTOR-SMD

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

This Document can not be used without Samsung's authorization

6-13

Design LOG

SEC CODE

Discription

L100

2703-002314

INDUCTOR-SMD

L104

2703-002314

INDUCTOR-SMD

L123

2703-002365

INDUCTOR-SMD

L218

2703-002365

INDUCTOR-SMD

L204

2703-002367

INDUCTOR-SMD

L207

2703-002368

INDUCTOR-SMD

L227

2703-002798

INDUCTOR-SMD

L221

2703-002858

INDUCTOR-SMD

L400

2703-002866

INDUCTOR-SMD

L402

2703-002866

INDUCTOR-SMD

L401

2703-002872

INDUCTOR-SMD

L224

2703-002906

INDUCTOR-SMD

L225

2703-002918

INDUCTOR-SMD

L609

2703-002961

INDUCTOR-SMD

L608

2703-003260

INDUCTOR-SMD

L605

2703-003297

INDUCTOR-SMD

L607

2703-003297

INDUCTOR-SMD

L606

2703-003347

INDUCTOR-SMD

L603

2703-003502

INDUCTOR-SMD

U601

2801-004339

CRYSTAL-SMD

OSC100

2801-004589

CRYSTAL-SMD

OSC200

2809-001277

OSCILLATOR-VCTCXO

F700

2901-001409

FILTER-EMI SMD

F701

2901-001409

FILTER-EMI SMD

F702

2901-001409

FILTER-EMI SMD

F703

2901-001409

FILTER-EMI SMD

F704

2901-001469

FILTER-EMI/ESD

F705

2901-001469

FILTER-EMI/ESD

F205

2904-001769

FILTER-SAW

F202

2904-001785

FILTER-SAW

F204

2904-001789

FILTER-SAW

F203

2910-000034

DUPLEXER-SAW

SAMSUNG Proprietary-Contents may change without notice

MAIN Electrical Parts List

6-14

This Document can not be used without Samsung's authorization

Design LOG

SEC CODE

Discription

F201

2910-000058

DUPLEXER-SAW

F100

2911-000128

DUPLEXER-FEM

L404

3301-001534

BEAD-SMD

L217

3301-001756

BEAD-SMD

L403

3301-001876

BEAD-SMD

L125

3301-001912

BEAD-SMD

TAC700

3404-001152

SWITCH-TACT

TAC701

3404-001152

SWITCH-TACT

RFS100

3705-001503

CONNECTOR-COAXIAL

CD400

3709-001392

CONNECTOR-CARD EDGE

SIM400

3709-001487

CONNECTOR-CARD EDGE

HEA701

3711-005728

HEADER-BOARD TO BOARD

HDC704

3711-006615

HEADER-BOARD TO BOARD

HDC700

3711-006852

HEADER-BOARD TO BOARD

HDC702

3711-006865

HEADER-BOARD TO BOARD

HEA702

3711-006919

HEADER-BOARD TO BOARD

BTC400

3711-007004

HEADER-BATTERY

IFC600

3722-002867

JACK-MINI USB

BAT400

4302-001180

BATTERY-LI(2ND)

F200

4709-001407

COUPLER-DIRECTION

F101

4709-001615

BALUN

ANT100

GH70-03928A

ICT-ANTENNA COTACT

GPS_ANT

GH70-03928A

ICT-ANTENNA COTACT
