5. MAIN Electrical Parts List

5-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

SEC Code

Design LOC

Description

0404-001250

D7001

DIODE-SCHOTTKY

0404-001250

D8000

DIODE-SCHOTTKY

0404-001782

D7000

DIODE-SCHOTTKY

0404-001782

D7002

DIODE-SCHOTTKY

0406-001506

ZD2000

DIODE-TVS

0406-001506

ZD2001

DIODE-TVS

0406-001506

ZD2002

DIODE-TVS

0406-001506

ZD2003

DIODE-TVS

0406-001506

ZD4005

DIODE-TVS

0406-001506

ZD4006

DIODE-TVS

0406-001506

ZD4007

DIODE-TVS

0406-001506

ZD4008

DIODE-TVS

0406-001506

ZD4009

DIODE-TVS

0406-001506

ZD4010

DIODE-TVS

0406-001506

ZD7002

DIODE-TVS

0406-001506

ZD7003

DIODE-TVS

0406-001561

ZD4000

DIODE-TVS

0406-001561

ZD4001

DIODE-TVS

0406-001561

ZD4002

DIODE-TVS

0406-001592

ZD4011

DIODE-TVS

0406-001592

ZD4012

DIODE-TVS

0406-001592

ZD8007

DIODE-TVS

0406-001592

ZD9000

DIODE-TVS

0406-001592

ZD9001

DIODE-TVS

0406-001592

ZD9002

DIODE-TVS

0406-001592

ZD9003

DIODE-TVS

0406-001592

ZD9004

DIODE-TVS

0406-001596

ZD8015

DIODE-TVS

0406-001596

ZD8016

DIODE-TVS

0406-001596

ZD8018

DIODE-TVS

0406-001596

ZD8019

DIODE-TVS

0406-001606

R8032

DIODE-TVS

0406-001606

ZD8012

DIODE-TVS

0406-001606

ZD8017

DIODE-TVS

0406-001606

ZD8020

DIODE-TVS

0406-001606

ZD8021

DIODE-TVS

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-2

0406-001625

ZD5000

DIODE-TVS

0406-001625

ZD5001

DIODE-TVS

0406-001625

ZD5002

DIODE-TVS

0406-001625

ZD5003

DIODE-TVS

0406-001625

ZD5004

DIODE-TVS

0406-001625

ZD5005

DIODE-TVS

0406-001625

ZD5006

DIODE-TVS

0406-001668

ZD9005

DIODE-TVS

0406-001690

ZD8005

DIODE-TVS

0406-001690

ZD8006

DIODE-TVS

0505-002341

U7013

FET-SILICON

0505-003234

Q7000

FET-SILICON

0505-003403

Q9000

FET-SILICON

0601-003338

LED4000

LED

0601-003515

LED7000

LED

0801-003228

U7014

IC-CMOS LOGIC

0902-003145

UCP5000

IC-MICROPROCESSOR

1001-001394

U7006

IC-ANALOG SWITCH

1001-001650

U3001

IC-ANALOG MULTIPLEX

1001-001913

L2012

IC-RF SWITCH

1001-001913

U2004

IC-RF SWITCH

1001-001948

U1001

IC-RF SWITCH

1009-001066

U6001

IC-HALL EFFECT S/W

1107-002375

UCP302UP

IC-UFS

1201-003735

U4005

IC-GPS AMP

1201-003740

PAM1000

IC-POWER AMP

1201-003793

U2002

IC-IF/RF AMP

1201-003795

U2003

IC-IF/RF AMP

1201-003820

F2003

IC-IF/RF AMP

1201-003920

U8002

IC-AUDIO AMP

1201-003922

U1002

IC-POWER AMP

1201-003923

U1000

IC-POWER AMP

1202-001120

U9001

IC-VOLTAGE COMP.

1203-008211

U4010

IC-MULTI REG.

1203-008348

U9002

IC-DC/DC CONVERTER

1203-008361

U7015

IC-POWER SUPERVISOR

1203-008396

U7007

IC-POWER SUPERVISOR

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-3

1203-008472

U7001

IC-POWER SUPERVISOR

1203-008477

U7002

IC-POWER SUPERVISOR

1203-008478

U3000

IC-POWER SUPERVISOR

1203-008483

U7019

IC-BATTERY

1203-008487

U8010

IC-VOL. DETECTOR

1203-008507

U7003

IC-SWITCH REG.

1204-003619

U1004

IC-MODULATOR

1204-003621

U9000

IC-SIGNAL PROCESSOR

1205-004916

U4009

IC-SWITCH

1205-005015

U7005

IC-SWITCH

1205-005155

U4001

IC-GPS RECEIVER

1205-005246

U4012

IC-NFC/RFID

1205-005248

U8006

IC-CODEC

1205-005271

UCP302

IC-MODEM

1205-005272

U2001

IC-TRANSCEIVER

1209-002043

U1003

IC-DETECTOR

1209-002199

U4015

IC-ACCEL./GYRO SENSOR

1209-002279

U4003

IC-ETC SENSOR

1209-002294

U4006

IC-PRESSURE SENSOR

1209-002330

U4002

IC-MAGNETIC SENSOR

1209-002343

U4014

IC-OPTICS SENSOR

1404-001724

TH5000

THERMISTOR-NTC

1404-001724

TH5001

THERMISTOR-NTC

1404-001724

TH7000

THERMISTOR-NTC

1404-001734

V2000

THERMISTOR-NTC

1405-001183

V4000

VARISTOR

1405-001183

V4001

VARISTOR

1405-001395

C2057

VARISTOR

1405-001395

C2101

VARISTOR

1405-001395

C2111

VARISTOR

1405-001395

C2113

VARISTOR

1405-001395

C4011

VARISTOR

1405-001395

C4111

VARISTOR

1405-001395

C4112

VARISTOR

1405-001395

V5000

VARISTOR

1405-001395

V6000

VARISTOR

1405-001395

V6002

VARISTOR

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-4

2007-007131

R5036

R-CHIP

2007-007310

R5063

R-CHIP

2007-007310

R5076

R-CHIP

2007-007310

R5078

R-CHIP

2007-007315

R3003

R-CHIP

2007-007315

R3004

R-CHIP

2007-007315

R3009

R-CHIP

2007-007315

R4031

R-CHIP

2007-007316

R4030

R-CHIP

2007-007586

R7178

R-CHIP

2007-007589

R7046

R-CHIP

2007-007741

R2002

R-CHIP

2007-007741

R7012

R-CHIP

2007-007741

R7028

R-CHIP

2007-007741

R7182

R-CHIP

2007-007741

R7185

R-CHIP

2007-007741

U7012

R-CHIP

2007-007741

U7018

R-CHIP

2007-008043

R2000

R-CHIP

2007-008045

R3002

R-CHIP

2007-008045

R7013

R-CHIP

2007-008045

R7023

R-CHIP

2007-008045

R7032

R-CHIP

2007-008045

R7038

R-CHIP

2007-008045

R9010

R-CHIP

2007-008052

R5053

R-CHIP

2007-008052

R5054

R-CHIP

2007-008052

R9009

R-CHIP

2007-008055

R5023

R-CHIP

2007-008055

R5024

R-CHIP

2007-008055

R5025

R-CHIP

2007-008055

R5027

R-CHIP

2007-008055

R5095

R-CHIP

2007-008055

R7005

R-CHIP

2007-008055

R7007

R-CHIP

2007-008055

R7024

R-CHIP

2007-008055

R7025

R-CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-5

2007-008055

R7031

R-CHIP

2007-008057

R1010

R-CHIP

2007-008057

R1011

R-CHIP

2007-008211

R4032

R-CHIP

2007-008403

R7029

R-CHIP

2007-008419

R4016

R-CHIP

2007-008419

R5041

R-CHIP

2007-008419

R5042

R-CHIP

2007-008419

R5049

R-CHIP

2007-008419

R5050

R-CHIP

2007-008419

R5057

R-CHIP

2007-008419

R5058

R-CHIP

2007-008420

R7014

R-CHIP

2007-008420

R7027

R-CHIP

2007-008420

R8024

R-CHIP

2007-008420

R9007

R-CHIP

2007-008486

R5031

R-CHIP

2007-008486

R7002

R-CHIP

2007-008486

R7006

R-CHIP

2007-008486

R7008

R-CHIP

2007-008486

R7011

R-CHIP

2007-008486

R7020

R-CHIP

2007-008486

R7033

R-CHIP

2007-008486

R8037

R-CHIP

2007-008486

U7011

R-CHIP

2007-008516

R3013

R-CHIP

2007-008516

R3014

R-CHIP

2007-008516

R3017

R-CHIP

2007-008516

R3020

R-CHIP

2007-008516

R3029

R-CHIP

2007-008516

R4004

R-CHIP

2007-008516

R4005

R-CHIP

2007-008516

R4017

R-CHIP

2007-008516

R4040

R-CHIP

2007-008516

R4041

R-CHIP

2007-008516

R5000

R-CHIP

2007-008516

R5001

R-CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-6

2007-008516

R5003

R-CHIP

2007-008516

R5005

R-CHIP

2007-008516

R5016

R-CHIP

2007-008516

R5018

R-CHIP

2007-008516

R5094

R-CHIP

2007-008516

R7000

R-CHIP

2007-008516

R7021

R-CHIP

2007-008516

R7177

R-CHIP

2007-008516

R8001

R-CHIP

2007-008516

R8019

R-CHIP

2007-008516

R8025

R-CHIP

2007-008516

R9011

R-CHIP

2007-008531

R5029

R-CHIP

2007-008531

R9012

R-CHIP

2007-008587

R1009

R-CHIP

2007-008588

R4006

R-CHIP

2007-008588

R4007

R-CHIP

2007-008588

R4014

R-CHIP

2007-008588

R8035

R-CHIP

2007-008588

R8040

R-CHIP

2007-008588

R8041

R-CHIP

2007-008774

R8021

R-CHIP

2007-008774

R8022

R-CHIP

2007-008798

R7001

R-CHIP

2007-008800

R3005

R-CHIP

2007-008800

R3006

R-CHIP

2007-008800

R3007

R-CHIP

2007-008800

R3008

R-CHIP

2007-008800

R3011

R-CHIP

2007-008800

R3016

R-CHIP

2007-008806

R1019

R-CHIP

2007-009084

R5008

R-CHIP

2007-009084

R7004

R-CHIP

2007-009111

R4047

R-CHIP

2007-009155

R8018

R-CHIP

2007-009157

R4028

R-CHIP

2007-009157

R4048

R-CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-7

2007-009157

R5032

R-CHIP

2007-009157

R5033

R-CHIP

2007-009157

R5034

R-CHIP

2007-009157

R5035

R-CHIP

2007-009157

R5064

R-CHIP

2007-009157

R5065

R-CHIP

2007-009157

R5066

R-CHIP

2007-009157

R7181

R-CHIP

2007-009157

R7183

R-CHIP

2007-009157

R7194

R-CHIP

2007-009157

R8020

R-CHIP

2007-009158

R3031

R-CHIP

2007-009161

R7180

R-CHIP

2007-009171

R3010

R-CHIP

2007-009171

R7030

R-CHIP

2007-009171

R8038

R-CHIP

2007-009199

R1008

R-CHIP

2007-009201

R8007

R-CHIP

2007-009201

R8011

R-CHIP

2007-009212

R7184

R-CHIP

2007-009212

R7186

R-CHIP

2007-009212

R8008

R-CHIP

2007-009223

R3030

R-CHIP

2007-009314

R5089

R-CHIP

2007-009315

R8005

R-CHIP

2007-009352

R3021

R-CHIP

2007-009361

R1002

R-CHIP

2007-009361

R1018

R-CHIP

2007-009408

R5039

R-CHIP

2007-009408

R5040

R-CHIP

2007-009408

R5047

R-CHIP

2007-009408

R5048

R-CHIP

2007-009408

R5051

R-CHIP

2007-009408

R5052

R-CHIP

2007-009408

R5059

R-CHIP

2007-009408

R5060

R-CHIP

2007-009408

R5082

R-CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-8

2007-009408

R5083

R-CHIP

2007-009408

R5085

R-CHIP

2007-009408

R5086

R-CHIP

2007-009408

R5087

R-CHIP

2007-009408

R5088

R-CHIP

2007-009793

R5068

R-CHIP

2007-009801

R7198

R-CHIP

2007-009866

R9006

R-CHIP

2007-009866

R9008

R-CHIP

2007-009920

R3025

R-CHIP

2007-009920

R3026

R-CHIP

2007-009920

R5070

R-CHIP

2007-009920

R5071

R-CHIP

2007-009920

R5072

R-CHIP

2007-009920

R5073

R-CHIP

2007-009920

R5074

R-CHIP

2007-009920

R5077

R-CHIP

2007-009920

R7192

R-CHIP

2007-009954

R7041

R-CHIP

2007-009969

R7044

R-CHIP

2007-009969

R7045

R-CHIP

2007-009969

R8012

R-CHIP

2007-010029

R7179

R-CHIP

2007-010029

R8039

R-CHIP

2007-010202

R7059

R-CHIP

2007-010202

R7195

R-CHIP

2007-011043

R4003

R-CHIP

2007-011043

R5090

R-CHIP

2007-011532

R1015

R-CHIP

2007-011648

R8031

R-CHIP

2007-012033

R1014

R-CHIP

2007-012033

R1017

R-CHIP

2007-012038

R7037

R-CHIP

2203-000278

C4113

C-CER,CHIP

2203-000585

C4022

C-CER,CHIP

2203-000585

C4029

C-CER,CHIP

2203-000627

C4080

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-9

2203-000714

C7190

C-CER,CHIP

2203-000725

C7133

C-CER,CHIP

2203-001124

C4078

C-CER,CHIP

2203-001124

C4089

C-CER,CHIP

2203-001239

C4077

C-CER,CHIP

2203-001239

C4083

C-CER,CHIP

2203-001239

C7147

C-CER,CHIP

2203-002443

C7182

C-CER,CHIP

2203-005682

C2066

C-CER,CHIP

2203-005682

C2076

C-CER,CHIP

2203-005682

C3049

C-CER,CHIP

2203-005682

C4054

C-CER,CHIP

2203-005682

C4108

C-CER,CHIP

2203-005682

C5080

C-CER,CHIP

2203-005682

C5094

C-CER,CHIP

2203-005682

C7095

C-CER,CHIP

2203-005682

C7099

C-CER,CHIP

2203-005682

C7137

C-CER,CHIP

2203-005682

C7151

C-CER,CHIP

2203-005682

C8011

C-CER,CHIP

2203-005682

C8018

C-CER,CHIP

2203-005682

C8074

C-CER,CHIP

2203-005717

C7020

C-CER,CHIP

2203-005719

C4085

C-CER,CHIP

2203-005719

C7196

C-CER,CHIP

2203-005719

C8076

C-CER,CHIP

2203-005725

C1036

C-CER,CHIP

2203-005725

C1037

C-CER,CHIP

2203-005725

C1038

C-CER,CHIP

2203-005725

C1050

C-CER,CHIP

2203-005725

C1058

C-CER,CHIP

2203-005725

C1063

C-CER,CHIP

2203-005725

C1068

C-CER,CHIP

2203-005725

C1077

C-CER,CHIP

2203-005725

C1124

C-CER,CHIP

2203-005725

C2043

C-CER,CHIP

2203-005725

C2069

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-10

2203-005725

C4076

C-CER,CHIP

2203-005725

C4091

C-CER,CHIP

2203-005725

C9012

C-CER,CHIP

2203-005725

C9015

C-CER,CHIP

2203-005727

C4081

C-CER,CHIP

2203-005727

C4082

C-CER,CHIP

2203-005729

C1057

C-CER,CHIP

2203-005729

C2068

C-CER,CHIP

2203-005731

C5004

C-CER,CHIP

2203-005731

C5005

C-CER,CHIP

2203-005731

C7041

C-CER,CHIP

2203-005731

C8053

C-CER,CHIP

2203-005731

C8055

C-CER,CHIP

2203-005732

C8043

C-CER,CHIP

2203-005732

C8052

C-CER,CHIP

2203-005732

C8054

C-CER,CHIP

2203-005734

C8075

C-CER,CHIP

2203-005736

C1002

C-CER,CHIP

2203-005736

C1003

C-CER,CHIP

2203-005736

C1007

C-CER,CHIP

2203-005736

C1008

C-CER,CHIP

2203-005736

C1019

C-CER,CHIP

2203-005736

C1027

C-CER,CHIP

2203-005736

C1048

C-CER,CHIP

2203-005736

C1049

C-CER,CHIP

2203-005736

C1054

C-CER,CHIP

2203-005736

C1070

C-CER,CHIP

2203-005736

C1076

C-CER,CHIP

2203-005736

C1093

C-CER,CHIP

2203-005736

C1096

C-CER,CHIP

2203-005736

C1108

C-CER,CHIP

2203-005736

C1109

C-CER,CHIP

2203-005736

C1111

C-CER,CHIP

2203-005736

C1115

C-CER,CHIP

2203-005736

C1117

C-CER,CHIP

2203-005736

C1122

C-CER,CHIP

2203-005736

C2004

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-11

2203-005736

C2005

C-CER,CHIP

2203-005736

C2016

C-CER,CHIP

2203-005736

C2022

C-CER,CHIP

2203-005736

C2047

C-CER,CHIP

2203-005736

C2054

C-CER,CHIP

2203-005736

C2060

C-CER,CHIP

2203-005736

C2070

C-CER,CHIP

2203-005736

C2074

C-CER,CHIP

2203-005736

C2110

C-CER,CHIP

2203-005736

C4000

C-CER,CHIP

2203-005736

C4001

C-CER,CHIP

2203-005736

C4012

C-CER,CHIP

2203-005736

C4044

C-CER,CHIP

2203-005736

C4048

C-CER,CHIP

2203-005736

C4086

C-CER,CHIP

2203-005736

C4093

C-CER,CHIP

2203-005736

C7098

C-CER,CHIP

2203-005736

C7136

C-CER,CHIP

2203-005736

C7150

C-CER,CHIP

2203-005736

L4024

C-CER,CHIP

2203-005777

C4109

C-CER,CHIP

2203-005789

C1020

C-CER,CHIP

2203-005789

C1080

C-CER,CHIP

2203-005789

C2049

C-CER,CHIP

2203-005792

C2073

C-CER,CHIP

2203-005792

C4065

C-CER,CHIP

2203-005806

C1098

C-CER,CHIP

2203-005806

C2014

C-CER,CHIP

2203-005806

C2053

C-CER,CHIP

2203-006123

C2065

C-CER,CHIP

2203-006187

C4107

C-CER,CHIP

2203-006194

C2011

C-CER,CHIP

2203-006194

C5087

C-CER,CHIP

2203-006194

C8047

C-CER,CHIP

2203-006348

C8051

C-CER,CHIP

2203-006399

C1085

C-CER,CHIP

2203-006399

C1086

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-12

2203-006399

C4066

C-CER,CHIP

2203-006400

C1104

C-CER,CHIP

2203-006400

C2000

C-CER,CHIP

2203-006400

C2055

C-CER,CHIP

2203-006400

C3041

C-CER,CHIP

2203-006400

C3042

C-CER,CHIP

2203-006400

C3043

C-CER,CHIP

2203-006400

C4058

C-CER,CHIP

2203-006400

C7195

C-CER,CHIP

2203-006400

R5037

C-CER,CHIP

2203-006400

R5038

C-CER,CHIP

2203-006400

R8023

C-CER,CHIP

2203-006410

C1030

C-CER,CHIP

2203-006423

C1047

C-CER,CHIP

2203-006423

C1120

C-CER,CHIP

2203-006423

C2056

C-CER,CHIP

2203-006423

C2071

C-CER,CHIP

2203-006423

C2075

C-CER,CHIP

2203-006423

C2100

C-CER,CHIP

2203-006423

C3045

C-CER,CHIP

2203-006423

C3051

C-CER,CHIP

2203-006423

C3053

C-CER,CHIP

2203-006423

C4028

C-CER,CHIP

2203-006423

C4035

C-CER,CHIP

2203-006423

C4042

C-CER,CHIP

2203-006423

C4043

C-CER,CHIP

2203-006423

C5013

C-CER,CHIP

2203-006423

C6010

C-CER,CHIP

2203-006423

C6011

C-CER,CHIP

2203-006423

C6012

C-CER,CHIP

2203-006423

C6013

C-CER,CHIP

2203-006423

C6014

C-CER,CHIP

2203-006423

C6017

C-CER,CHIP

2203-006423

C6019

C-CER,CHIP

2203-006423

C6020

C-CER,CHIP

2203-006423

C6022

C-CER,CHIP

2203-006423

C6029

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-13

2203-006423

C6030

C-CER,CHIP

2203-006423

C6032

C-CER,CHIP

2203-006423

C6036

C-CER,CHIP

2203-006423

C6037

C-CER,CHIP

2203-006423

C6038

C-CER,CHIP

2203-006423

C6039

C-CER,CHIP

2203-006423

C7010

C-CER,CHIP

2203-006423

C7138

C-CER,CHIP

2203-006423

C8007

C-CER,CHIP

2203-006423

C8013

C-CER,CHIP

2203-006423

C8017

C-CER,CHIP

2203-006423

C8022

C-CER,CHIP

2203-006423

C8023

C-CER,CHIP

2203-006423

C8024

C-CER,CHIP

2203-006423

C8025

C-CER,CHIP

2203-006423

C9005

C-CER,CHIP

2203-006423

C9006

C-CER,CHIP

2203-006423

U4007

C-CER,CHIP

2203-006462

C1075

C-CER,CHIP

2203-006556

C4003

C-CER,CHIP

2203-006562

C8073

C-CER,CHIP

2203-006642

C4075

C-CER,CHIP

2203-006668

C2001

C-CER,CHIP

2203-006668

C2009

C-CER,CHIP

2203-006668

C5078

C-CER,CHIP

2203-006668

C9007

C-CER,CHIP

2203-006674

C1034

C-CER,CHIP

2203-006674

L2030

C-CER,CHIP

2203-006707

C4098

C-CER,CHIP

2203-006707

C4099

C-CER,CHIP

2203-006707

C4100

C-CER,CHIP

2203-006712

C1107

C-CER,CHIP

2203-006839

C3008

C-CER,CHIP

2203-006839

C3009

C-CER,CHIP

2203-006839

C3011

C-CER,CHIP

2203-006839

C3012

C-CER,CHIP

2203-006839

C3013

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-14

2203-006839

C3014

C-CER,CHIP

2203-006839

C3015

C-CER,CHIP

2203-006839

C3016

C-CER,CHIP

2203-006839

C3044

C-CER,CHIP

2203-006839

C3047

C-CER,CHIP

2203-006839

C3055

C-CER,CHIP

2203-006839

C3057

C-CER,CHIP

2203-006839

C4017

C-CER,CHIP

2203-006839

C4018

C-CER,CHIP

2203-006839

C4020

C-CER,CHIP

2203-006839

C4021

C-CER,CHIP

2203-006839

C4040

C-CER,CHIP

2203-006839

C4041

C-CER,CHIP

2203-006839

C5076

C-CER,CHIP

2203-006839

C5081

C-CER,CHIP

2203-006839

C5085

C-CER,CHIP

2203-006839

C5086

C-CER,CHIP

2203-006839

C5095

C-CER,CHIP

2203-006839

C7125

C-CER,CHIP

2203-006841

C7097

C-CER,CHIP

2203-006841

C7124

C-CER,CHIP

2203-006846

L1008

C-CER,CHIP

2203-006872

C3056

C-CER,CHIP

2203-006896

C2061

C-CER,CHIP

2203-006896

C2104

C-CER,CHIP

2203-006968

C1102

C-CER,CHIP

2203-006979

C1064

C-CER,CHIP

2203-006979

C2020

C-CER,CHIP

2203-006979

C2026

C-CER,CHIP

2203-006979

C2028

C-CER,CHIP

2203-006979

C2034

C-CER,CHIP

2203-006979

C2038

C-CER,CHIP

2203-006979

C2040

C-CER,CHIP

2203-006979

C4039

C-CER,CHIP

2203-006994

C4074

C-CER,CHIP

2203-007165

C8008

C-CER,CHIP

2203-007165

C8019

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-15

2203-007165

R4015

C-CER,CHIP

2203-007194

C2041

C-CER,CHIP

2203-007194

C2064

C-CER,CHIP

2203-007194

C4050

C-CER,CHIP

2203-007269

C9030

C-CER,CHIP

2203-007269

C9031

C-CER,CHIP

2203-007317

C4009

C-CER,CHIP

2203-007317

C4064

C-CER,CHIP

2203-007317

C6016

C-CER,CHIP

2203-007317

C7094

C-CER,CHIP

2203-007317

C8031

C-CER,CHIP

2203-007317

C8032

C-CER,CHIP

2203-007317

C8034

C-CER,CHIP

2203-007317

C8035

C-CER,CHIP

2203-007317

C8037

C-CER,CHIP

2203-007317

C8044

C-CER,CHIP

2203-007317

U4008

C-CER,CHIP

2203-007369

C3036

C-CER,CHIP

2203-007369

C4038

C-CER,CHIP

2203-007369

C4062

C-CER,CHIP

2203-007369

C4105

C-CER,CHIP

2203-007391

C1087

C-CER,CHIP

2203-007391

C7042

C-CER,CHIP

2203-007391

C8036

C-CER,CHIP

2203-007392

C7110

C-CER,CHIP

2203-007393

C4106

C-CER,CHIP

2203-007393

C7084

C-CER,CHIP

2203-007393

C7085

C-CER,CHIP

2203-007393

C7113

C-CER,CHIP

2203-007449

C2027

C-CER,CHIP

2203-007449

C2033

C-CER,CHIP

2203-007449

C2039

C-CER,CHIP

2203-007449

C3017

C-CER,CHIP

2203-007449

C3018

C-CER,CHIP

2203-007449

C3020

C-CER,CHIP

2203-007449

C3021

C-CER,CHIP

2203-007449

C3022

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-16

2203-007449

C3023

C-CER,CHIP

2203-007449

C3024

C-CER,CHIP

2203-007449

C3025

C-CER,CHIP

2203-007449

C3026

C-CER,CHIP

2203-007449

C3027

C-CER,CHIP

2203-007449

C3029

C-CER,CHIP

2203-007449

C3050

C-CER,CHIP

2203-007449

C3052

C-CER,CHIP

2203-007449

C4002

C-CER,CHIP

2203-007449

C4102

C-CER,CHIP

2203-007449

C5006

C-CER,CHIP

2203-007449

C5007

C-CER,CHIP

2203-007449

C5008

C-CER,CHIP

2203-007449

C5009

C-CER,CHIP

2203-007449

C5010

C-CER,CHIP

2203-007449

C5011

C-CER,CHIP

2203-007449

C5012

C-CER,CHIP

2203-007449

C5039

C-CER,CHIP

2203-007449

C5045

C-CER,CHIP

2203-007449

C5047

C-CER,CHIP

2203-007449

C5048

C-CER,CHIP

2203-007449

C5060

C-CER,CHIP

2203-007449

C5061

C-CER,CHIP

2203-007449

C5062

C-CER,CHIP

2203-007449

C5063

C-CER,CHIP

2203-007449

C5065

C-CER,CHIP

2203-007449

C5070

C-CER,CHIP

2203-007449

C5102

C-CER,CHIP

2203-007449

C5104

C-CER,CHIP

2203-007449

C5105

C-CER,CHIP

2203-007449

C5106

C-CER,CHIP

2203-007449

C6000

C-CER,CHIP

2203-007449

C6001

C-CER,CHIP

2203-007449

C6002

C-CER,CHIP

2203-007449

C6003

C-CER,CHIP

2203-007449

C6004

C-CER,CHIP

2203-007449

C6005

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-17

2203-007449

C6006

C-CER,CHIP

2203-007449

C6007

C-CER,CHIP

2203-007449

C6008

C-CER,CHIP

2203-007449

C6024

C-CER,CHIP

2203-007449

C6025

C-CER,CHIP

2203-007449

C7062

C-CER,CHIP

2203-007449

C7066

C-CER,CHIP

2203-007449

C7067

C-CER,CHIP

2203-007449

C7078

C-CER,CHIP

2203-007449

C7093

C-CER,CHIP

2203-007449

C7101

C-CER,CHIP

2203-007449

C7131

C-CER,CHIP

2203-007449

C8000

C-CER,CHIP

2203-007449

C8001

C-CER,CHIP

2203-007449

C8020

C-CER,CHIP

2203-007449

C8021

C-CER,CHIP

2203-007449

C8026

C-CER,CHIP

2203-007449

C8027

C-CER,CHIP

2203-007449

C8028

C-CER,CHIP

2203-007449

C8029

C-CER,CHIP

2203-007449

C8038

C-CER,CHIP

2203-007449

C8039

C-CER,CHIP

2203-007449

C8049

C-CER,CHIP

2203-007449

C9001

C-CER,CHIP

2203-007449

C9002

C-CER,CHIP

2203-007449

C9003

C-CER,CHIP

2203-007474

C4063

C-CER,CHIP

2203-007474

C7082

C-CER,CHIP

2203-007474

C7083

C-CER,CHIP

2203-007503

C7120

C-CER,CHIP

2203-007503

C7121

C-CER,CHIP

2203-007544

C7123

C-CER,CHIP

2203-007544

C7177

C-CER,CHIP

2203-007544

C7178

C-CER,CHIP

2203-007544

C7179

C-CER,CHIP

2203-007544

C7180

C-CER,CHIP

2203-007544

C7193

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-18

2203-007544

C7194

C-CER,CHIP

2203-007634

C8070

C-CER,CHIP

2203-007687

C7122

C-CER,CHIP

2203-007687

C7181

C-CER,CHIP

2203-007775

C7185

C-CER,CHIP

2203-007781

C9024

C-CER,CHIP

2203-007795

C2019

C-CER,CHIP

2203-007795

C2025

C-CER,CHIP

2203-007795

C2037

C-CER,CHIP

2203-007795

C2081

C-CER,CHIP

2203-007795

C3000

C-CER,CHIP

2203-007795

C3001

C-CER,CHIP

2203-007795

C3002

C-CER,CHIP

2203-007795

C3010

C-CER,CHIP

2203-007795

C3032

C-CER,CHIP

2203-007795

C3033

C-CER,CHIP

2203-007795

C3034

C-CER,CHIP

2203-007795

C4070

C-CER,CHIP

2203-007795

C5021

C-CER,CHIP

2203-007795

C6015

C-CER,CHIP

2203-007795

C7003

C-CER,CHIP

2203-007795

C7004

C-CER,CHIP

2203-007795

C7015

C-CER,CHIP

2203-007795

C7045

C-CER,CHIP

2203-007795

C7072

C-CER,CHIP

2203-007795

C7096

C-CER,CHIP

2203-007795

C7102

C-CER,CHIP

2203-007795

C7129

C-CER,CHIP

2203-007795

C9011

C-CER,CHIP

2203-007795

C9025

C-CER,CHIP

2203-007795

C9032

C-CER,CHIP

2203-007795

R8028

C-CER,CHIP

2203-007796

C1032

C-CER,CHIP

2203-007796

C1033

C-CER,CHIP

2203-007796

C1089

C-CER,CHIP

2203-007796

C1105

C-CER,CHIP

2203-007796

C1118

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-19

2203-007796

C1119

C-CER,CHIP

2203-007796

C3037

C-CER,CHIP

2203-007796

C3038

C-CER,CHIP

2203-007796

C3039

C-CER,CHIP

2203-007796

C3040

C-CER,CHIP

2203-007796

C3046

C-CER,CHIP

2203-007796

C4006

C-CER,CHIP

2203-007796

C4007

C-CER,CHIP

2203-007796

C4023

C-CER,CHIP

2203-007796

C4024

C-CER,CHIP

2203-007796

C4025

C-CER,CHIP

2203-007796

C4026

C-CER,CHIP

2203-007796

C4027

C-CER,CHIP

2203-007796

C4067

C-CER,CHIP

2203-007796

C4069

C-CER,CHIP

2203-007796

C4071

C-CER,CHIP

2203-007796

C4072

C-CER,CHIP

2203-007796

C4073

C-CER,CHIP

2203-007796

C4087

C-CER,CHIP

2203-007796

C4088

C-CER,CHIP

2203-007796

C4096

C-CER,CHIP

2203-007796

C7128

C-CER,CHIP

2203-007796

C7130

C-CER,CHIP

2203-007796

C7145

C-CER,CHIP

2203-007796

C8004

C-CER,CHIP

2203-007796

C8048

C-CER,CHIP

2203-007796

C9016

C-CER,CHIP

2203-007796

C9017

C-CER,CHIP

2203-007796

C9018

C-CER,CHIP

2203-007796

C9019

C-CER,CHIP

2203-007796

C9020

C-CER,CHIP

2203-007796

C9021

C-CER,CHIP

2203-007796

C9022

C-CER,CHIP

2203-007796

C9023

C-CER,CHIP

2203-008095

C1011

C-CER,CHIP

2203-008097

C1081

C-CER,CHIP

2203-008097

C1082

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-20

2203-008097

C1084

C-CER,CHIP

2203-008097

C1088

C-CER,CHIP

2203-008097

C1090

C-CER,CHIP

2203-008097

C1091

C-CER,CHIP

2203-008097

C1095

C-CER,CHIP

2203-008097

C2032

C-CER,CHIP

2203-008097

C2035

C-CER,CHIP

2203-008097

C2036

C-CER,CHIP

2203-008097

C7009

C-CER,CHIP

2203-008097

C7017

C-CER,CHIP

2203-008097

C7018

C-CER,CHIP

2203-008097

C7115

C-CER,CHIP

2203-008097

C7127

C-CER,CHIP

2203-008097

C8014

C-CER,CHIP

2203-008161

C7175

C-CER,CHIP

2203-008161

C7176

C-CER,CHIP

2203-008192

C7118

C-CER,CHIP

2203-008192

C7119

C-CER,CHIP

2203-008194

C2078

C-CER,CHIP

2203-008194

C2079

C-CER,CHIP

2203-008242

C3019

C-CER,CHIP

2203-008242

C3028

C-CER,CHIP

2203-008242

C3054

C-CER,CHIP

2203-008242

C4008

C-CER,CHIP

2203-008242

C5025

C-CER,CHIP

2203-008242

C5026

C-CER,CHIP

2203-008242

C5027

C-CER,CHIP

2203-008242

C5028

C-CER,CHIP

2203-008242

C5029

C-CER,CHIP

2203-008242

C5030

C-CER,CHIP

2203-008242

C5032

C-CER,CHIP

2203-008242

C5033

C-CER,CHIP

2203-008242

C5034

C-CER,CHIP

2203-008242

C5035

C-CER,CHIP

2203-008242

C5036

C-CER,CHIP

2203-008242

C5037

C-CER,CHIP

2203-008242

C5040

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-21

2203-008242

C5044

C-CER,CHIP

2203-008242

C5057

C-CER,CHIP

2203-008242

C5058

C-CER,CHIP

2203-008242

C5074

C-CER,CHIP

2203-008242

C5107

C-CER,CHIP

2203-008242

C5108

C-CER,CHIP

2203-008242

C5109

C-CER,CHIP

2203-008242

C7000

C-CER,CHIP

2203-008242

C7001

C-CER,CHIP

2203-008242

C7023

C-CER,CHIP

2203-008242

C7024

C-CER,CHIP

2203-008242

C7026

C-CER,CHIP

2203-008242

C7027

C-CER,CHIP

2203-008242

C7028

C-CER,CHIP

2203-008242

C7029

C-CER,CHIP

2203-008242

C7030

C-CER,CHIP

2203-008242

C7031

C-CER,CHIP

2203-008242

C7032

C-CER,CHIP

2203-008242

C7033

C-CER,CHIP

2203-008242

C7034

C-CER,CHIP

2203-008242

C7035

C-CER,CHIP

2203-008242

C7036

C-CER,CHIP

2203-008242

C7037

C-CER,CHIP

2203-008242

C7038

C-CER,CHIP

2203-008242

C7039

C-CER,CHIP

2203-008242

C7063

C-CER,CHIP

2203-008242

C7064

C-CER,CHIP

2203-008242

C7065

C-CER,CHIP

2203-008242

C7068

C-CER,CHIP

2203-008242

C7069

C-CER,CHIP

2203-008242

C7074

C-CER,CHIP

2203-008242

C7075

C-CER,CHIP

2203-008242

C7079

C-CER,CHIP

2203-008242

C7080

C-CER,CHIP

2203-008242

C7090

C-CER,CHIP

2203-008242

C7092

C-CER,CHIP

2203-008242

C7154

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-22

2203-008242

C7157

C-CER,CHIP

2203-008242

C7158

C-CER,CHIP

2203-008242

C7159

C-CER,CHIP

2203-008242

C8012

C-CER,CHIP

2203-008242

C8030

C-CER,CHIP

2203-008242

C8033

C-CER,CHIP

2203-008242

C8056

C-CER,CHIP

2203-008242

C9000

C-CER,CHIP

2203-008242

C9008

C-CER,CHIP

2203-008242

C9010

C-CER,CHIP

2203-008242

C9033

C-CER,CHIP

2203-008243

C4019

C-CER,CHIP

2203-008243

C4103

C-CER,CHIP

2203-008243

C4104

C-CER,CHIP

2203-008243

ZD8010

C-CER,CHIP

2203-008470

C7088

C-CER,CHIP

2203-008529

C1009

C-CER,CHIP

2203-008529

C4005

C-CER,CHIP

2203-008572

C7173

C-CER,CHIP

2203-008572

C7191

C-CER,CHIP

2203-008572

C8015

C-CER,CHIP

2203-008572

C8016

C-CER,CHIP

2203-008572

C8072

C-CER,CHIP

2203-008691

C7132

C-CER,CHIP

2203-008691

C7192

C-CER,CHIP

2203-008691

U4011

C-CER,CHIP

2203-008692

C3030

C-CER,CHIP

2203-008692

C8002

C-CER,CHIP

2203-008790

C7087

C-CER,CHIP

2203-008794

C1010

C-CER,CHIP

2203-008876

C7005

C-CER,CHIP

2203-008876

C7006

C-CER,CHIP

2203-008876

C7007

C-CER,CHIP

2203-008876

C7008

C-CER,CHIP

2203-008876

C7013

C-CER,CHIP

2203-008876

C7016

C-CER,CHIP

2203-008876

C7019

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-23

2203-008876

C7022

C-CER,CHIP

2203-008876

C7043

C-CER,CHIP

2203-008876

C7044

C-CER,CHIP

2203-008876

C7048

C-CER,CHIP

2203-008876

C7050

C-CER,CHIP

2203-008876

C7051

C-CER,CHIP

2203-008876

C7052

C-CER,CHIP

2203-008876

C7053

C-CER,CHIP

2203-008876

C7056

C-CER,CHIP

2203-008876

C7058

C-CER,CHIP

2203-008876

C7059

C-CER,CHIP

2203-008876

C7061

C-CER,CHIP

2203-008876

C7106

C-CER,CHIP

2203-008876

C7126

C-CER,CHIP

2203-008876

C7135

C-CER,CHIP

2203-008876

C7184

C-CER,CHIP

2203-009047

C1083

C-CER,CHIP

2203-009047

C1092

C-CER,CHIP

2203-009047

C8003

C-CER,CHIP

2203-009064

C5000

C-CER,CHIP

2203-009064

C5001

C-CER,CHIP

2203-009064

C5014

C-CER,CHIP

2203-009064

C5016

C-CER,CHIP

2203-009064

C5020

C-CER,CHIP

2203-009064

C5023

C-CER,CHIP

2203-009223

C4110

C-CER,CHIP

2203-009328

C3035

C-CER,CHIP

2203-009328

C5103

C-CER,CHIP

2203-009328

C7014

C-CER,CHIP

2203-009328

C7047

C-CER,CHIP

2203-009328

C7155

C-CER,CHIP

2203-009328

C7156

C-CER,CHIP

2203-009328

C9004

C-CER,CHIP

2203-009444

C1106

C-CER,CHIP

2203-009537

C3031

C-CER,CHIP

2203-009537

C5031

C-CER,CHIP

2203-009537

C7002

C-CER,CHIP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-24

2203-009537

C7021

C-CER,CHIP

2203-009537

C7046

C-CER,CHIP

2203-009537

C7049

C-CER,CHIP

2203-009537

C7054

C-CER,CHIP

2203-009537

C7055

C-CER,CHIP

2203-009537

C7057

C-CER,CHIP

2203-009537

C7060

C-CER,CHIP

2203-009537

C7070

C-CER,CHIP

2203-009537

C7071

C-CER,CHIP

2203-009537

C7073

C-CER,CHIP

2203-009537

C7076

C-CER,CHIP

2203-009537

C7077

C-CER,CHIP

2203-009537

C7081

C-CER,CHIP

2203-009537

C7086

C-CER,CHIP

2203-009537

C7152

C-CER,CHIP

2203-009537

C9026

C-CER,CHIP

2203-009537

C9027

C-CER,CHIP

2203-009537

C9028

C-CER,CHIP

2203-009537

C9029

C-CER,CHIP

2203-009537

C9034

C-CER,CHIP

2404-001561

TA8000

C-TA,CHIP

2409-001330

C7148

C-POLYMER ,CHIP

2703-002309

C2017

INDUCTOR-SMD

2703-002309

L7021

INDUCTOR-SMD

2703-002309

L7022

INDUCTOR-SMD

2703-002903

L1014

INDUCTOR-SMD

2703-002953

L1010

INDUCTOR-SMD

2703-002955

C1039

INDUCTOR-SMD

2703-002955

C1040

INDUCTOR-SMD

2703-002955

C1053

INDUCTOR-SMD

2703-002955

C1125

INDUCTOR-SMD

2703-002958

L1004

INDUCTOR-SMD

2703-002958

L2001

INDUCTOR-SMD

2703-002959

R9003

INDUCTOR-SMD

2703-002960

C2114

INDUCTOR-SMD

2703-002960

C4015

INDUCTOR-SMD

2703-003904

C1123

INDUCTOR-SMD

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-25

2703-003920

L2009

INDUCTOR-SMD

2703-003970

L4004

INDUCTOR-SMD

2703-004000

L1037

INDUCTOR-SMD

2703-004001

C1028

INDUCTOR-SMD

2703-004013

L1047

INDUCTOR-SMD

2703-004018

L2010

INDUCTOR-SMD

2703-004034

C4092

INDUCTOR-SMD

2703-004035

C1001

INDUCTOR-SMD

2703-004035

C1029

INDUCTOR-SMD

2703-004035

C1072

INDUCTOR-SMD

2703-004035

C1073

INDUCTOR-SMD

2703-004037

C1071

INDUCTOR-SMD

2703-004037

C2042

INDUCTOR-SMD

2703-004037

C2067

INDUCTOR-SMD

2703-004037

L1022

INDUCTOR-SMD

2703-004037

L1023

INDUCTOR-SMD

2703-004037

L1028

INDUCTOR-SMD

2703-004037

L2011

INDUCTOR-SMD

2703-004037

L2015

INDUCTOR-SMD

2703-004037

L2020

INDUCTOR-SMD

2703-004038

C1055

INDUCTOR-SMD

2703-004038

C1097

INDUCTOR-SMD

2703-004038

C2002

INDUCTOR-SMD

2703-004038

L1017

INDUCTOR-SMD

2703-004038

L1021

INDUCTOR-SMD

2703-004038

L2008

INDUCTOR-SMD

2703-004193

L1006

INDUCTOR-SMD

2703-004193

L1039

INDUCTOR-SMD

2703-004286

C2044

INDUCTOR-SMD

2703-004286

L1029

INDUCTOR-SMD

2703-004286

L2034

INDUCTOR-SMD

2703-004287

C1094

INDUCTOR-SMD

2703-004288

C2046

INDUCTOR-SMD

2703-004289

C1016

INDUCTOR-SMD

2703-004289

L1019

INDUCTOR-SMD

2703-004289

L1049

INDUCTOR-SMD

2703-004289

L2017

INDUCTOR-SMD

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-26

2703-004290

C2006

INDUCTOR-SMD

2703-004298

C1031

INDUCTOR-SMD

2703-004298

L1012

INDUCTOR-SMD

2703-004298

L4006

INDUCTOR-SMD

2703-004300

L2014

INDUCTOR-SMD

2703-004328

L2019

INDUCTOR-SMD

2703-004328

L4003

INDUCTOR-SMD

2703-004328

L4005

INDUCTOR-SMD

2703-004332

L9003

INDUCTOR-SMD

2703-004365

L1000

INDUCTOR-SMD

2703-004366

L4019

INDUCTOR-SMD

2703-004366

L4025

INDUCTOR-SMD

2703-004367

L1009

INDUCTOR-SMD

2703-004368

L1046

INDUCTOR-SMD

2703-004371

L4021

INDUCTOR-SMD

2703-004764

C1100

INDUCTOR-SMD

2703-004914

L4007

INDUCTOR-SMD

2703-005007

L9002

INDUCTOR-SMD

2703-005058

L7023

INDUCTOR-SMD

2703-005066

L7000

INDUCTOR-SMD

2703-005066

L8001

INDUCTOR-SMD

2703-005067

L7001

INDUCTOR-SMD

2703-005067

L7004

INDUCTOR-SMD

2703-005067

L7006

INDUCTOR-SMD

2703-005067

L7007

INDUCTOR-SMD

2703-005067

L7008

INDUCTOR-SMD

2703-005067

L7009

INDUCTOR-SMD

2703-005067

L7010

INDUCTOR-SMD

2703-005067

L7013

INDUCTOR-SMD

2703-005067

L7014

INDUCTOR-SMD

2703-005067

L7015

INDUCTOR-SMD

2703-005067

L7016

INDUCTOR-SMD

2703-005067

L7017

INDUCTOR-SMD

2703-005070

L9006

INDUCTOR-SMD

2703-005100

U8000

INDUCTOR-SMD

2703-005100

U8001

INDUCTOR-SMD

2703-005104

L4031

INDUCTOR-SMD

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-27

2703-005104

L4032

INDUCTOR-SMD

2703-005170

L1034

INDUCTOR-SMD

2703-005170

L1035

INDUCTOR-SMD

2703-005201

U7009

INDUCTOR-SMD

2703-005225

L1036

INDUCTOR-SMD

2703-005225

L3000

INDUCTOR-SMD

2703-005225

L3001

INDUCTOR-SMD

2703-005225

L3002

INDUCTOR-SMD

2703-005225

L3003

INDUCTOR-SMD

2703-005225

L3004

INDUCTOR-SMD

2703-005225

L7018

INDUCTOR-SMD

2703-005226

L7002

INDUCTOR-SMD

2703-005226

L7003

INDUCTOR-SMD

2703-005226

L7005

INDUCTOR-SMD

2703-005226

L7011

INDUCTOR-SMD

2703-005226

L7012

INDUCTOR-SMD

2801-005252

OSC5000

CRYSTAL-SMD

2801-005393

OSC7000

CRYSTAL-SMD

2802-001287

OSC4001

RESONATOR-CERAMIC

2805-001106

OSC4000

OSCILLATOR-TCXO

2809-001411

TCX2000

OSCILLATOR-VCTCXO

2901-001690

C3003

FILTER-EMI SMD

2901-001690

C3004

FILTER-EMI SMD

2901-001690

C3005

FILTER-EMI SMD

2901-001690

C3006

FILTER-EMI SMD

2901-001690

C3007

FILTER-EMI SMD

2901-001690

C3048

FILTER-EMI SMD

2901-001690

C5002

FILTER-EMI SMD

2901-001690

C5003

FILTER-EMI SMD

2901-001690

C5015

FILTER-EMI SMD

2901-001690

C5017

FILTER-EMI SMD

2901-001690

C5018

FILTER-EMI SMD

2901-001690

C5019

FILTER-EMI SMD

2901-001690

C5022

FILTER-EMI SMD

2901-001690

C5090

FILTER-EMI SMD

2901-001690

C5091

FILTER-EMI SMD

2901-001690

C5092

FILTER-EMI SMD

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-28

2901-001690

C5093

FILTER-EMI SMD

2901-001758

F9000

FILTER-EMI/ESD

2901-001758

F9001

FILTER-EMI/ESD

2901-001758

F9002

FILTER-EMI/ESD

2901-001786

F9003

FILTER-EMI/ESD

2901-001786

F9004

FILTER-EMI/ESD

2901-001786

F9005

FILTER-EMI/ESD

2901-001786

F9006

FILTER-EMI/ESD

2901-001786

F9007

FILTER-EMI/ESD

2901-001802

F9008

FILTER-EMI/ESD

2901-001802

F9009

FILTER-EMI/ESD

2901-001802

F9010

FILTER-EMI/ESD

2901-001802

F9011

FILTER-EMI/ESD

2901-001802

F9012

FILTER-EMI/ESD

2904-002134

F2006

FILTER-SAW

2904-002141

F1000

FILTER-SAW

2904-002143

F2007

FILTER-SAW

2904-002168

F4003

FILTER-SAW

2904-002168

F4005

FILTER-SAW

2904-002236

F4000

FILTER-SAW

2904-002286

F4001

FILTER-SAW

2904-002298

F2004

FILTER-SAW

2911-000364

F2005

DUPLEXER-FEM

2911-000367

F2001

DUPLEXER-FEM

3301-001885

L8007

BEAD-SMD

3301-001885

R8014

BEAD-SMD

3301-001895

L2005

BEAD-SMD

3301-001895

L2006

BEAD-SMD

3301-001895

L2007

BEAD-SMD

3301-001895

L2018

BEAD-SMD

3301-001895

L4002

BEAD-SMD

3301-001895

L4014

BEAD-SMD

3301-001895

L4015

BEAD-SMD

3301-002078

L9000

BEAD-SMD

3301-002228

L8000

BEAD-SMD

3301-002235

L2035

BEAD-SMD

3301-002236

R9000

BEAD-SMD

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-29

3301-002236

R9001

BEAD-SMD

3301-002236

R9002

BEAD-SMD

3301-002242

L8006

BEAD-SMD

3301-002248

C2015

BEAD-SMD

3301-002269

L7019

BEAD-SMD

3301-002269

L7020

BEAD-SMD

3301-002269

L8002

BEAD-SMD

3301-002279

L8004

BEAD-SMD

3301-002279

L8005

BEAD-SMD

3301-002286

C6009

BEAD-SMD

3301-002286

C6021

BEAD-SMD

3301-002312

C2013

BEAD-SMD

3301-002312

C2021

BEAD-SMD

3301-002312

C2029

BEAD-SMD

3301-002312

L1045

BEAD-SMD

3301-002312

L1048

BEAD-SMD

3301-002312

L9001

BEAD-SMD

3301-002312

L9004

BEAD-SMD

3301-002312

L9005

BEAD-SMD

3705-001708

RFS1001

CONNECTOR-COAXIAL

3705-001708

RFS1003

CONNECTOR-COAXIAL

3705-002014

RFS1000

CONNECTOR-COAXIAL

3705-002014

RFS1002

CONNECTOR-COAXIAL

3709-001871

SIM5001

CONNECTOR-CARD EDGE

3711-007172

HDC4001

HEADER-BOARD TO BOARD

3711-008600

HDC4000

HEADER-BOARD TO BOARD

3711-008650

HDC8000

HEADER-BOARD TO BOARD

3711-008716

HDC9002

HEADER-BOARD TO BOARD

3711-008842

HDC9000

HEADER-BOARD TO BOARD

3711-008847

HDC7000

CONNECTOR-BATTERY

3711-008925

HDC9001

HEADER-BOARD TO BOARD

3712-001544

ANT7002

CONNECTOR-TERMINAL

3712-001544

ANT7003

CONNECTOR-TERMINAL

3712-001564

ANT2000

CONNECTOR-TERMINAL

3712-001564

ANT2002

CONNECTOR-TERMINAL

3712-001564

ANT2003

CONNECTOR-TERMINAL

3712-001564

ANT2004

CONNECTOR-TERMINAL

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-30

3712-001564

ANT2006

CONNECTOR-TERMINAL

3712-001564

ANT2008

CONNECTOR-TERMINAL

3712-001564

ANT4000

CONNECTOR-TERMINAL

3712-001564

ANT4004

CONNECTOR-TERMINAL

3712-001564

ANT4006

CONNECTOR-TERMINAL

3712-001569

ANT4010

CONNECTOR-TERMINAL

3712-001569

ANT4011

CONNECTOR-TERMINAL

3712-001569

ANT4012

CONNECTOR-TERMINAL

3712-001569

ANT4013

CONNECTOR-TERMINAL

3712-001569

ANT4014

CONNECTOR-TERMINAL

3712-001569

ANT4015

CONNECTOR-TERMINAL

3712-001569

ANT4016

CONNECTOR-TERMINAL

3712-001569

ANT7000

CONNECTOR-TERMINAL

3712-001569

ANT7001

CONNECTOR-TERMINAL

3712-001569

ANT7004

CONNECTOR-TERMINAL

3712-001569

ANT7005

CONNECTOR-TERMINAL

3712-001569

ANT7006

CONNECTOR-TERMINAL

3712-001569

ANT8000

CONNECTOR-TERMINAL

3712-001569

ANT8001

CONNECTOR-TERMINAL

4709-002187

CPL1000

COUPLER-DIRECTION

4709-002196

F1002

FREQ-DISTRIBUTER

4709-002196

F2000

FREQ-DISTRIBUTER

4709-002346

U4004

FREQ-DISTRIBUTER

4709-002348

U4000

W-LAN MODULE

GH02-09801A

SDP1

THERMAL CONDUCTIVE ADHESIVE-S

HIELD CAN

GH41-04693A



PCB MAIN-SM_G920F

GH62-00040A

CN1102

PAD GAP-SMD GASKET (SM-G925F)

GH62-00040A

CN1103

PAD GAP-SMD GASKET (SM-G925F)

GH62-00040A

CN1104

PAD GAP-SMD GASKET (SM-G925F)

GH62-00040A

CN6000

PAD GAP-SMD GASKET (SM-G925F)

GH62-00040A

CN6001

PAD GAP-SMD GASKET (SM-G925F)

GH62-00040A

CN9002

PAD GAP-SMD GASKET (SM-G925F)

GH63-09845A

SUS6000

SHIELD-PCB PLATE TOP

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-31

GH63-10455A

SC6004

SHIELD CAN-RF

GH63-10456A

SC6002

SHIELD CAN-TRCV

GH63-10597A

SC6003

SHIELD-AP(64GB)

GH63-10598A

SC6007

SHIELD-CP(64GB)

GH80-03321A

R6003

SOLDER-CREAM

GH80-03321A

R8000

SOLDER-CREAM

GH80-03321A

R8036

SOLDER-CREAM

GH98-35907A

SC6001

ASSY SHIELD CAN-ET

GH98-36442A

SC6006

ASSY SHIELD CAN-PMIC

Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list.


Wyszukiwarka

Podobne podstrony:
SM G920F EPLIS 11
SM G360FY EPLIS 11
SM J700F EPLIS 11
SM P901 EPLIS 11
SM G350E EPLIS 11
SM A300H EPLIS 11
SM G7202 EPLIS 11
SM G600FY EPLIS 11
SM G900F EPLIS 11
SM G318HZ EPLIS 11
SM A710FD EPLIS 11
SM T805 EPLIS 11
SM T531 EPLIS 11
SM N900 EPLIS 11
SM J500F EPLIS 11
SM G531H EPLIS 11
SM T705 EPLIS 11

więcej podobnych podstron
