Process This

hile the term “signal processing” can cover a

full range of topics, we’ve decided to concentrate on

processing in this issue’s theme articles.

DSP continues to he a hot topic, with more and more

consumer and industrial devices showing up on the market sporting features
and capabilities previously found only on very expensive equipment or not
found anywhere at all.

Does digital signal processing necessarily mean the use of a dedicated

digital signal processor chip, though? In our first article, we take a look

instances where some of today’s fast RISC processors actually look pretty
good next to dedicated

in traditional

DSP applications.

Our next two articles move away from benchmarks and theory and into

the practical uses of DSP chips. Audio spectrum analyzers have traditionally
been

using rows of analog filters tuned for specific frequencies. Using

DSP, though, our first project fits in the palm of your hand while analyzing

the frequency content of a voice input and displaying the results on an
oscilloscope screen. Our second project demonstrates the dynamic nature of
filters implemented using DSP as the

Audio Waveform Shaper

works to extract voice from a signal full of static.

I’m particularly excited about the last article in the feature section this

issue. The single most important invention in the development of today’s
high-speed electronic computer was unquestionably the silicon transistor.
However, electron-based computers are quickly approaching theoretical
limits when it comes to speed and size. Light is certainly going to play a
large role in future computers. We are thrilled to be the first publication to run
an article detailing a new invention that could be as important to the

computer industry as the silicon transistor: the photonic transistor. Using
light and holograms, future computers many orders of magnitude faster than
today’s best desktop machines will be the norm, all based on the very simple
photonic transistor. Be sure to check it out.

In our

section, we take a look at how to replace the popular

stepper motor with a closed-loop DC motor control system that offers
additional benefits over steppers. In the second article, we discuss a topic
many readers have written to us about: designing with programmable logic
devices. There are some pitfalls you have to avoid if you want a solid design.

out our issue are our regular columns. Ed wraps up his

series describing the various HCS II modules by presenting some tricks he
used in the DIO- and

modules. He

also lets us in on a very useful

debugging session that took place in the Circuit Cellar. Jeff shares the
results of his experiments using the latest in instant PC board etching
systems. Tom reviews a new standard designed to eliminate much of the
cable clutter found behind a typical PC. Finally, John explores some options
for reducing power consumption in battery-powered embedded systems
without the need for complicated power monitoring hardware.

our next issue, we’ll have articles dealing with Measurement 8

Control and Embedded Graphics Video, so watch for it in the mail.
