MX PRO Lo 80 100 120Service

background image

2008 - MX PRO LO

Technical instructions

© Marzocchi Suspension

2008 - MX PRO LO

background image

Spare part list - MX PRO LO - 80

Rif.

Code

Description

Q.ty in the
model

1

818529/E

CROWN+STANC+STEM-MX PRO LO '08

1

3

504350-TW

AIR PLUG- MX PRO LO '08

1

4

528320-TW
(replaces EXR FAA072)

O RING (P22)FAA072

2

5

549072AD

ALUMINUM BLACK KNOB

1

6

504351-TW

ADJUST CAP FEE260-40

1

7

549143-TW

ADJUST KNOB FEE255-32

1

11

5141674-TW

MAIN SPRING-MX PRO LO 80 '08

1

12

533301

DUST SEAL DIA.30

2

13

523261

STOP RING

2

14

528172NOK>B
(replaces 528172NOK)

OIL SEAL DIA.30

2

17

850690

OIL SEAL KIT M/ARCH

1

19

5321364VT/C

BLACK MONOL.D.30 MX PRO LO '08

1

19

5321364VI/C

WHITE MONOL.D.30 MX PRO LO '08

1

20

547971

RH+LH BLK LABELS-MX PRO LO '08

1

20

547972

RH+LH WTE LABELS-MX PRO LO '08

1

21

523011

STOP RING

1

22

5321106

RUBBER

1

23

5321158>A

CABLE GUIDE

1

24

5321114>A
(replaces 5321114)

PIN ADAPTOR

2

25

5321115QF>A
(replaces 5321115QF)

CANTILEVER PIN

2

30

528046

O-RING

2

31

5321129>A

FOOT NUT UNIT

1

32

5321130>B
(replaces 5321130>A)

FOOT NUT UNIT

1

33

549067

ADJUSTER

1

35

520313

SCREW

1

40

524127>A

PISTON RING

1

42

703836-TW

DAMPER UNIT FUN006-23

1

45

5141410

C/ML 20DE23.0DI18.2 K F

1

46

5181094>A
(replaces 5181094)

PRELOAD SLEEVE 40MM LONG

1

47

805023

GR.BUSTA+ROND+VALVOLA D30'06

1

49

523270

STOP RING

1

50

512105

FOOT BUFFER

1

54

528223

O-RING

1

© Marzocchi Suspension

2008 - MX PRO LO

background image

Spare part list - MX PRO LO - 100

Rif.

Code

Description

Q.ty in the
model

1

818529/E

CROWN+STANC+STEM-MX PRO LO '08

1

3

504350-TW

AIR PLUG- MX PRO LO '08

1

4

528320-TW
(replaces EXR FAA072)

O RING (P22)FAA072

2

5

549072AD

ALUMINUM BLACK KNOB

1

6

504351-TW

ADJUST CAP FEE260-40

1

7

549143-TW

ADJUST KNOB FEE255-32

1

11

5141673-TW

MAIN SPRING FEP209-10

1

12

533301

DUST SEAL DIA.30

2

13

523261

STOP RING

2

14

528172NOK>B
(replaces 528172NOK)

OIL SEAL DIA.30

2

17

850690

OIL SEAL KIT M/ARCH

1

19

5321364VT/C

BLACK MONOL.D.30 MX PRO LO '08

1

19

5321364VI/C

WHITE MONOL.D.30 MX PRO LO '08

1

20

547971

RH+LH BLK LABELS-MX PRO LO '08

1

20

547972

RH+LH WTE LABELS-MX PRO LO '08

1

21

523011

STOP RING

1

22

5321106

RUBBER

1

23

5321158>A

CABLE GUIDE

1

24

5321114>A
(replaces 5321114)

PIN ADAPTOR

2

25

5321115QF>A
(replaces 5321115QF)

CANTILEVER PIN

2

30

528046

O-RING

2

31

5321129>A

FOOT NUT UNIT

1

32

5321130>B
(replaces 5321130>A)

FOOT NUT UNIT

1

33

549067

ADJUSTER

1

35

520313

SCREW

1

40

524127>A

PISTON RING

1

41

8031422

GR.POMP.30 EST.F/R EXR1 100'06

1

42

703836-TW

DAMPER UNIT FUN006-23

1

45

5141410

C/ML 20DE23.0DI18.2 K F

1

46

5181268

PRELOAD SLEEVE 15MM LONG

1

47

805023

GR.BUSTA+ROND+VALVOLA D30'06

1

49

523270

STOP RING

1

50

512105

FOOT BUFFER

1

54

528223

O-RING

1

© Marzocchi Suspension

2008 - MX PRO LO

background image

Spare part list - MX PRO LO - 120

Rif.

Code

Description

Q.ty in the
model

1

818529/E

CROWN+STANC+STEM-MX PRO LO '08

1

3

504350-TW

AIR PLUG- MX PRO LO '08

1

4

528320-TW
(replaces EXR FAA072)

O RING (P22)FAA072

2

5

549072AD

ALUMINUM BLACK KNOB

1

6

504351-TW

ADJUST CAP FEE260-40

1

7

549143-TW

ADJUST KNOB FEE255-32

1

11

5141672-TW

MAIN SPRING FEP208-10

1

12

533301

DUST SEAL DIA.30

2

13

523261

STOP RING

2

14

528172NOK>B
(replaces 528172NOK)

OIL SEAL DIA.30

2

17

850690

OIL SEAL KIT M/ARCH

1

19

5321364VT/C

BLACK MONOL.D.30 MX PRO LO '08

1

19

5321364VI/C

WHITE MONOL.D.30 MX PRO LO '08

1

20

547971

RH+LH BLK LABELS-MX PRO LO '08

1

20

547972

RH+LH WTE LABELS-MX PRO LO '08

1

21

523011

STOP RING

1

22

5321106

RUBBER

1

23

5321158>A

CABLE GUIDE

1

24

5321114>A
(replaces 5321114)

PIN ADAPTOR

2

25

5321115QF>A
(replaces 5321115QF)

CANTILEVER PIN

2

30

528046

O-RING

2

31

5321129>A

FOOT NUT UNIT

1

32

5321130>B
(replaces 5321130>A)

FOOT NUT UNIT

1

33

549067

ADJUSTER

1

35

520313

SCREW

1

40

524127>A

PISTON RING

1

41

8031421

GR.POMP.30 EST.F/R EXR1 120'06

1

42

703836-TW

DAMPER UNIT FUN006-23

1

45

5141410

C/ML 20DE23.0DI18.2 K F

1

47

805023

GR.BUSTA+ROND+VALVOLA D30'06

1

49

523270

STOP RING

1

50

512105

FOOT BUFFER

1

54

528223

O-RING

1

© Marzocchi Suspension

2008 - MX PRO LO

background image

Technical characteristics: Technical characteristics

Single-crown fork with ø 30mm legs.

Available travels: 80 mm, 100 mm, 120 mm.

Right fork leg damping element: spring (air pre-load).

Left fork leg damping element -

Right fork leg damping system: pumping element with external rebound adjustment.

Left fork leg damping system: LOCK OUT cartridge.

The stanchion tubes are pressed into the crown.

Lubrication and cooling of the parts subject to friction with a specially formulated oil.

Steer tube: steel or (optional) aluminium, 1-1/8", threadless.

Crown: aluminium alloy forged and CNC machined.

Stanchions: anodised aluminium.

One-piece assembly: made of magnesium alloy cast and CNC machined for lighter weight and more stiffness.

Sliding bushings: made of friction-free and wear-free material.

Seals: computer designed oil seals that guarantee maximum seal in any condition.

Oil: specially formulated oil that prevents foam and keeps the viscosity unchanged while offering high performance; free from static friction.

Dropout type: standard.

Disk brake mount: Post Mount for 6" disk (fitting the special adapter supplied by the brake system manufacturer you can install the 7" disk).

V-Brake fit: removable.

Max wheel size: 2.2" x 26".

© Marzocchi Suspension

2008 - MX PRO LO

background image

Tightening torques


MX PRO LO - 80 - Oil levels

MX PRO LO - 100 - Oil levels

MX PRO LO - 120 - Oil levels

Components Tightening torque (Nm)

Position

Oil type

Quantity (cc)

Right fork leg SAE 7,5 - 550013

125

Left fork leg

EXR 9170-001

7,5

Position

Oil type

Quantity (cc)

Right fork leg SAE 7,5 - 550013

125

Left fork leg

EXR 9170-001

7,5

Position

Oil type

Quantity (cc)

Right fork leg SAE 7,5 - 550013

125

Left fork leg

EXR 9170-001

7,5

© Marzocchi Suspension

2008 - MX PRO LO

background image

© Marzocchi Suspension

2008 - MX PRO LO
