MEMORY CH-

MEMORY CHANNELS

In Memory channels, you can store frequencies and related data that you often use. Then you need not reprogram the

data every time. You can quickly recall a programmed channel by simple operation. A total of 1000 Memory channels

are available for bands A and B.

SIMPLEX & REPEATER OR ODD-SPLIT MEMORY
CHANNEL?

You can use each memory channel as a simplex &

repeater channel or as an odd-split channel. Store only

one frequency to use as a simplex & repeater channel or

two separate frequencies to use as an odd-split channel.

Select either application for each channel depending on

the operations you have in mind.
Simplex & repeater channels allow:
• Simplex frequency operation
• Repeater operation with a standard offset (if an offset

direction is stored)

Odd-split channels allow:
• Repeater operation with a non-standard offset
The data listed below can be stored in each Memory

channel:

Parameter

Simplex &

Repeater

Odd-split

Receive frequency

Yes

Yes

Transmit frequency

Yes

Receive frequency

step size

Yes

Yes

Transmit frequency

step size

Yes

Offset direction

Yes

No

Tone ON/OFF

Yes

Yes

Tone frequency

Yes

Yes

CTCSS ON/OFF

Yes

Yes

CTCSS frequency

Yes

Yes

DCS ON/OFF

Yes

Yes

DCS code

Yes

Yes

Reverse ON/OFF

Yes

No

Memory channel

lockout

Yes

Yes

Memory channel

name

Yes

Yes

Modulation/

Demodulation mode

Yes

Yes

STORINg SIMPLEX AND STANDARD REPEATER
FREquENCIES

1 Press [VFO] to enter VFO mode.
2 Rotate the Tuning control to select your desired

frequency.

• Additionally, you can press the microphone

[UP]/[DWN]

keys to select a frequency.

3 Set up any additional data desired for the frequency.

• Offset direction, Tone ON/OFF, Tone frequency, CTCSS

ON/OFF, CTCSS frequency, DCS ON/OFF, DCS code,

etc.

4 Press [F].

• A memory channel number appears.

5 Rotate the Tuning control to select your desired

channel number.

• When the selected channel number does not have stored

data, the “ ” icon appears. When the channel does have

stored data, the “ ” icon appears.

• Additionally, you can press the microphone

[UP]/[DWN]

keys to select a channel.

6 Press [M.IN] to store the data in the selected Memory

channel.

Note: If you store the data in a Memory channel that already has

data stored in it, the old data will be cleared and the new data will be

stored.

n

Call Channel Memory (Simplex)

The Call channel can be used to store any frequency

and related data that you will recall often. You may

want to dedicate the Call channel as an emergency

channel within your group.

To store a simplex frequency and related data as the

Call channel instead of in a Memory channel, after step

4 (above), press

[C.IN].

Note: Storing new data in the Call channel will clear the old

data. (The Call channel itself cannot be cleared, but data can be

replaced with new data.)

MEMORY CH-

STORINg ODD-SPLIT REPEATER FREquENCIES

Some repeaters use a receive and transmit frequency pair

with a non-standard offset. To access those repeaters,

store two separate frequencies in a memory channel. You

can then operate on those repeaters without changing the

offset frequency you stored in the menu.
1 Set up a simplex channel by following steps 1 to 6 of

“STORING SIMPLEX AND STANDARD REPEATER

FREQUENCIES”, above.

2 Press [VFO] to enter VFO mode.
3 Rotate the Tuning control to select your desired

transmit frequency.

• Additionally, you can press the microphone

[UP]/[DWN]

keys to select a frequency.

4 Set up any additional data desired for the transmit

frequency.

• Tone ON/OFF, Tone frequency, CTCSS ON/OFF, CTCSS

frequency, DCS ON/OFF, DCS code, etc.

5 Press [F].

• A memory channel number appears.

6 Rotate the Tuning control to select your desired

channel number.

• Additionally, you can press the microphone

[UP]/[DWN]

keys to select a channel.

7 Press [PTT], [M.IN] to store the data in the selected

Memory channel.

n

Call Channel Memory (Odd-Split)

The Call channel can be used to store any frequency

and related data that you will recall often. You may

want to dedicate the Call channel as an emergency

channel within your group.

To store an odd-split frequency and related data as the

Call channel instead of in a Memory channel, after step

6 (above), press

[PTT], [C.IN].

Note: You cannot store the transmit offset status and Reverse

status in an odd-split Call channel.

RECALLINg A MEMORY CHANNEL

1 Press [MR] to enter Memory Recall mode.
2 Rotate the Tuning control to select your desired

Memory channel.

• Additionally, you can press the microphone

[UP]/[DWN]

keys to select a channel, or you can enter a channel

number using the microphone keypad.

n

Memory Recall Method

The transceiver Menu also provides you with the option

to recall Memory channels with stored frequencies in

your current band, or all Memory channels:
1 Enter Menu mode and access Menu 201.

2 Set the recall method to CURRENT (current band)

or ALL BANDS (all bands).

• CURRENT allows you to recall only those memory

channels that have stored frequencies within the

current band. ALL allows you to recall all programmed

memory channels.

• When the recalled memory channel is an AM channel,

you cannot recall on the B band.

Frequency ranges:
• 118 MHz: 118 ~ 135.995 MHz

• 144 MHz: 136 ~ 199.995 MHz
• 220 MHz: 200 ~ 299.995 MHz

• 300 MHz: 300 ~ 399.995 MHz
• 430/440 MHz: 400 ~ 523.995 MHz
• 1200 MHz: 800 ~ 1299.990 MHz

CLEARINg A MEMORY CHANNEL

1 Press [MR] to enter Memory Recall mode.
2 Rotate the Tuning control to select your desired

Memory channel.

• Additionally, you can press the microphone

[UP]/[DWN]

keys to select a channel, or you can enter a channel

number using the microphone keypad.

3 Turn the transceiver power OFF.
4 Press [MR] + Power ON.

• A confirmation message appears on the display.

5 Press the Tuning control to clear the Memory channel.

• To exit without clearing the channel, press

[ESC].

MEMORY CH-

NAMINg A MEMORY CHANNEL

You can name Memory channels using up to 8 characters.

When you recall a named Memory channel, its name

appears on the display. Names can be call signs,

repeater names, cities, people, etc.

1 Press [MR] to enter Memory Recall mode.
2 Rotate the Tuning control to select your desired

Memory channel.

3 Enter Menu mode and access Menu 200.

4 Enter your desired name for the channel.

Note: You can overwrite a Memory channel name by performing the

steps above. You can also clear a Memory channel name by clearing

the Memory channel.

MEMORY-TO-VFO TRANSFER

Transferring the contents of a Memory channel or the Call

channel to the VFO can be useful if you want to search

for other stations or a clear frequency, near the selected

Memory channel or Call channel frequency.
1 Press [MR] or [CALL] to enter Memory Recall mode or

select the Call channel.

2 Rotate the Tuning control to select your desired

channel. (This step is not necessary when selecting

the Call channel.)

3 Press [F], [M>V].

• The entire contents of the Memory channel or Call channel

are copied to the VFO, and VFO mode is selected after

the transfer is complete.

• When copying a transmit frequency from an odd-split

Memory or Call channel, you must first turn the Reverse

function ON before pressing

[F], [M>V].

CHANNEL DISPLAY FuNCTION

Use this function when you want to use only Memory

channels. When this function is switched ON, the

transceiver displays only a Memory channel number

instead of a frequency.
1 Turn the transceiver power OFF.
2 Press [LOW] + Power ON to turn the channel display

ON or OFF.

Note:
u

If no Memory channels have saved data in them, channel display

will not function.

u

When using Channel Display, you cannot reset the transceiver.

While in Channel Display mode, the transceiver keys

function as shown next page:

MEMORY CH-

Key Name

[KEY]

[F], [KEY]

[KEY] (1s)

While Transmitting [KEY] + Power ON

Power ON/OFF

Power ON/OFF

Power ON/OFF

Power ON/OFF

X

PM

–

–

–

–

–

TNC

–

DX PacketClusters

Monitor ON/OFF

–

–

–

CALL

Call mode

–

Call Scan

–

–

VFO

–

–

–

–

–

MR

MR mode

–

Memory Scan

–

–

KEY

–

–

–

–

–

F

Function mode

Exit Function mode

Key Lock

–

Reset

TONE

–

–

–

–

–

REV

Reverse ON/OFF

–

–

–

–

LOW/ MUTE

Change output

power

Mute

–

Change output

power

Change channel

display

PF1

Select the Weather

channel (K type)

–

–

–

–

PF2

Change control band

(default)

–

–

–

–

Tuning control

–

–

Group Scan

–

–

BAND SEL A

A band

–

Change Single/Dual

–

–

BAND SEL B

B band

–

Change Single/Dual

–

–
