Copyright 2002-2004 Triple S Customs
MAZDA MIATA 1990-2003
V
V
E
E
H
H
I
I
C
C
L
L
E
E
W
W
I
I
R
R
I
I
N
N
G
G
Copyright 2002-2004 Triple S Customs
2
WIRING INFORMATION 1990 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
WIRING INFORMATION 1991 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
WIRING INFORMATION 1992 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
Copyright 2002-2004 Triple S Customs
3
WIRING INFORMATION 1993 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
WIRING INFORMATION 1994 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
WIRING INFORMATION 1995 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
Copyright 2002-2004 Triple S Customs
4
WIRING INFORMATION 1996 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
WIRING INFORMATION 1997 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
WIRING INFORMATION 1998 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
STARTER WIRE
BLACK/BLUE
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
WHITE/LT,GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
RED/WHITE or WHITE
At Under Dash Light
TACHOMETER YELLOW/BLUE Ignition
Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/RED or GREEN/YELLOW
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
WHITE/RED
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
Copyright 2002-2004 Triple S Customs
5
WIRING INFORMATION 1999 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE/RED
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
12V IGNITION WIRE
RED/BLACK
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
GREEN/RED
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
LT.GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
WHITE/RED
Harness In Driver’s Kick Panel
TACHOMETER
BROWN or BROWN/YELLOW
Ignition Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/ORANGE
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
GREEN
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
WHITE/RED
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
WIRING INFORMATION 2000 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE/RED
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
12V IGNITION WIRE
RED/BLACK
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
GREEN/RED
Ignition Harness
POWER DOOR LOCK
Must add actuator in doors
POWER DOOR UNLOCK
Must add actuator in doors
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
LT.GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
WHITE/RED
Harness In Driver’s Kick Panel
TACHOMETER
BROWN or BROWN/YELLOW
Ignition Coil
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/ORANGE
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
WHITE/RED
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
Copyright 2002-2004 Triple S Customs
6
WIRING INFORMATION 2001 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE/RED
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK (Negative trigger
through a 1000-ohm resistor)
PURPLE
At Module Under Driver’s Side Dash
POWER DOOR UNLOCK (Negative trigger)
Same wire as lock
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
LT.GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
WHITE/RED
Harness In Driver’s Kick Panel
TRUNK RELEASE (-)
RED/WHITE
Module Behind Glove Box
TACHOMETER
GREEN/ORANGE
At Data Connector At Rear Left Of Engine Bay
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/ORANGE
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
WHITE/RED
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
This vehicle is equipped with an Immobilizer system. This must be bypassed when installing a remote start system.
WIRING INFORMATION 2002 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE/RED
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK (Negative trigger
through a 1000-ohm resistor)
PURPLE
At Module Under Driver’s Side Dash
POWER DOOR UNLOCK (Negative trigger)
Same wire as lock
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
LT.GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
WHITE/RED
Harness In Driver’s Kick Panel
TRUNK RELEASE (-)
RED/WHITE
Module Behind Glove Box
TACHOMETER
GREEN/ORANGE
At Data Connector At Rear Left Of Engine Bay
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/ORANGE
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
WHITE/RED
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
This vehicle is equipped with an Immobilizer system. This must be bypassed when installing a remote start system.
Copyright 2002-2004 Triple S Customs
7
WIRING INFORMATION 2003 Mazda Miata
WIRE
COLOR
LOCATION
12V CONSTANT WIRE
WHITE/RED
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
12V IGNITION WIRE
BLUE
Ignition Harness
SECOND 12V IGNITION WIRE
BLACK/RED
Ignition Harness
12V ACCESSORY WIRE
BLACK/WHITE
Ignition Harness
POWER DOOR LOCK (Negative trigger
through a 1000-ohm resistor)
PURPLE
At Module Under Driver’s Side Dash
POWER DOOR UNLOCK (Negative trigger)
Same wire as lock
PARKING LIGHTS (+)
RED/BLACK
Rear Of Dimmer Switch
PARKING LIGHTS (-)
LT.GREEN
Harness At Steering Column
DOOR TRIGGER/DOME LIGHT
SUPERVISION (-)
WHITE/RED
Harness In Driver’s Kick Panel
TRUNK RELEASE (-)
RED/WHITE
Module Behind Glove Box
TACHOMETER
GREEN/ORANGE
At Data Connector At Rear Left Of Engine Bay
BRAKE WIRE (+)
GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
GREEN/ORANGE
Harness At Steering Column
LEFT FRONT WINDOW UP
GREEN/RED
In Center Console
LEFT FRONT WINDOW DOWN
WHITE/RED
In Center Console
RIGHT FRONT WINDOW UP
RED/BLACK
In Center Console
RIGHT FRONT WINDOW DOWN
RED/GREEN
In Center Console
This vehicle is equipped with an Immobilizer system. This must be bypassed when installing a remote start system.
Wyszukiwarka
Podobne podstrony:
MAZDA MIATA 1990
MAZDA MIATA 1990
MAZDA PROTEGE 1990(1)
MAZDA PROTEGE 1995 2003
MAZDA MIATA 1996
MAZDA PICKUP 1990(1)
MAZDA MIATA 1999
Analiza samobójstw w materiale sekcyjnym Zakładu Medycyny Sądowej AMB w latach 1990 2003
MAZDA MPV 1990
MAZDA MIATA 1995
MAZDA MIATA 1991
MAZDA MIATA 1997
mazda 626 1990
INFINITI Q45 1990 2003
MAZDA PROTEGE 1990(1)
MAZDA PROTEGE 1995 2003
MAZDA MIATA 1992
mazda rx 8 se 2003 2010
więcej podobnych podstron
