NP R60FE0A SER SM EN 20080602190217734 01 Cover

background image

If there are the contents not included in this book, please refer to K-zone Service Manual

SENS R60 Plus

Feature

SERVICE

Manual

U93 Soxv

SUDKD
QW0U93 Soxv{{{{2{{{

1. Simple & Essential Note PC

-. Intel Core2 Duo/Celeron M

Processor

-. AMD RS600ME + AMD SB600

-. ATI M64S Graphics

2. High Performance & Security

-. 15.4" WXGA/WXGA+ Super Bright

Glare LCD/Non Glare LCD

-. AVS now, Bluetooth.

background image

- CONTENTS -

1. Precaution

1) General After-Sales Service Precaution............................................................. 1-1
2) Safety cautions............................................................................................ 1-2
3) Ground connection item................................................................................ 1-3
4) Static caution.................................................................................................1-3

2. Product Characteristic and Specification

1) Introduction...................................................................................................2-1
2) Specification..................................................................................................2-2
3) System Spec Comparison............................................................................... 2-7
4) Wireless LAN Specification.............................................................................. 2-9
5) Option List................................................................................................... 2-10
6) S/W List..................................................................................................... 2-13
7) Description of Main-Board............................................................................. 2-14

3. Disassembling and Reassembling

1) Main System..................................................................................................3-1
2) Top Ass'y......................................................................................................3-8
3) LCD Ass'y.................................................................................................... 3-8
4) Main Board................................................................................................. 3-12

4. Troubleshooting

1) General........................................................................................................ 4-1
2) Debugging Flow Chart................................................................................... 4-2
3) System Diagnosis........................................................................................

4-4

4) Use of diagnostic program................................................................................4-8
5) H/W Troubleshooting....................................................................................... 4-13
6) Device Settings Related Software Diagnosis........................................................ 4-21
7) Battery Use Time............................................................................................ 4-24
8) Other.............................................................................................................4-29

5. Exploded View

1) System Main Ass'y (List).................................................................................. 5-1
2) LCD Front Ass'y (List)..................................................................................... 5-3
3) LCD Back Ass'y...............................................................................................5-4
4) Ass'y CAP-TOP (List)....................................................................................... 5-5
5) Housing Top Ass'y (List).................................................................................. 5-6
6) Housing Bottom Ass'y (List)............................................................................ 5-7
7) ODD (List)......................................................................................................5-9

6. Material List

1) Material List....................................................................................................6-1

7. System Wire Diagram

1) Top/Bottom.....................................................................................................7-1
2) LCD...............................................................................................................7-2
3) System Layout ................................................................................................7-3

8. Block-Diagram and Schematic

1) Block-Diagram................................................................................................8-1
2) Schematic.......................................................................................................8-7

- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -

- This Document can not be used without Samsung's authorization -
