SERVICE PARTS LIST FOR
MITSUBISHI ELECTRIC
DRAIN LIFT UP MECHANISM

Series : PAC-KE07DM-E

INDEX

PAC-KE07DM-E

Jan. 2008

BWE07250

No.

Part No.

Part Name

Spec.

Dwg. No.

Price

Re

vision Histor

y

G : RoHS Apply Only
W : RoHS Apply by Running Change

PAC-KE07DM-E

EXTERNAL PARTS

*

Content of revision : Some of parts are changed.

PA

C-KE07DM-E

*

0 R6 00 68 G Pump

PLD

P7223X0

02 R6 00 54 G Float switch

BH68C952H02

03 R6 08 529 G Drain pan assy

KB00G857G0

04 R63 00 527 G Pump hose

W95395G0

05 R63 7G7 28 G Socket

W66457H0

06 R6 002 527 G Tube drain

P839027X0

07 R6 002 524 G Band

2

P694049X0

08 R6 00 525 G Drain hose

BC27R200K02

09 R63 Y0 05 G Ferrite clamp

P49042X0

109

105

104

101

108

107

106

107

103

102

BWE07250 (200803)
