WIRING INFORMATION: 1991 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

DK. BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/RED

Ignition Harness

SECOND ACCESSORY WIRE

BLACK

Ignition Harness

POWER DOOR LOCK (5-wire reverse
polarity)

ORANGE

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (5-wire reverse
polarity)

PINK

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

At Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



TACHOMETER WIRE

GRAY

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN or WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 1992 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

DK. BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/ORANGE

Ignition Harness

SECOND ACCESSORY WIRE

BLACK/WHITE

Ignition Harness

POWER DOOR LOCK (5-wire reverse
polarity)

ORANGE/PURPLE

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (5-wire reverse
polarity)

PINK/PURPLE

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

At Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



TACHOMETER WIRE

GRAY

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN or WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 1993 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

DK. BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/ORANGE

Ignition Harness

SECOND ACCESSORY WIRE

BLACK/WHITE

Ignition Harness

POWER DOOR LOCK (5-wire reverse
polarity)

ORANGE/PURPLE

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (5-wire reverse
polarity)

PINK/PURPLE

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

At Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



TACHOMETER WIRE

GRAY

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN or WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

3

WIRING INFORMATION: 1994 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/ORANGE

Ignition Harness

SECOND ACCESSORY WIRE

BLACK/WHITE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/BLACK

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

PINK/BLACK

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Harness In Driver’s Kick Pane

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



TACHOMETER WIRE

GRAY/BLACK

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 1995 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

SECOND IGNITION WIRE

BLACK/WHITE

Ignition Harness

ACCESSORY WIRE

BLACK/ORANGE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Harness In Driver’s Kick Pane

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



TACHOMETER WIRE

GRAY/BLACK

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 1996 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

SECOND IGNITION WIRE

BLACK/WHITE

Ignition Harness

ACCESSORY WIRE

BLACK/ORANGE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Harness In Driver’s Kick Pane

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



TACHOMETER WIRE

GRAY/BLACK

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

4

WIRING INFORMATION: 1997 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

SECOND IGNITION WIRE

BLACK/WHITE

Ignition Harness

ACCESSORY WIRE

BLACK/ORANGE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Harness In Driver’s Kick Pane

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



TACHOMETER WIRE

GRAY/BLACK

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 1998 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED or RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK or BLUE

Ignition Harness

SECOND IGNITION WIRE

ORANGE or BLACK/ORANGE

Ignition Harness

ACCESSORY WIRE

BROWN or BLACK/WHITE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness Right Of Steering Column

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness Right Of Steering Column

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



FACTORY ALARM DISARM (-)

BLACK/ORANGE

Harness Against Firewall Close To Driver’s
Kick Panel

TACHOMETER WIRE

GRAY

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 1999 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED or RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK or BLUE

Ignition Harness

SECOND IGNITION WIRE

ORANGE or BLACK/ORANGE

Ignition Harness

ACCESSORY WIRE

BROWN or BLACK/WHITE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness Right Of Steering Column

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness Right Of Steering Column

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



FACTORY ALARM DISARM (-)

BLACK/ORANGE

Harness Against Firewall Close To Driver’s
Kick Panel

TACHOMETER WIRE

GRAY

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

5

WIRING INFORMATION: 2000 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED or RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK or BLUE

Ignition Harness

SECOND IGNITION WIRE

ORANGE or BLACK/ORANGE

Ignition Harness

ACCESSORY WIRE

BROWN or BLACK/WHITE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness Right Of Steering Column

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness Right Of Steering Column

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



FACTORY ALARM DISARM (-)

BLACK/ORANGE

Harness Against Firewall Close To Driver’s
Kick Panel

TACHOMETER WIRE

GRAY

At Ignition Coil

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 2001 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED or RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

BLUE (Thinner)

Ignition Harness

SECOND IGNITION WIRE

YELLOW/RED

Ignition Harness

ACCESSORY WIRE

BLUE (Thicker)

Ignition Harness

SECOND ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



FACTORY ALARM ARM/LOCK (Negative
trigger through a 644 ohm resistor)

BLACK/ORANGE

Harness In Driver’s Kick Panel

FACTORY ALARM DISARM/UNLOCK
(Negative trigger through a 1565 ohm resistor

Same wire as arm



TACHOMETER WIRE

GRAY

At Powertrain Control Module By Wiper
Motor

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

6

WIRING INFORMATION: 2002 Dodge Ram Van

WIRE

     WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED or RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

BLUE (Thinner)

Ignition Harness

SECOND IGNITION WIRE

YELLOW/RED

Ignition Harness

ACCESSORY WIRE

BLUE (Thicker)

Ignition Harness

SECOND ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

ORANGE/PURPLE

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (+)

PINK/PURPLE

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BLACK/YELLOW

At Headlight Switch

DOOR TRIGGER (-)

YELLOW

Headlight Switch

DOME LIGHT SUPERVISION

USE DOOR TRIGGER



FACTORY ALARM ARM/LOCK (Negative
trigger through a 644 ohm resistor)

BLACK/ORANGE

Harness In Driver’s Kick Panel

FACTORY ALARM DISARM/UNLOCK
(Negative trigger through a 1565 ohm resistor

Same wire as arm



TACHOMETER WIRE

GRAY

At Powertrain Control Module By Wiper
Motor

BRAKE WIRE (+)

WHITE/TAN

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

LT.BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN/WHITE

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PURPLE/WHITE

Harness In Driver’s Kick From Driver Door
