f you listen closely, you can almost hear it. Around most of

us, systems, devices, and people are communicating at an un-

precedented rate. Wires and fibers are filled to bandwidth limit

and the air is saturated with infrared and radio-frequency trans-
missions. In most of the places we spend our

office,

factory, car, or store-communications have

so en-

trenched in the routine of daily life that they fade into the back-

ground. As the companies which provide us with information

and data carriers compete to offer more complete and more com-

plex services, the odds are overwhelmingly in favor of commu-
nications playing an increasing role in our professional and

personal lives.

of the technologies looming on the horizon is Integrated

Services Digital Network, or ISDN. To be sure,

has

looming on that horizon for nearly ten years now, but pieces arc
falling into place for its eventual availability in most offices and

homes. If roadways are appropriate analogies for data channels,
residential ISDN is rather like have an eight-lane expressway

running out of your garage. There will be sufficient bandwidth
for applications such as video conferencing to move out of

priced satellite centers and into the living room. (Whether resi-

dential customers will want video telephones and the like is a

totally separate and utterly unresolved issue.) Entertainment,

education, and centralized security are among the application

areasthatareunderexplorationfortheday whenbandwidthwill

not be the limiting factor in residential communications.

phones revolutionized the way individuals lead their private

lives: It is not a great stretch to imagine that the next ten to fifteen

years will seecommunication development that will

least

as much impact as the original telephone.

When you start looking at the implications of increasingly

capable residential communications, it’s hard to avoid the topic

of home automation. After competing with one another for small

niches for years, the manufacturers of home automation prod-
ucts learned a lesson from the small computer and

tainment industries: Market size and standards

related.

Customers are so repulsed by the notion of buying a proprietary
system which might be orphaned that they will choose to buy

nothing rather than take that risk. A good standard removes the

risk, and with it a high barrier to customer outlay.

standard has sufficient weight and support to throw home auto-

mation into a period of tremendous growth. According to a study

by Rose Associates, home automation

(of some sort) are

now in two percent of U.S. homes.They predict that the percent-

age will rise to 15% by 2000, and hit 50% in twenty years.

also estimate the current home automation market at nearly 1.5
billion dollars a year, you can see the potential for market growth

in sheer dollar terms. While I won‘t deny the importance of

contained stand-alone machine intelligence, the potential avail-

able to fully communicating dwellings begins to stagger the
imagination.

One of the important social ramifications of the

I’ve

been discussing is that they make where you are much less

important than how you’re connected. Obviously, there are

hundreds of jobs that require face-to-face human interaction, but

many industries have already found that workers can be as pro-
ductive (or more productive) in their own environment as they

are in the office. In areas such as Southern California, air quality

regulations are adding a governmental component to the trend

toward keeping as

many

people as possible away from the office.

Social trends having nothing to do with computers may also act

on the “urge to stay home” with a resulting reliance on commu-

nications channels. During the recent war, a number of compa-
nies turned to videoconferencing as a replacement for interna-

tional travel. When thecapabilityexists for
