CHEVROLET AVEO 2004-2005

V

V

E

E

H

H

I

I

C

C

L

L

E

E





W

W

I

I

R

R

I

I

N

N

G

G




























Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION: 2004 Chevrolet Aveo

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED/BLACK and ORANGE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

YELLOW or RED/BLACK

Ignition Harness

SECOND ACCESSORY WIRE

YELLOW

Ignition Harness

KEYSENSE WIRE (-)

LT.GREEN

Ignition Harness

POWER DOOR LOCK (-)

GRAY

At Module In Passenger Kick Panel

POWER DOOR UNLOCK (-)

LT.GREEN

At Module In Passenger Kick Panel

PARKING LIGHTS (+)

PURPLE (left) and BROWN/WHITE (right)

In Yellow Connector In Driver’s Kick Panel

DOOR TRIGGER (-)

WHITE or DK.GREEN/WHITE

In Black Connector In Driver’s Kick Panel

TRUNK TRIGGER (-)

ORANGE/BLACK

At Light In Trunk

FACTORY ALARM DISARM (-)

DARK BLUE

Harness In Driver’s Kick Panel From Driver
Door

TACHOMETER WIRE

WHITE or GRAY

Module At Front Of Driver Shock Tower

BRAKE WIRE (+)

BROWN

At Brake Switch

HORN TRIGGER (-)

BLACK or BLACK/WHITE

At Steering Column

LEFT FRONT WINDOW UP

WHITE

At Switch In Driver’s Door

LEFT FRONT WINDOW DOWN

DK.BLUE

At Switch In Driver’s Door

RIGHT FRONT WINDOW UP

BROWN

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

DK.GREEN

Harness In Driver’s Kick Panel From Driver
Door

LEFT REAR WINDOW UP

GRAY/DK.GREEN

Harness In Driver’s Kick Panel From Driver
Door

LEFT REAR WINDOW DOWN

DK.GREEN/RED

Harness In Driver’s Kick Panel From Driver
Door

RIGHT REAR WINDOW UP

PURPLE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT REAR WINDOW DOWN

LT.BLUE

Harness In Driver’s Kick Panel From Driver
Door

This vehicle is equipped with a key-based Immobilizer anti-theft system. This must be bypassed when installing a remote start system.


WIRING INFORMATION: 2005 Chevrolet Aveo

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED/BLACK and ORANGE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

YELLOW or RED/BLACK

Ignition Harness

SECOND ACCESSORY WIRE

YELLOW

Ignition Harness

KEYSENSE WIRE (-)

LT.GREEN

Ignition Harness

POWER DOOR LOCK (-)

GRAY

At Module In Passenger Kick Panel

POWER DOOR UNLOCK (-)

LT.GREEN

At Module In Passenger Kick Panel

PARKING LIGHTS (+)

PURPLE (left) and BROWN/WHITE (right)

In Yellow Connector In Driver’s Kick Panel

DOOR TRIGGER (-)

WHITE or DK.GREEN/WHITE

In Black Connector In Driver’s Kick Panel

TRUNK TRIGGER (-)

ORANGE/BLACK

At Light In Trunk

FACTORY ALARM DISARM (-)

DARK BLUE

Harness In Driver’s Kick Panel From Driver
Door

TACHOMETER WIRE

WHITE or GRAY

Module At Front Of Driver Shock Tower

BRAKE WIRE (+)

BROWN

At Brake Switch

HORN TRIGGER (-)

BLACK or BLACK/WHITE

At Steering Column

LEFT FRONT WINDOW UP

WHITE

At Switch In Driver’s Door

LEFT FRONT WINDOW DOWN

DK.BLUE

At Switch In Driver’s Door

RIGHT FRONT WINDOW UP

BROWN

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

DK.GREEN

Harness In Driver’s Kick Panel From Driver
Door

LEFT REAR WINDOW UP

GRAY/DK.GREEN

Harness In Driver’s Kick Panel From Driver
Door

LEFT REAR WINDOW DOWN

DK.GREEN/RED

Harness In Driver’s Kick Panel From Driver
Door

RIGHT REAR WINDOW UP

PURPLE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT REAR WINDOW DOWN

LT.BLUE

Harness In Driver’s Kick Panel From Driver
Door

This vehicle is equipped with a key-based Immobilizer anti-theft system. This must be bypassed when installing a remote start system.
