BWE0360Z PartsList PURY 200 250YMF Sep 2004

background image

INDEX

P U R Y - 2 0 0 Y M F

P U R Y - 2 5 0 Y M F

SERVICE PARTS LIST FOR
MITSUBISHI ELECTRIC
PACKAGED AIR-CONDITIONERS

Please change the old catalogs (issued Aug. 2003, No.BWE0360Z) to this new catalog.
Content of revision : Some parts are changed.

Series PURY

Sep. 2004

R E V I S E D

background image

1

18

19

2

5

22

14

12

23

13

16

11

5

7.8

20

21

21

11

3

4

9.10

1

17

6

12

22

14

15

PURY-200YMF
PURY-250YMF

EXTERNAL PARTS

background image

2

PURY-200YMF
PURY-250YMF

EXTERNAL PARTS

1

R61 375 689

Compressor cover U-Y ass'y

1

1

W614488G03

2

R61 907 499

Block board U ass'y

1

W814351G01

3

R61 Y01 629 Partition board ass'y 1

1

1

W620431G01

4

R61 Y02 629 Partition board ass'y 2

1

1

W856966G01

5

R61 849 668

Support frame

2

2

W374342G01

6

R61 Y03 659 Front panel

1

1

W618663G04

7

R61 Y29 480 Heat exchanger B

1

W861763G06

8

R61 Y30 480 Heat exchanger B

1

W861763G08

9

R61 Y23 480 Heat exchanger F

1

W861763G05

10

R61 Y24 480 Heat exchanger F

1

W861763G07

11

R61 849 669

Reinforcement SU

2

2

W374350G01

12

R61 562 611

Guard ass'y

2

2

W255022G01

13

R61 595 677

Panel B

1

1

W374352G02

14

R61 Y02 652 Panel FU ass'y

2

2

W623772G02

15

R61 Y03 652 Panel SR ass'y

1

1

W623771G02

16

R61 Y04 652 Panel SL

1

1

W258817G03

17

R61 Y05 652 Panel F ass'y

1

1

W623773G01

18

R61 Y01 118 Fan guard ass'y

1

1

W258791G01

19

R12 801 118

Bell mouth ass'y

3

4

W814320G02

20

R61 Y05 293 NF (HF4030C-MX2)

1

1

W638330G01

21

R61 Y01 015 Troidal ferrite cramp

2

2

P419042X01

22

R61 Y01 690 Guard fixing plate

2

2

W860979G01

23

R61 Y02 499 Block board

1

1

W621476G01

Dwg. No.

Price

No.

Part No.

Part Name

Spec.

-200YMF

-250YMF

background image

3

5

14

25.30

1.9

22

3.4

25.30

24

2

26

33

25.30

25.30

28

17

29

25.30

14

25.30

29

27

11

4.31

32

20

19

35

18

17

12

13.16

11

7

23

18

21

15

3.4

9

34

8

14

1.9

6

PURY-200YMF
PURY-250YMF

FUNCTIONAL PARTS

background image

4

FUNCTIONAL PARTS

1

R61 Y03 237 Liquid level detecting heater CH2,3

1

1

P493643X02

2

R61 Y01 403 Four way valve

VH60100

1

1

P633077X01

3

R61 435 232

Solenoid valve

NEV-202DXF

2

2

P631807X02

4

R61 Y04 243 Solenoid valve coil

SV1,4,5

3

3

P631205X01

5

R61 375 401

Linear expansion valve

EDM-402,SLEV

1

1

P632290X01

6

R61 Y06 484 Accumulator ass'y

Equipped with socket.

1

1

W260329G02

7

R61 Y01 425 Capillary tube processing 1.0DX3.0DX1000

1

1

W859678G01

8

R61 971 425

Capillary tube processing 1.0DX3.0DX200 1

1

W846301G01

9

R61 155 454

Strainer

3

3

P643209X01

10

R61 375 454

Strainer

1

1

W817243H06

11

R61 436 418

Check valve

EGV-S55A

3

3

P639808X01

12

R61 Y01 487 Oil separator

1

1

W260347G01

13

R61 Y08 262 Belt heater

240V45W,CH1

1

1

P493642X01

14

R61 670 202

Thermistor

NTH3A14, TH2~4,6 4

4

P425496X01

15

R61 375 200

Thermistor (Discharge)

Wire length 1700, TH1 1

1

P425438X01

16

R69 926 478

Scroll compressor

HHV92FA1-Y

1

1

RF15144G03

17

R61 801 454

Strainer

2

2

W834017G01

18

R61 800 413

Charging plug

2

2

A50U666H04

19

R61 411 410

Ball valve

1frange

1

1

S636001H02

20

R61 701 410

Ball valve

3/4

1

1

S636001H05

21

R61 Y02 288 Pressure sensor

YSKBA30L030,63HS

1

1

P419099X01

22

R61 376 454

Strainer

1

1

P643206X01

23

R61 Y06 208 Pressure switch

ACB-1TB10W,63H 1

1

P426258X02

24

R61 Y06 242 Four way valve coil

LB63030, 21S4

1

1

P633097X01

25

R61 Y02 243 Solenoid valve coil

SV6A~E, SV7

6

6

P631172X02

26

R61 800 202

Thermistor

NTH3A23-3, TH5 1

1

P425494X01

27

R61 799 418

Check valve

2

2

P639104X01

28

R61 703 418

Check valve

8-16

1

1

S639001H04

29

R61 631 418

Check valve

8-12.7

3

3

S639001H03

30

R61 799 232

Solenoid valve

SB46PFA-06

6

6

P631158X04

31

R61 800 232

Solenoid valve

NEV-603DXF

1

1

P631805X01

32

R61 A42 454 Strainer

3

3

P643210X01

33

R61 799 454

Strainer

1

1

W834000H01

34

R61 800 454

Strainer

1

1

W834000H02

35

R61 799 413

Charging plug

1

1

W494431H03

Dwg. No.

Price

No.

Part No.

Part Name

Spec.

-200YMF

-250YMF

PURY-200YMF
PURY-250YMF

*

*

: Not illustrated.

background image

5

-

+

R 2

-

+

R 3

C 3

C 2

T 1

52C

R 1

R 4

M F 1 B

M F 1 A

W

L2

CN06

TB1

CN04

CN05

CAUTION

TB7

TB3

PURY-200YMF

PURY-250YMF

DCL

V

U

A1

A2

A3

N

F

-

+

R 2

-

+

R 3

C 3

C 2

T 1

52C

R 1

R 4

M F 1 B

M F 1 A

W

L2

A1

A2

A3

N

F

CN06

TB1

CN04

CN05

CAUTION

TB7

TB3

DCL

V

U

7

9

16

4

14

3

15

6

10

18

10

8

13

15

12

17

2

1

7

9

16

4

14

3

15

5

10

18

10

8

13

15

11

17

2

1

*

1

*

1: It may be needed to process the hole for attaching parts

into the metal plate of Control box.

*

1

*

1: It may be needed to process the hole for attaching parts

into the metal plate of Control box.

PURY-200YMF
PURY-250YMF

CONTROL BOX PARTS

This page was revised in September,2004.

background image

6

PURY-200YMF
PURY-250YMF

CONTROL BOX PARTS

1

R61 Y12 281 Controller board

1

1

P718324X01

2

R61 Y04 282 B/A board

1

1

P718326X01

3

R61 Y11 320 Diode

1

1

W876941G05

4

R61 Y13 320 Transistor

3

3

W848413G08

5

R61 Y04 252 Condenser

400WV 2200µF

2

P412167X01

6

R61 Y02 252 Condenser

400WV 3300µF

2

P412168X01

7

R61 Y04 259 Reactor

1.92mH

1

1

P715381X01

8

R61 Y01 225 Magnet contactor

1

1

P427135X01

9

R61 Y10 260 Transformer

240V/210V

1

1

P715274X01

10

R61 Y05 234 Resistor

40W 5kΩ

2

2

P411133X01

11

R61 Y04 234 Resistor

10W 33kΩ

2

P411124X01

12

R61 Y02 234 Resistor

10W 33kΩ

2

P411126X01

13

R61 Y03 234 Resistor

20W 180kΩ

1

1

P411125X01

14

R61 670 261

DC-CT

1

1

P419031X01

15

R61 Y02 114 Fan

2

2

P712181X01

16

R61 375 200

Thermistor

1

1

P425438X01

17

R61 Y01 244 Choke coil

1A 30mH

1

1

P419098X01

18

R61 Y03 215 Relay

220/240VAC

1

1

P421246X01

Dwg. No.

Price

No.

Part No.

Part Name

Spec.

-200YMF

-250YMF

This page was revised in September,2004.

background image

7

1

R61 Y01 122 Fan set screw

3

4

P517000X01

2

R11 942 942

Propeller fan

400D

3

4

W122507G02

3

R61 Y61 220 Motor

ME-0804B

1

1

P714297X01

4

R61 Y62 220 Motor

ME-0554B

1

2

P714299X01

5

R61 Y63 220 Motor

ME-0504B

1

P714300X02

6

R61 Y64 220 Motor

ME-0654B

1

P714298X01

7

R61 849 130

Motor support

2

2

W240972G01

8

R61 562 130

Support leg

2

2

W374343H01

9

R61 799 574

O ring

4D,P15

3

4

S648001H15

10

R61 352 135

Polish washer

3

4

S562131H11

ME-0504B

ME-0554B

ME-0554B

ME-0654B

ME-0554B

ME-0804B

ME-0804B

PURY-200YMF

PURY-250YMF

(FRONT)

(FRONT)

PURY-200YMF
PURY-250YMF

BLOWER PARTS

Dwg. No.

Price

No.

Part No.

Part Name

Spec.

-200YMF

-250YMF

background image

MITSUBISHI ELECTRIC CORPORATION

HEAD OFFICE: MITSUBISHI DENKI BLDG. , 2-2-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN

BWE0360Z(20040930)
