FORD ASPIRE 1994 1997

background image

Copyright 2002-2004 Triple S Customs

F

F

O

O

R

R

D

D

A

A

S

S

P

P

I

I

R

R

E

E

1

1

9

9

9

9

4

4

-

-

1

1

9

9

9

9

7

7

V

V

E

E

H

H

I

I

C

C

L

L

E

E

W

W

I

I

R

R

I

I

N

N

G

G










background image

Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION: 1994 Ford Aspire

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BLACK/WHITE

Ignition Harness

STARTER WIRE

WHITE

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/RED

Ignition Harness

SECOND ACCESSORY WIRE

GREEN

Ignition Harness

PARKING LIGHTS (+)

RED/BLACK

Harness In Driver’s Kick Panel

PARKING LIGHTS (-)

GREEN

Harness At Steering Column

HEADLIGHTS (-)

RED

Harness At Steering Column

DOOR TRIGGER (-)

RED/WHITE

Harness In Driver’s Kick Panel

TRUNK TRIGGER (-)

RED

At Light In Trunk

TACHOMETER WIRE

WHITE

At Distributor

BRAKE WIRE (+)

GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

RED/BLACK

Harness At Steering Column


WIRING INFORMATION: 1995 Ford Aspire

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BLACK/WHITE

Ignition Harness

STARTER WIRE

WHITE

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/RED

Ignition Harness

SECOND ACCESSORY WIRE

GREEN

Ignition Harness

PARKING LIGHTS (+)

RED/BLACK

Harness In Driver’s Kick Panel

PARKING LIGHTS (-)

GREEN

Harness At Steering Column

HEADLIGHTS (-)

RED

Harness At Steering Column

DOOR TRIGGER (-)

RED/WHITE

Harness In Driver’s Kick Panel

TRUNK TRIGGER (-)

RED

At Light In Trunk

TACHOMETER WIRE

WHITE

At Distributor

BRAKE WIRE (+)

GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

RED/BLACK

Harness At Steering Column


WIRING INFORMATION: 1996 Ford Aspire

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BLACK/WHITE

Ignition Harness

STARTER WIRE

WHITE

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/RED

Ignition Harness

SECOND ACCESSORY WIRE

GREEN

Ignition Harness

PARKING LIGHTS (+)

RED/BLACK

Harness In Driver’s Kick Panel

PARKING LIGHTS (-)

GREEN

Harness At Steering Column

HEADLIGHTS (-)

RED

Harness At Steering Column

DOOR TRIGGER (-)

RED/WHITE

Harness In Driver’s Kick Panel

TRUNK TRIGGER (-)

RED

At Light In Trunk

TACHOMETER WIRE

WHITE

At Distributor

BRAKE WIRE (+)

GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

RED/BLACK

Harness At Steering Column


WIRING INFORMATION: 1997 Ford Aspire

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BLACK/WHITE

Ignition Harness

STARTER WIRE

WHITE

Ignition Harness

IGNITION WIRE

BLUE

Ignition Harness

ACCESSORY WIRE

BLACK/RED

Ignition Harness

SECOND ACCESSORY WIRE

GREEN

Ignition Harness

PARKING LIGHTS (+)

RED/BLACK

Harness In Driver’s Kick Panel

PARKING LIGHTS (-)

GREEN

Harness At Steering Column

HEADLIGHTS (-)

RED

Harness At Steering Column

DOOR TRIGGER (-)

RED/WHITE

Harness In Driver’s Kick Panel

TRUNK TRIGGER (-)

RED

At Light In Trunk

TACHOMETER WIRE

WHITE

At Distributor

BRAKE WIRE (+)

GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

RED/BLACK

Harness At Steering Column
