©2002 Fairchild Semiconductor Corporation

Rev. A2, July 2002

KSP

9

4

PNP Epitaxial Silicon Transistor

Absolute Maximum Ratings

T

a

=25

°

C unless otherwise noted

Electrical Characteristics

T

a

=25

°

C unless otherwise noted

Symbol

Parameter

Value

Units

V

CBO

Collector-Base Voltage

-400

V

V

CEO

Collector-Emitter Voltage

-400

V

V

EBO

Emitter-Base Voltage

-6

V

I

C

Collector Current

-300

mA

P

C

Collector Power Dissipation

625

mW

T

J

Junction Temperature

150

°

C

T

STG

Storage Temperature

-55~150

°

C

Symbol

Parameter

Test Condition

Min.

Typ.

Max.

Units

BV

CBO

Collector-Base Breakdown Voltage

I

C

= -100

µ

A, I

E

=0

-400

V

BV

CES

Collector-Emitter Breakdown Voltage

I

C

= -100

µ

A, V

BE

=0

-400

V

BV

EBO

Emitter-Base Breakdown Voltage

I

E

= -10

µ

A, I

C

=0

-6

V

I

CBO

Collector Cut-off Current

V

CB

= -300V, V

E

=0

-100

nA

I

CES

Collector Cut-off Current

V

CE

= -400V, V

BE

=0V

-1

µ

A

I

EBO

Emitter Cut-off Current

V

BE

= -4V, I

C

=0

-100

nA

h

FE1

h

FE2

h

FE3

h

FE4

DC Current Gain

V

CE

= -10V, I

C

= -1mA

V

CE

= -10V, I

C

= -10mA

V

CE

= -10V, I

C

= -50mA

V

CE

= -10V, I

C

= -100mA

40
50
45
40

300

V

CE

(sat)

1

V

CE

(sat)

2

Collector-Emitter Saturation Voltage

I

C

= -10mA, I

B

= -1mA

I

C

= -50mA, I

B

= -5mA

-500
-750

mV
mV

V

BE

(sat)

Base-Emitter Saturation Voltage

I

C

= -10mA, I

B

= -1mA

-750

mV

C

ob

Output Capacitance

V

CB

= -20V, I

E

=0, f=1MHz

7

pF

KSP94

High Voltage Transistor

• High Collector-Emitter Voltage: V

CEO

= -400V

• Low Collector-Emitter Saturation Voltage
• Complement to KSP44

1. Emitter 2. Base 3. Collector

TO-92

1

©2002 Fairchild Semiconductor Corporation

KSP

9

4

Rev. A2, July 2002

Typical Characteristics

Figure 1. DC current Gain

Figure 2. Base-Emitter Saturation Voltage

Figure 3. Collector-Emitter Saturation Voltage

Figure 4. Collector Output Capacitance

-1

-10

-100

-1000

1

10

100

1000

V

CE

= -10V

h

FE

, DC

CURRENT

G

A

IN

I

C

[mA], COLLECTOR CURRENT

-1

-10

-100

-1000

-0.01

-0.1

-1

-10

I

C

= 10 I

B

V

BE

(s

a

t)

, SATURAT

IO

N

V

O

L

T

AG

E

I

C

[mA], COLLECTOR CURRENT

-1

-10

-100

-1000

-0.01

-0.1

-1

-10

I

C

= 10 I

B

V

CE

(s

a

t)

, SATURAT

IO

N

V

O

L

T

AG

E

I

C

[mA], COLLECTOR CURRENT

-0.1

-1

-10

-100

1

10

100

I

E

= 0

f = 1MHz

C

ob

[p

F

], C

A

P

A

C

IT

A

NCE

V

CB

[V], COLLECTOR-BASE VOLTAGE

0.46

±

0.10

1.27TYP

(R2.29)

3.86MAX

[1.27

±

0.20

]

1.27TYP

[1.27

±

0.20

]

3.60

±

0.20

14.47

±

0.40

1.02

±

0.10

(0.25)

4.58

±

0.20

4.58

+0.25
–0.15

0.38

+0.10
–0.05

0.38

+0.10

–0.05

TO-92

Package Dimensions

KSP

9

4

©2002 Fairchild Semiconductor Corporation

Dimensions in Millimeters

Rev. A2, July 2002
