BC807
PNP general purpose transistor

book, halfpage

M3D088

1999 Apr 08

2

Philips Semiconductors

Product specification

PNP general purpose transistor

BC807

FEATURES

•

High current (max. 500 mA)

•

Low voltage (max. 45 V).

APPLICATIONS

•

General purpose switching and amplification.

DESCRIPTION

PNP transistor in a SOT23 plastic package.
NPN complements: BC817.

PINNING

PIN

DESCRIPTION

1

base

2

emitter

3

collector

Fig.1 Simplified outline (SOT23) and symbol.

handbook, halfpage

2

1

3

MAM256

Top view

2

3

1

MARKING

Note

1.

∗

= p: Made in Hong Kong.

∗

= t: Made in Malaysia.

TYPE NUMBER

MARKING CODE

(1)

BC807

5D

∗

BC807-16

5A

∗

BC807-25

5B

∗

BC807-40

5C

∗

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

Note

1. Transistor mounted on an FR4 printed-circuit board.

SYMBOL

PARAMETER

CONDITIONS

MIN.

MAX.

UNIT

V

CBO

collector-base voltage

open emitter

−

−

50

V

V

CEO

collector-emitter voltage

open base; I

C

=

−

10 mA

−

−

45

V

V

EBO

emitter-base voltage

open collector

−

−

5

V

I

C

collector current (DC)

−

−

500

mA

I

CM

peak collector current

−

−

1

A

I

BM

peak base current

−

−

200

mA

P

tot

total power dissipation

T

amb

≤

25

°

C; note 1

−

250

mW

T

stg

storage temperature

−

65

+150

°

C

T

j

junction temperature

−

150

°

C

T

amb

operating ambient temperature

−

65

+150

°

C

1999 Apr 08

3

Philips Semiconductors

Product specification

PNP general purpose transistor

BC807

THERMAL CHARACTERISTICS

Note

1. Transistor mounted on an FR4 printed-circuit board.

CHARACTERISTICS

T

j

= 25

°

C unless otherwise specified.

Notes

1. Pulse test: t

p

≤

300

µ

s;

δ ≤

0.02.

2. V

BE

decreases by about

−

2 mV/K with increasing temperature.

SYMBOL

PARAMETER

CONDITIONS

VALUE

UNIT

R

th j-a

thermal resistance from junction to ambient

note 1

500

K/W

SYMBOL

PARAMETER

CONDITIONS

MIN.

TYP.

MAX.

UNIT

I

CBO

collector cut-off current

I

E

= 0; V

CB

=

−

20 V

−

−

−

100

nA

I

E

= 0; V

CB

=

−

20 V; T

j

= 150

°

C

−

−

−

5

µ

A

I

EBO

emitter cut-off current

I

C

= 0; V

EB

=

−

5 V

−

−

−

100

nA

h

FE

DC current gain

I

C

=

−

100 mA; V

CE

=

−

1 V; note 1

see Figs 2, 3 and 4

BC807

100

−

600

BC807-16

100

−

250

BC807-25

160

−

400

BC807-40

250

−

600

h

FE

DC current gain

I

C

=

−

500 mA; V

CE

=

−

1 V; note 1

40

−

−

V

CEsat

collector-emitter saturation voltage I

C

=

−

500 mA; I

B

=

−

50 mA; note 1

−

−

−

700

mV

V

BE

base-emitter voltage

I

C

=

−

500 mA; V

CE

=

−

1 V;

notes 1 and 2

−

−

−

1.2

V

C

c

collector capacitance

I

E

= i

e

= 0; V

CB

=

−

10 V; f = 1 MHz

−

9

−

pF

f

T

transition frequency

I

C

=

−

10 mA; V

CE

=

−

5 V; f = 100 MHz

80

−

−

MHz

1999 Apr 08

4

Philips Semiconductors

Product specification

PNP general purpose transistor

BC807

Fig.2 DC current gain; typical values.

handbook, full pagewidth

0

250

50

100

150

200

MBH717

−

10

−

1

−

1

hFE

−

10

IC (mA)

−

10

2

−

10

3

VCE =

−

1 V

BC807-16.

Fig.3 DC current gain; typical values.

handbook, full pagewidth

0

500

100

200

300

400

MBH718

−

10

−

1

−

1

hFE

−

10

IC (mA)

−

10

2

−

10

3

VCE =

−

1 V

BC807-25.

1999 Apr 08

5

Philips Semiconductors

Product specification

PNP general purpose transistor

BC807

Fig.4 DC current gain; typical values.

handbook, full pagewidth

0

500

100

200

300

400

MBH719

−

10

−

1

−

1

hFE

−

10

IC (mA)

−

10

2

−

10

3

VCE =

−

1 V

BC807-40.

1999 Apr 08

6

Philips Semiconductors

Product specification

PNP general purpose transistor

BC807

PACKAGE OUTLINE

UNIT

A

1

max.

b

p

c

D

E

e

1

H

E

L

p

Q

w

v

REFERENCES

OUTLINE

VERSION

EUROPEAN

PROJECTION

ISSUE DATE

97-02-28

IEC

JEDEC

EIAJ

mm

0.1

0.48
0.38

0.15
0.09

3.0
2.8

1.4
1.2

0.95

e

1.9

2.5
2.1

0.55
0.45

0.1

0.2

DIMENSIONS (mm are the original dimensions)

0.45
0.15

SOT23

bp

D

e1

e

A

A1

Lp

Q

detail X

HE

E

w

M

v

M

A

B

A

B

0

1

2 mm

scale

A

1.1
0.9

c

X

1

2

3

Plastic surface mounted package; 3 leads

SOT23

1999 Apr 08

7

Philips Semiconductors

Product specification

PNP general purpose transistor

BC807
