Copyright 2002-2004 Triple S Customs



CHEVROLET SSR 2004-2005

V

V

E

E

H

H

I

I

C

C

L

L

E

E





W

W

I

I

R

R

I

I

N

N

G

G




























Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION: 2004 Chevrolet SSR

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

SECOND ACCESSORY WIRE

BROWN

Ignition Harness

KEYSENSE WIRE (-)

LT.GREEN

Ignition Harness

POWER DOOR LOCK (-)

LT.BLUE

Blue Connector At BCM Behind Rear Center
Console

POWER DOOR UNLOCK (-)

WHITE

Blue Connector At BCM Behind Rear Center
Console

PARKING LIGHTS (+)

DO NOT USE

PARKING LIGHTS (-)

GRAY/BLACK

Brown Connector At BCM Behind Rear Center
Console

DRIVER DOOR TRIGGER (-)

GRAY/BLACK

Blue Connector At BCM Behind Rear Center
Console

PASSENGER DOOR TRIGGER (-)

BLACK/WHITE

Blue Connector At BCM Behind Rear Center
Console

DOMELIGHT SUPERVISION (+)

GRAY/BLACK

Black Connector At BCM Behind Rear Center
Console

FACTORY ALARM DISARM (-)

LT.GREEN

Harness In Driver’s Kick Panel From Door

TACHOMETER WIRE

WHITE

At PCM On Driver Side Of Engine Bay

BRAKE WIRE (+)

WHITE

Harness In Driver’s Kick Panel

HORN TRIGGER (-)

BLACK/YELLOW or BLACK

Gray Connector At BCM Behind Rear Center
Console

LEFT FRONT WINDOW UP
LEFT FRONT WINDOW DOWN
RIGHT FRONT WINDOW UP
RIGHT FRONT WINDOW DOWN

Not recommended

This vehicle is equipped with the Passlock II Immobilizer anti-theft system. This must be bypassed when installing a remote start system.


Copyright 2002-2004 Triple S Customs

3

WIRING INFORMATION: 2005 Chevrolet SSR

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

SECOND ACCESSORY WIRE

BROWN

Ignition Harness

KEYSENSE WIRE (-)

LT.GREEN

Ignition Harness

POWER DOOR LOCK (-)

LT.BLUE

Blue Connector At BCM Behind Rear Center
Console

POWER DOOR UNLOCK (-)

WHITE

Blue Connector At BCM Behind Rear Center
Console

PARKING LIGHTS (+)

DO NOT USE

PARKING LIGHTS (-)

GRAY/BLACK

Brown Connector At BCM Behind Rear Center
Console

DRIVER DOOR TRIGGER (-)

GRAY/BLACK

Blue Connector At BCM Behind Rear Center
Console

PASSENGER DOOR TRIGGER (-)

BLACK/WHITE

Blue Connector At BCM Behind Rear Center
Console

DOMELIGHT SUPERVISION (+)

GRAY/BLACK

Black Connector At BCM Behind Rear Center
Console

FACTORY ALARM DISARM (-)

LT.GREEN

Harness In Driver’s Kick Panel From Door

TACHOMETER WIRE

WHITE

At PCM On Driver Side Of Engine Bay

BRAKE WIRE (+)

WHITE

Harness In Driver’s Kick Panel

HORN TRIGGER (-)

BLACK/YELLOW or BLACK

Gray Connector At BCM Behind Rear Center
Console

LEFT FRONT WINDOW UP
LEFT FRONT WINDOW DOWN
RIGHT FRONT WINDOW UP
RIGHT FRONT WINDOW DOWN

Not recommended

This vehicle is equipped with the Passlock II Immobilizer anti-theft system. This must be bypassed when installing a remote start system.
