New minor data package version 6 01 (MCU SW 4 03 18)

background image

CONFIDENTIAL

1 (2)

x

Level 1

x

Level 2

x

Level 3

x

Level 4

Ref.

RM-1 SB-031

Copyright © Nokia Corporation 2005

Customer and Market Operations

Service Bulletin No. SB-031/18.04.05

EMEA Customer Care


RM-1




NEW MINOR DATA PACKAGE VERSION 6.01 (MCU SW 4.03.18)


New minor data package version 6.01 (MCU SW 4.03.18) has been released
for RM-1.

Before installing minor data package, please install Phoenix Service
Software version 2005.04.6.84 or later.

Do not remove old RM-1 major data package version 5.0 before installing
major data package 6.0 and minor data package 6.01.

Software downgrade is not allowed, due to BB5 security. In case older
software is flashed, the phone does not boot up. USB flashing doesn’t
work if phone cannot boot up. This can be fixed by flashing newer
software or the same software that was previously used in the phone.
This can be done only in level 3 service using phone specific adapter
and prommer.

Minor data package v6.01 includes following SW components:

-

MCU SW file 4.03.18 + variant images

-

Language package files (PPM’s) for MCU SW:

0521009 3 UK
0521051 Orange FR

-

Product specific ini-files

-

Default SW setting files (product profiles, user profiles, WAP bookmarks,
etc)

-

Label printing files

-

User interface configuration file for Product Profile tool

-

Product specific files for Faultlog reporting


Changes made from major data package 6.0 to minor data package 6.01:

-

Improvements to variant files

Note:

-

Manual File Selection should be un-checked (parameters menu)
before press Flash button. Phoenix can automatically select proper
Image File and PPM File according to product code.

background image

CONFIDENTIAL

2 (2)

x

Level 1

x

Level 2

x

Level 3

x

Level 4

Ref.

RM-1 SB-031

Copyright © Nokia Corporation 2005

Needed equipment for software update:

-

Phoenix Service Software version 2005.04.6.84 or later

-

Data packages v5.0 & 6.0 and minor data package 6.01

-

PKD-1 Dongle & Activated Flash Prommer FPS-10 or
DKU-2 USB Cable

-

Product specific service tools
