Oak Brings a Fresh Sound to These 12" & 13" Snare Drums.

Professional Quality at an Attractive Price.

1.6mm Triple flange steel with 8 holes

1.6mm Triple flange steel with 6 holes

2.7mm

Remo Ambassador Coated

Release side : B type Butt side : B type

Size

Hoop

Separate Lugs

Lugs

Shell

Snare Bed

Short / Hi-carbon steel / 20 strands

Short / Hi-carbon steel / 16 strands

Snare

Head

Batter

Remo Ambassador Snare

Bottom

Strainer

All Oak 7-ply

All Oak 7-ply (w/ Groove Wedge*)

13"x6 1/2"

12"x6"

NSD1365M

NSD1260MBGW

* The Groove Wedge is supplied with the NSD1260MBGW and cannot be sold separately.

NSD1260MBGW

Size : 12 "x6"

NSD1365M

Size : 13 "x6 1/2"

•The 7-ply all oak shells produce a crisp attack with a full-bod-

ied sound that can cut through and be heard.

•See through black mirror finish delivers a stunning exterior.
•The 12" model comes equipped with a black Groove Wedge

specially designed for use with the Musashi. The Wedge is
great for getting that fat wood hoop sound when using a
cross stick technique.

•A deeper than normal 2.7mm snare bed is less sensitive to

vibration due to influence from other drums.

Oak Brings a Fresh Sound to These 12" & 13" Snare Drums.

Professional Quality at an Attractive Price.

Release Side

B type

Butt Side

B type

Air-Seal

System

Ambassador

Coated

REMO

(Top)

Ambassador

Snare

REMO

(Bottom)

Hi-carbon

Steel Snare

(13")

Oak

7-ply

B type

(BUTT)

Snare Bed

Depth

Short / 20

Hi-carbon

Steel Snare

(12")

B

Lug Nut

Triple flange

(Steel / 1.6mm)

B type

(RELEASE)

B

Short / 16

Separate

Lug

Groove

Wedge

(12")

The black Groove Wedge is specially
designed for use with the 12" Musashi
Snare Drum.

Both release side and butt side strain-
ers are designed with two smaller feet
for attachment to the drum shell. Their
smaller footprint provides minimum
strainer to shell contact, delivering a
more natural shell sound.

The 12" snare drum uses a unique snare
design where the 16 snare strands are
separated into two groups with a gap
between the two.

This document is printed on chlorine-free (ECF) paper with soy ink.

LDR0228

*Some models may not be available in some countries.
*Colors shown in this catalog may not be represented exactly

as the original colors due to printing processes involved.

*Specifications are subject to change without notice.

Printed in Japan

02615

NSD087

Size : 14 "x7"

Matte Sedona

Red Oak

NSD085

Size : 14 "x5 1/2"

Blue Ridge Blue

Oak

New H type

B type

Air-Seal

System

Ambassador

Coated

REMO

(Top)

Ambassador

Snare

REMO

(Bottom)

Hi-carbon

Steel Snare

(5 1/2")

Oak

6-ply

B type

(BUTT)

Snare Bed

Depth

Short / 20

Hi-carbon

Steel Snare

(7")

Short / 25

B

Small

Lug

New H type

(RELEASE)

DynaHoop

(Steel / 2.3mm)

H

New

Lug Nut

Bryce Canyon

Brown Oak

Matte Ozark

Black Oak

*Please understand that the woods used are natural products there-
fore grain and color, such as light and dark areas, will differ between
drums.

BLO : Blue Ridge Blue Oak

BRO : Bryce Canyon Brown Oak

AMO : York Honey Amber Oak

MBN : Matte Badlands Brown Oak

MBK : Matte Ozark Black Oak

MNO : Matte Natural Oak

COLOR FINISHES

MRO : Matte Sedona Red Oak

[Glossy Finishes]

[Matte Finishes]

Adjustable Snare Wires

The snares under the batter head are attached to an adjust-

ment knob to regulate snare pressure against the head.

Against the bottom head is a set of hi-carbon steel snares.

Both snares can be used simultaneously, separately, or

switched off as you like.

DynaHoop (2.3mm triple flange steel) with 10 holes

Short / Hi-carbon steel / 20 strands

Short / Hi-carbon steel / 25 strands

Remo Ambassador Coated

Release side : New H type Butt side : B type

Size

Hoop

New Small Lugs

Lugs

Adjustable Snare Wires

Batter Snare

Shell

Bottom Snare

Head

Batter

Remo Ambassador Snare

Bottom

Strainer

All Oak 6-ply

14"x5 1/2"

14"x7"

NSD085

NSD087

All Oak

6-ply

45°

RELEASE

BUTT

Lug Nut

Lug Nut
Holding Plate

Combination Six-sided/
Philips (+) bolt head

Nylon Ring

O Ring

New Small Lugs

These newly designed, small round shaped lugs

are easily attached to the shell with a single bolt.

They also provide precise and secure tuning.

Strainers

Both strainers feature small

footprints to provided minimum strainer to

shell contact as well as easy operation.

This beautifully finished snare drum utilizes a 6-ply, all oak shell to

produce a tight, natural tone. Adjustable Snare Wires under the

batter head can be adjusted to meet your particular taste.

New Small Lugs

These newly designed, small round shaped lugs

are easily attached to the shell with a single bolt.

They also provide precise and secure tuning.
