01 077 4193

Name and formula


Reference code: 01-077-4193


Compound name: Barium Titanium Oxide

Common name: Barium titanate


Empirical formula: BaO3Ti

Chemical formula: Ba ( TiO3 )



Crystallographic parameters


Crystal system: Tetragonal

Space group: P4mm

Space group number: 99


a (A): 3,9972

b (A): 3,9972

c (A): 4,0410

Alpha (°): 90,0000

Beta (°): 90,0000

Gamma (°): 90,0000


Volume of cell (10^6 pm^3): 64,57

Z: 1,00


RIR: 7,77



Status, subfiles and quality


Status: Alternate Pattern

Subfiles: Ceramic

Common Phase

ICSD Pattern

Inorganic

Quality: Blank (B)


Comments


ANX: ABX3

Creation Date: 2009-11-13

Modification Date: 2011-01-19

ANX: ABX3

Analysis: Ba1 O3 Ti1

Formula from original source: Ba (Ti O3)

ICSD Collection Code: 245944 FIZ245944

Calculated Pattern Original Remarks: Given R-value is Rw. Results of real space PDF refinements over 20A. Nanocrystallites scale about 26nm. See CCodes 245945, 245946 for 45nm resp. 70nm scales

Significant Warning: 15%<R factor (for powder)

Wyckoff Sequence: c b2 a (P4MM)

Unit Cell Data Source: Powder Diffraction.


References


Primary reference: Calculated from ICSD using POWD-12++

Structure: Smith, M.B., Page, K., Siegrist, T., Redmond, P.L., Walter, E.C., Seshadri, R., Brus, L.E., Steigerwald, M.L., J. Am. Chem. Soc., 130, 6955, (2008)


Peak list


No. h k l d [A] 2Theta[deg] I [%]

1 0 0 1 4,04100 21,978 10,2

2 1 0 0 3,99720 22,222 19,0

3 1 0 1 2,84180 31,455 100,0

4 1 1 0 2,82640 31,631 52,7

5 1 1 1 2,31610 38,851 34,4

6 0 0 2 2,02050 44,821 15,9

7 2 0 0 1,99860 45,340 30,6

8 1 0 2 1,80320 50,578 5,0

9 2 0 1 1,79150 50,932 5,1

10 2 1 0 1,78760 51,051 5,0

11 1 1 2 1,64370 55,892 17,2

12 2 1 1 1,63480 56,223 33,3

13 2 0 2 1,42090 65,656 15,3

14 2 2 0 1,41320 66,060 7,7

15 0 0 3 1,34700 69,761 0,5

16 2 1 2 1,33880 70,251 3,9

17 2 2 1 1,33400 70,541 2,0

18 3 0 0 1,33240 70,638 1,2

19 1 0 3 1,27650 74,234 6,3

20 3 0 1 1,26540 74,997 7,2

21 3 1 0 1,26400 75,094 7,2

22 1 1 3 1,21600 78,613 2,9

23 3 1 1 1,20640 79,362 5,4

24 2 2 2 1,15810 83,386 6,4

25 2 0 3 1,11700 87,199 1,1

26 3 0 2 1,11230 87,661 1,1

27 3 2 0 1,10860 88,029 1,0

28 2 1 3 1,07580 91,455 6,8

29 3 1 2 1,07160 91,916 6,9

30 3 2 1 1,06910 92,194 6,9

31 0 0 4 1,01020 99,374 1,0

32 4 0 0 0,99930 100,859 1,9

33 1 0 4 0,97950 103,705 0,9

34 2 2 3 0,97500 104,381 0,8

35 3 2 2 0,97190 104,853 1,6

36 4 0 1 0,97010 105,130 1,0

37 4 1 0 0,96950 105,222 1,0

38 1 1 4 0,95130 108,140 2,4

39 3 0 3 0,94730 108,810 2,4

40 4 1 1 0,94270 109,595 5,1

41 3 3 0 0,94270 109,595 5,1

42 3 1 3 0,92170 113,386 2,4

43 3 3 1 0,91750 114,188 1,2

44 2 0 4 0,90160 117,380 2,9

45 4 0 2 0,89570 118,633 3,0

46 4 2 0 0,89380 119,044 3,0

47 2 1 4 0,87950 122,289 1,5

48 4 1 2 0,87410 123,587 1,4

49 4 2 1 0,87270 123,931 1,4

50 3 2 3 0,85600 128,285 4,3

51 3 3 2 0,85390 128,870 2,2

52 2 2 4 0,82190 139,179 2,7

53 4 2 2 0,81740 140,910 5,4

54 0 0 5 0,80820 144,768 0,2

55 3 0 4 0,80500 146,232 0,8

56 4 0 3 0,80260 147,380 0,7

57 4 3 0 0,79940 148,986 1,0

Structure


No. Name Elem. X Y Z Biso sof Wyck.

1 BA1 Ba 0,00000 0,00000 0,00000 0,5000 1,0000 1a

2 TI1 Ti 0,50000 0,50000 0,50000 0,5000 1,0000 1b

3 O1 O 0,50000 0,50000 0,01800 0,5000 1,0000 1b

4 O2 O 0,50000 0,00000 0,51200 0,5000 1,0000 2c

Stick Pattern
