24 25 |
Forend Screw Forend Screw Escutcheon |
50 51 |
Hammer Hammer Pin | ||
1 |
Frame |
26 |
Sear |
52 |
Mainspring Plunger |
2 |
Slide |
27 |
Sear Pin |
53 |
Mainspring, Inner |
3 |
Barrel with Ventilated Rib |
28 |
Sear Spring |
54 |
Mainspring, Outer |
4 |
Barrel Guide Pin |
29 |
Sear Spring Pin |
55 |
Magazine Latch |
5 |
Counterweight Support |
30 |
Ejector |
56 |
Magazine Latch Spring |
6 |
Counterweight Support Screw |
31 |
Ejector Deflection Pin |
57 |
Magazine Latch Pin |
7 |
Counterweight Support Bushing |
32 |
Extractor |
58 |
Ventilated Rib Retaining Pin |
8 |
Counterweight—2.52 oz. |
33 |
Extractor Spring Extractor Plunger |
59 |
Sight Aperture, Rear |
9 |
Counterweight—1.79 oz. |
34 |
60 |
Sight Windage Screw, Rear | |
10 |
Counterweight—.94 oz. |
35 |
Sight Blade, Front |
61 |
Sight Windage Bushing, Rear |
11 |
Counterweight Support and |
36 |
Sight Blade Retaining Pin, Front |
62 |
Sight Windage Washer, Rear |
Weights |
37 |
Magazine |
63 |
Sight Elevation Screw, Rear | |
12 |
Barrel Mounting Screw |
38 |
Magazine Button |
64 |
Sight Elevation Spring |
13 |
Barrel Mounting Screw Washer |
39 |
Magazine Follower |
65 |
Sight Adjusting Screw Follower, |
14 |
Click Platę |
40 |
Magazine Spring |
Windage or Elevation | |
15 |
Disconnector |
41 |
Magazine Complete |
66 |
Sight Adjusting Screw Follower Spring, Windage and Elevation |
16 |
Disconnector Spring |
42 |
Grip, Right-Hand | ||
17 |
Recoil Spring Guide |
43 |
Stop Open Latch |
67 |
Trigger |
18 |
Recoil Spring |
44 |
Stop Open Latch Spring |
68 |
Trigger Pin |
19 |
Firing Pin |
45 |
Grip Screw |
69 |
Trigger Backlash Adjustment Sci^ |
20 |
Fire Pin—For Dry Firing |
46 |
Grip Escutcheon, Threaded |
70 |
Safety |
21 22 23 |
Firing Pin Spring Firing Pin Retaining Pin Forend |
47 48 49 |
Grip Escutcheon, Unthreaded Hammer Link Pin Hammer Link |
71 |
Trigger Puli Adjustment Screw |
