siec w trakcie g72k sson

Kj) Monitor zasobów

Plik Monitor Pomoc

Przegląd

Procesor CPU

Pamięć

Dysk

Sieć

Procesy o aktywności sieciowej

Widoki w\

Obraz	Ident...	Wysyłanie (B/s)	Odbieranie (B/s)	Razem (B/s)
OpenPhone.exe	4660	2 103	1 527	3 630
. System	4	0	74	74
H svchost.exe (NetworkService)	1336	0	30	30

44 Kb/s (We/Wy sieci)

Aktywność sieci

Połączenia TCP

Porty nasłuchujące

^ OpenPhone

File Edit View Cali Help

Speed Dials sip:student@ 192.168.102.12

O

o

i

[7] Speaker \V Microphone

1

Rx Audio	Tx Audio Rx Video Tx Video Fax
Bandwidth: 10.8 kbps		Min Interval: 10 ms
Total Bytes: 86240		Avg Interval: 20 ms
Packę ts: 1078		Max Interval: 30 ms
Packets Lost: 0		Avg Jitter: 1 ms
Out of Order: 0		Max Jitter: 3 ms
Too Late: 0 Overruns: 0		Jitter Delay: 400 ms

Cali Time: 0i31

Hang Up

Hołd

Conference

*sip: 192.168.102.14* has deared the cali, on Wt 9:12. Duration 2:0 ls.

Calling *sip:student@192.168.102.12*

Cali failed as could not find common media capabilities with *sip:student@192.168.102.12*, on Wt 9: Calling *sip:student@192.168.102.12*

Cali failed as could not find common media capabilities with *sip:student@192.168.102.12*, on Wt 9: Cali failed as could not find common media capabilities with *sip: 192.168.

Incoming cali at Wt 9:15 from student

Started sending G.722. l-32k (20ms) to sip endpoint

Started receiving G.722. l-32k from sip endpoint

Established cali from sip:student@192.168.102.12 to sip: 192.168.102.14

0% wykorzystania sieci

Sieć

100 Kb/s -i

No Hand

m n® ir® m ir®

09:16

2012-10-16
