1N4148.1N4448

Vishay Semiconductors Fast Switching Diodes Features

D Silicon Epitaxial Planar Diodes D Electrically equivalent diodes: 1N4148 – 1N914

1N4448 – 1N914B

Applications

94 9367

Extreme fast switches

Order Instruction

Type

Type Differentiation

Ordering Code

Remarks

1N4148–TAP

Ammopack

1N4148

V

= 100 V V @I 10mA = 1 V

RRM = 100 V, VF@IF 10mA = 1

1N4148–TR

Tape and Reel

1N4448–TAP

Ammopack

1N4448

VRRM

V

= 100 V V

RRM = 100 V, F

V @I

F

F

@I 100mA = 1 V

F 100mA = 1

1N4448–TR

Tape and Reel

Absolute Maximum Ratings Tj = 25_C

Parameter

Test Conditions

Type

Symbol

Value

Unit

Repetitive peak reverse voltage VRRM

100

V

Reverse voltage

VR

75

V

Peak forward surge current tp=1ms

IFSM

2

A

Repetitive peak forward current IFRM

500

mA

Forward current

IF

300

mA

Average forward current

VR=0

IFAV

150

mA

l=4 mm, T

Power dissipation

L=45 °C

PV

440

mW

Power dissipation

l=4 mm, TLx25 °C

PV

500

mW

Junction temperature

Tj

200

°C

Storage temperature range Tstg

–65...+200

°C

Maximum Thermal Resistance Tj = 25_C

Parameter

Test Conditions

Symbol

Value

Unit

Junction ambient

l=4 mm, TL=constant

RthJA

350

K/W

Document Number 85521

www.vishay.com

Rev. 4, 12-Feb-01

1 (4)

1N4148.1N4448

Vishay Semiconductors Electrical Characteristics Tj = 25_C

Parameter

Test Conditions

Type

Symbol

Min

Typ

Max

Unit

IF=5mA

1N4448

VF

0.62

0.72

V

Forward voltage

g

IF=10mA

1N4148

VF

1

V

IF=100mA

1N4448

VF

1

V

VR=20 V

IR

25

nA

Reverse current

VR=20 V, Tj=150 °C

IR

50

mA

VR=75 V

IR

5

mA

I

Breakdown voltage

R=100mA, tp/T=0.01,

V

t

(BR)

100

V

p=0.3ms

Diode capacitance

VR=0, f=1MHz, VHF=50mV

CD

4

pF

Rectification efficiency VHF=2V, f=100MHz

hr

45

%

IF=IR=10mA, iR=1mA

trr

8

ns

Reverse recovery time

IF=10mA, VR=6V, iR=0.1xIR, RL=100W

trr

4

ns

Characteristics (Tj = 25_C unless otherwise specified) 1.2

1000

1 N 4148

)

1.0

I

)

F = 100 mA

V

100

0.8

oltage (

10 mA

V

Scattering Limit

0.6

10

1 mA

0.4

– Forward F

0.1 mA

1

V

I – Forward Current ( mA F

0.2

Tj = 25°C

0

0.1

–30

0

30

60

90

120

0

0.4

0.8

1.2

1.6

2.0

94 9169

Tj – Junction Temperature ( °C ) 94 9170

VF – Forward Voltage ( V ) Figure 1. Forward Voltage vs. Junction Temperature Figure 2. Forward Current vs. Forward Voltage www.vishay.com

Document Number 85521

2 (4)

Rev. 4, 12-Feb-01

1N4148.1N4448

Vishay Semiconductors 1000

1000

1 N 4448

)

)

100

Tj = 25°C

100

Scattering Limit

10

Scattering Limit

10

1

I – Forward Current ( mA F

I – Reverse Current ( nA R

Tj = 25°C

0.1

1

0

0.4

0.8

1.2

1.6

2.0

1

10

100

94 9171

VF – Forward Voltage ( V ) 94 9098

VR – Reverse Voltage ( V ) Figure 3. Forward Current vs. Forward Voltage Figure 4. Reverse Current vs. Reverse Voltage Dimensions in mm

Cathode Identification

∅ 0.55 max.

technical drawings

according to DIN

specifications

94 9366

∅ 1.7 max.

Standard Glass Case

54 A 2 DIN 41880

JEDEC DO 35

26 min.

3.9 max.

Weight max. 0.3 g

26 min.

Document Number 85521

www.vishay.com

Rev. 4, 12-Feb-01

3 (4)

1N4148.1N4448
