Amethyst T191 L3 parts List
ACM Part Number	Part Description	Part Ref	ACM Part Number	Part Description	Part Ref
84.04403.01F	XTOR UMT4403 UMT3 PNP	BQ2	22.10128.006	Conn SIM	U2
84.04401.01F	XTOR UMT4401 UMT3 NPN	BQ3 BQ4	71.03011.00U	IC INTF PTWL3011GGM A12 BGA100	U3
83.1R003.A8Q	DIODE S.B CRS03 30V1A PMDU	D1	21.N0015.002	CONN COIN-BATT	U4
83.02221.070	LED 2.7*1.2*1.3 22-21SYGC/S135	D13 D3 D4	72.28160.04U	IC FLASH 28F160C3TA100 16MUBGA	U5
83.00222.101	DIODE ARR DAN222 EM3	D14	72.28320.04U	IC FLASH 28F320C3TA100 32MUBGA	U5
83.00520.080	DIODE SB RB520S-30 EMD2	D15 D2	72.S1664.03T	IC SRAM LP62S1664BU-70LLT48CSP	U6
83.01921.070	LED 1.6*0.8 Y/G WA/CL 19-21SYG	D5 D6 D7 D8 D9 D10 D11 D12	74.15514.0FT	IC RF TRANSC HD155141TF TQFP56	U61
83.00057.01H	DIODE TUNING BBY57-02W SCD-80	D601 D602	69.11006.001	VCO RF UCVE4X307A 5.5*4.8*2.0	U63
69.41004.001	CHIP FUSE 1A 24V F0603 1608FF	F1	69.D1002.001	BALUN 300HZ LDB15C101A3700	U64
62.10039.003	DC Jack	J1	82.20083.001	OSC 880/1710 ENFVF382S12 VCO	U65
21.N0009.022	CONN BATT	JP1	69.10100.001	FILTER RF SAW LD45A 942.5MHZ	U66
84.01905.03F	FET MOS SI1905DL PC SOT-363	Q700	69.10101.001	SAFSD1GG84C A0T00B0S	U67
74.00014.030	IC VOLT SUP MLVS0603K14 0603	T1 T10 T2 T3 T4 T5 T9 T8	84.00010.01F	XTOR UMH10N UMD 6P NPN	U7
69.60009.001	THERM SMD 10K NTC 0402 NTH5G	TR1	74.77301.0K0	IC POWER AMP CX77301	U71
71.31950.00U( 71.41529.00U)	ASIC XF731950 GHH BGA 179B	U1	69.50017.001	SW RF ANTENNA MS-147 HIROSE	U72
74.03157.09Y	IC ANALOG SW NC7SB3157 SC70 6P	U10 U8	74.7WZ16.0MY	IC DUAL BUFFER NC7WZ16 SC70-6P	U73
84.0C143.01P	XTOR DTC143ZET1 SC-75 NPN	U15	74.04473.0K0	IC POWER AMP MAX4473EUA 8UMAX	U74
84.06303.03K	FET MOS FDG6303N NC SC70-6	U16 U18	74.LMC33.030	IC DIPLEXER+SW LMC33-07A0524A	U75
84.06506.030	FET MOS FDC6506P PC SOT-6	U17	84.0EMD3.01H	XTOR PLANER EMD3 EMT6	U84 U86
22.10128.006	Conn SIM	U2	82.21026.031	26M VCTCXO 5*3.2 ENG3003A	U85
71.03011.00U	IC INTF PTWL3011GGM A12 BGA100	U3	69.10074.001	FILTER EMI EMIF01-10005W5SOT32	U9 U14
21.N0015.002	CONN COIN-BATT	U4	74.08882.A3B	IC LR MAX8882EUTJJ 2.85V SOT23	U90
72.28160.04U	IC FLASH 28F160C3TA100 16MUBGA	U5	82.30001.C71	XTAL 32.768K 8P 30PPM SM-14J	X1
72.28320.04U	IC FLASH 28F320C3TA100 32MUBGA	U5	21.N0020.001	Conn MIC	X2
72.S1664.03T	IC SRAM LP62S1664BU-70LLT48CSP	U6
74.15514.0FT	IC RF TRANSC HD155141TF TQFP56	U61	23.20059.001	COIL BATTERY MS614
69.11006.001	VCO RF UCVE4X307A 5.5*4.8*2.0	U63
69.D1002.001	BALUN 300HZ LDB15C101A3700	U64
82.20083.001	OSC 880/1710 ENFVF382S12 VCO	U65
69.10100.001	FILTER RF SAW LD45A 942.5MHZ	U66
69.10101.001	SAFSD1GG84C A0T00B0S	U67
84.00010.01F	XTOR UMH10N UMD 6P NPN	U7
74.77301.0K0	IC POWER AMP CX77301	U71
69.50017.001	SW RF ANTENNA MS-147 HIROSE	U72
74.7WZ16.0MY	IC DUAL BUFFER NC7WZ16 SC70-6P	U73
74.04473.0K0	IC POWER AMP MAX4473EUA 8UMAX	U74
74.LMC33.030	IC DIPLEXER+SW LMC33-07A0524A	U75
84.0EMD3.01H	XTOR PLANER EMD3 EMT6	U84 U86
82.21026.031	26M VCTCXO 5*3.2 ENG3003A	U85
69.10074.001	FILTER EMI EMIF01-10005W5SOT32	U9 U14
74.08882.A3B	IC LR MAX8882EUTJJ 2.85V SOT23	U90
82.30001.C71	XTAL 32.768K 8P 30PPM SM-14J	X1
21.N0020.001	Conn MIC	X2
23.20059.001	COIL BATTERY MS614
