European Spare Parts | 2006.08.1 | ||
| Level 3 Parts List | Version 1.0 | |||
| K1 | ||||
| Ref. Des. | Part Number | Description | ||
| C21 C22 C24 C28 | 2113947B05 | CAPACITOR 33.0PF 50V | ||
| D903 | 4809653F10 | TRANSISTOR | ||
| FL100_SAW | 9188668L10 | FILTER SAW QUADBAND | ||
| FL1400 FL1401 FL1402 VR1201 VR3002 | 4809948D49 | DIODE 5.5V | ||
| FL3001 FL3002 | 9171527C04 | FILTER LOW PASS | ||
| FL301 | 9109674L33 | FILTER BLUETOOTH | ||
| FL54 FL82 | 9109403K08 | FILTER 240MHZ | ||
| J1_USB | 0988486Y02 | CONNECTOR USB | ||
| L1201 | 2587511Y01 | FILTER ESD PROTECTION | ||
| Q903 | 4809807C45 | TRANSISTOR | ||
| Q904 | 4809579E73 | TRANSISTOR Q904 | ||
| U1401 | 5114007A42 | IC INVERTER | ||
| U1600 | 5189336Y01 | IC HALL EFFECT SWITCH | ||
| U250_SYNTH | 5188450M37 | IC SYNTHESIZER | ||
| U301 | 5189914Y01 | IC BLUETOOTH | ||
| U50_PA | 5188995Y01 | IC AMPLIFIER | ||
| U700_MEM | 5170200A87 | IC FLASH | ||
| U800 | 5199185K03 | IC NEPTUNE | ||
| U801 | 5189153N01 | IC BFR CMOS | ||
| U900_AUL | 5188450M48 | IC ATLAS | ||
| U950 | 5109522E92 | IC INVERTER | ||
| Y201_26MHZ | 4809612J53 | XTAL 26 MHZ | ||
| Y900_32KHZ | 4809995L15 | XTAL 32.768MHZ 32KHZ | ||
| = Level 4 authorized Part | ||||
