European Spare Parts	2006.02.01
			Level 3 Parts List	Version 1.1
			V3x
			Author: Ralf Lorenzen-Scheil, Kai Nielsen
	Ref. Des.	Part Number	Description
	C1002 C1003 C1007 C1008 C1012 C1013 C1014 C1016 C1017 C1018 C1021 C1023 C1024 C1031	2113947H01	CAPACITOR 100.000PF 6.3V
	FL001	4889729N03	FRONT ENDO MODULE
	FL002	9109674L25	FILTER BANDPASS 2.14GHZ
	FL003	9109674L28	FILTER BANDPASS 1.95GHZ
	FL004	9109674L30	FLTR,CER,BANDREJECT,2.14GHZ NO
	FL100	9188695K05	FILTER 13MHZ
	FL5000 FL5001	9188916Y01	FILTER LOWPASS
	FL5002	9109674L26	FILTER BANDPASS 2.45GHZ
	FL900	9109239M38	FILTER 2140MHZ
	J4100	5089874N01	MICROPHONE
	J5212	0989851N02	KEYBOARD CONNECTOR
	J5501	0988486Y02	CONNECTOR USB
	J8000	0988866N04	KEYBOARD CONNECTOR
	J8005	0971834C01	CONNECTOR BOARD TO BOARD
	M5400	3971392B01	CONNECTOR BATTERY
	Q3963	4888585Y01	TRANSISTOR
	T901	5885949K04	IC BALUN 920MHZ
	T902 T903	5885949K06	IC BALUN 1850MHZ
	U001	5109944C61	IC LNA 1.93GHZ
	U100	5188450M23	IC HARMONY
	U1000	5199169K06	IC POG
	U1300	5199187J01	IC FLASH 512MBIT
	U200	5188450M21	IC MODULE RATTLER
	U3000	5185941F02	IC PCAP
	U3200	5188128Y01	IC CONVERTER
	U400	5189552N01	IC TX PA 1.92GHZ
	U5100 U5101 U5202 U5204 U6011	4885534E09	FILTER LOWPASS 95MHZ
	U5104	4889526L13	FILTER ESD PROTECTION
	U6003	5109773F18	IC CHARGE AND BATTERY CONTROL
	U6004	5109509A71	IC FLASH/SRAM 64/32MB 2X256MBI
	U6006	5189914Y01	IC BLUETOOTH
	U6008 U6009	5164751E03	IC LEVEL SHIFT
	U800	5188220Y02	IC PA 880MH
	U880	5109768D12	IC,TEMP SENSOR
	U900	4889717N03	IC BLUE MODULE
	Y3982	4809995L20	XTAL 032768MHZ
	Y500	4809718L24	XTAL 26MHZ
			= Level 4 authorized Part
