Parts List EU Z8 A4 BW L3 CFLG1041AB,014,FL,1 V1 0



Global Spare Parts 2007.03.05

Level 3 Parts List Version 1.0

Z8

CFLG1041AB,014,FL,1

















Ref. Des. Part Number Description


C2005 C2006 C2007 C2008 C3003 C3010 C3011 C3013 C3014 C3016 C3017 C3018 C819 2113946F08 CAPACITY 22UF


D3000 D3003 4809653F10 TRANSISTOR


FL1 9109674L27 FILTER BANDPASS WB


FL300 9109239M43 FILTER SAW WB


FL500 9188322Z02 FILTER SAW GSM


FL5100 FL5101 FL8003 4885534E09 FILTER LOWPASS 95MHZ


FL7500 FL7501 9103603D06 FILTER ESD


FL8000 FL8001 FL8002 4871380E01 FILTER ESD


FL8004 4813979M36 FILTER ESD


Q3000 Q3002 Q3003 4809807C45 TRANSISTOR


U1 4889729N07 IC FRONTEND MODULE


U1000 5199217K05 IC ARGON


U102 5188800Y04 IC SYMPHONY


U1500 5103535B52 IC SDRAM 128MB POP


U2000 5103535B04 IC OMAP PDA PROCESSOR


U2001 0103508F16 IC OMAP POWER MANAGEMENT


U2002 5103535B69 IC OMAP FLASH 1G


U3000 5188450M53 IC ATLAS


U301 5189240Y02 IC LNA WB


U403 5188686Y02 IC POWER AMPLIFIER WCDMA


U505 5188450M37 IC SYNTHESIZER


U800 5109908K98 IC POWER AMPLIFIER GSM


U8000 U8001 5103535B16 IC SERIALIZER


VR4000 4809948D49 DIODE 5.5V


Y102 4809718L24 XTAL 26MHZ


Y3000 4809995L15 XTAL 32.768MHZ 32KHZ










= Level 4 authorized Part
