RM-1 SB-030

Copyright © Nokia Corporation 2005

Customer and Market Operations

Service Bulletin No. SB-030/05.04.05

EMEA Customer Care

RM-1

NEW MAJOR DATA PACKAGE VERSION 6.0 (MCU SW 4.03.18)

New major data package version 6.0 (MCU SW 4.03.18) has been released
for RM-1.

Before installing product data package, please install Phoenix Service
Software version 2005.04.6.84 or later.

Do not remove old RM-1 major data package version 5.0 before installing
new major data package 6.0.

Software downgrade is not allowed, due to BB5 security. In case older
software is flashed, the phone does not boot up. USB flashing doesn’t
work if phone cannot boot up. This can be fixed by flashing newer
software or the same software that was previously used in the phone.
This can be done only in level 3 service using phone specific adapter
and prommer.

Major data package v6.0 includes following SW components:

-

MCU SW file 4.03.18

-

Language package files (PPM’s) for MCU SW:

0521009 3 UK
0521051 Orange FR

-

Product specific ini-files

-

Default SW setting files (product profiles, user profiles, WAP bookmarks,
etc)

-

Label printing files

-

User interface configuration file for Product Profile tool

-

Product specific files for Faultlog reporting

-

Changes/improvements made from MCU SW v 3.45.11.3 to v 4.03.18:

-

Telephony:
-

2-digit voice mailbox numbers supported (e.g. “*30”), earlier minimum
was 3 or more numbers

-

GSM AMR voice codec supported

-

Behaviour improved when Call Control and FDN is activated

-

Operator name display functionality improved

CONFIDENTIAL

2 (3)

x

Level 1

x

Level 2

x

Level 3

x

Level 4

Ref.

RM-1 SB-030

Copyright © Nokia Corporation 2005

-

SIM / USAT:
-

USAT Mobile originated Short Message Control supported

-

USAT Send DTMF supported

-

Terminal now responds also to unsupported SIM ATK commands to
ensure running toolkit application can continue running allthough some
spesific commands would not be supported

-

Handling of SIM phonebook with additional numbers (ANR) improved.

-

Handling of long SIM ADN contacts (up to maximum 30 numbers)
improved

-

Terminal can better handle USIM phonebooks with differing sizes of
ADN blocks

-

Interoperability with specific RAN infrastructure improved

-

Phone behaviour improved when performing ISHO

-

Phone behaviour improved in weak field conditions when performing a
blind handover from WCDMA to GSM

-

Audio and Video:
-

Wider UDP and bandwidth ranges available in phone variant SW

-

Streaming rate adaptation supported

-

Interoperability improved for some servers

-

Identification and playback of some streaming files identified to be
3GPP rel6 format now possible (please note that Nokia 6630 does not
support all 3GPP rel6 streaming requirements)

-

Resuming of streaming after MT call improved

-

Up to 2MB DRM protected files can now be set as ringing tones

-

Handling of pause and play with long MP3 variable bit rate files
improved

-

Ringing tone playback improved in low memory situations

-

Browser:
-

Handling of content with multiple nested object tags improved

-

Handling of underlined links improved, link visibility now better for end
user

-

Handling of saved browser pages with inconsistent HTTP content-type
header and actual encoded content text type improved

-

Browser memory handling improved.

-

Decoding of HTML tag information when split between different TCP
packets improved

-

HTTP pipelining will be set as disabled in terminal to ensure correct
display of images and other content when used with spesific content
servers (IIS 4.0, 5.0 and Netscape-Enterprise 3)

-

Cookie handling on some webpages improved. ECMAScript handling
changed.

-

Handling of white space encoding for plug-ins changed, browser no
longer closes itself

-

Table rendering improved

-

Video Call:
-

Video Telephony DTMF tones supported (UII messages)

-

Bluetooth headset supported during VT call

-

Further improvements on video call setup time implemented

-

Some localisation texts updated

-

Automatic access point settings updated

CONFIDENTIAL

3 (3)

x

Level 1

x

Level 2

x

Level 3

x

Level 4

Ref.

RM-1 SB-030

Copyright © Nokia Corporation 2005

-

PC Dialup over USB improved

-

Bluetooth headset connection swapping between headset and mobile
improved

-

Symbian installation trust setting for Geotrust CA for UTI used for verifying
signing of midlets now set to “untrusted” instead of trusted.

-

Java Audio playback improved

-

MMS handling improved

-

Global GCF 3G WDCMA Certification

Note:

-

Manual File Selection should be un-checked (parameters menu)
before press Flash button. Phoenix can automatically select proper
Image File and PPM File according to product code.

Needed equipment for software update:

-

Phoenix Service Software version 2005.04.6.84 or later

-

Product Data Package v6.0

-

PKD-1 Dongle & Activated Flash Prommer FPS-10 or
DKU-2 USB Cable

-

Product specific service tools
