RM-1 SB-067

Customer and Market Operations

Service Bulletin No. SB-067/16.03.06

EMEA Customer Care

RM-1

NEW MAJOR DATA PACKAGE VERSION 11.0 (MCU SW 6.03.08)

New major data package version 11.0 (MCU SW 6.03.08) has been released
for RM-1.

Before installing product data package, please install Phoenix Service
Software version 2005.44.7.123 or later.

Software downgrade is not allowed, due to BB5 security. In case older
software is flashed, the phone does not boot up. USB flashing doesn’t
work if phone cannot boot up. This can be fixed by flashing newer
software or the same software that was previously used in the phone.
This can be done only in level 3 service using phone specific adapter
and prommer.

Major data package v11.0 includes following SW components:

MCU SW file 6.03.08

- Variant images for 6.03.08
- Product specific ini-files (e.g. RM_1.ini)
- Configuration and testing ini-files (adcreadings.ini, autotune_RM-1.ini,

Bluetooth.ini, Camera_control.ini, Factoryset.ini, Phoneinfo.ini,
Rfconf_RM-1.xml, RM_1displaytest.ini, RM_1_als.ini, RM_1_tunings.ini)

Size of the data package is 102 MB

Changes/improvements made from MCU SW v 5.03.08 to v 6.03.08:

- SIM

USAT

- FPLMN list updated on USIM.
- Axalto USIM card detection improved.
- FDN activation and deactivation with Axalto USIM card improved.
- SMS sending from Gemplus SIMATK improved.

- Audio and Video

- Unknown Hi-fi headset default volume decreased.
- RTSP Teardown now sent after streaming is stopped.
- Video player stability improved when playing invalid MP4 file.

- Browser

- Improved handling of large web pages when rendering them using “By

quality” option.

- Handling of unescaped # character in web page improved.

CONFIDENTIAL

2 (4)

Level 1

Level 2

Level 3

Level 4

Version 1

RM-1 SB-067

- General Browser stability improved.

- Messaging

- Fixed phone freeze problem with some T9 combinations.
- General T9 robustness improved.
- Receiving problem with DRM protected MMS fixed.
- Changed the handling of <DIV> tags in order to remove unwanted

linefeeds.

- Fix the problem of corrupted Hebrew characters in received email.

- Video

Call

- Phone reset problem during video sharing initialization corrected.
- SMS and Video call alert tones both played, if received at the same

time.

- Video Call initialization phase robustness improved.

- Handling of corrupted jpeg files improved.
- Phone reset problem with Motorola BT headsets fixed.
- General connectivity robustness improved with BT car kits.
- Bluetooth pairing interoperability improved.
- Problem to access menu with certain SIM cards corrected.
- Logs GPRS counter clearing improved in certain situations.
- Operator name list updated.
- Improvements in weak field performance.
- Phone reset with certain SIM and SMS combination corrected.
- Snooze option disappearing problem corrected.
- Removed possibility to change profiles when SIM not inserted.
- MAP service UnstructeredSSNotify functionality improved.
- Network connection failure not shown anymore after using PUK code.
- 3gp file recognition from header (extension independent recognition)

improved.

- USSD message not cleared automatically anymore after automatic

acknowledge sent to network.

- Sound quality of music track is no longer affected by camera shooting.
- Current consumption improved.
- Usage of SRES parameter improved.
- Added support for Network error code "00011010 Insufficient Resources"

in networks that doesn’t support multiple PDP context.

- GMS network selection improved in case GERAN is preferred.

Supported variants/languages in major data package v 11.0:

0518104 France
0518141 France
0517773 Euro1
0630780 Euro1
0518190 Euro1
0518191 Euro1
0518119 Switzerland
0518144 Switzerland
0518120 Italy
0518145 Italy

CONFIDENTIAL

3 (4)

Level 1

Level 2

Level 3

Level 4

Version 1

RM-1 SB-067

0518142 Ger_Tur
0518117 Ger_Tur
0518118 Alps
0518143 Alps
0518121 Scandinavia1
0516982 Scandinavia1
0518122 Scandinavia2
0518146 Scandinavia2
0518123 Iceland
0518147 Iceland
0518124 Benelux1
0518148 Benelux1
0518149 Benelux2
0518125 Benelux2
0518168 Hebrew
0518107 Hebrew
0518138 CIS
0518163 CIS
0518126 Estonia
0518150 Estonia
0518127 Latvia
0518151 Latvia
0518128 Lithuania
0518152 Lithuania
0518129 Poland
0518153 Poland
0518130 Czech_Slovakia
0518154 Czech_Slovakia
0518131 Hungary
0518155 Hungary
0518132 Croatia
0518156 Croatia
0518157 Slovenia
0518133 Slovenia
0518134 Romania
0518159 Romania
0518135 Turkey
0518160 Turkey
0518136 Spain
0518161 Spain
0518137 Portugal
0518162 Portugal
0518105 Greece
0518166 Greece
0518167 RUSSIA
0518106 RUSSIA
0519362 RUSSIA
0519363 RUSSIA

CONFIDENTIAL

4 (4)

Level 1

Level 2

Level 3

Level 4

Version 1

RM-1 SB-067

0518139 Bulgaria
0518164 Bulgaria
0518140 Serbia
0518165 Serbia
0518108 Arabic
0518169 Arabic
0518192 Arabic
0518193 Arabic

Needed equipment for software update:

- Phoenix Service Software version 2005.44.7.123 or later
- Product

Data

Package

v11.0

- PKD-1 Dongle & Activated Flash Prommer FPS-10 or

DKU-2 USB Cable

- Product specific service devices
