WIRING INFORMATION: 1991 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
YELLOW
Ignition Harness
STARTER WIRE
RED/LT. BLUE
Ignition Harness
IGNITION WIRE
RED/LT. GREEN
Ignition Harness
ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
SECOND ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Down Low In Drivers Kick
POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN Harness
Down Low In Drivers Kick
PARKING LIGHTS (+)
BROWN
At Headlight Switch
HEADLIGHTS (+)
RED/YELLOW
At Headlight Switch
DOOR TRIGGER (+)
BLACK/LT.BLUE
Harness In Driver’s Kick Panel Or Under Dash
Light
DOME SUPERVISION (+)
Use Door Trigger Wire
TRUNK RELEASE (+)
PURPLE/YELLOW
At Trunk Release Switch
TACHOMETER WIRE
DK.GREEN/YELLOW
At Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
YELLOW/LT. GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
3
WIRING INFORMATION: 1992 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
YELLOW
Ignition Harness
STARTER WIRE
RED/LT. BLUE
Ignition Harness
IGNITION WIRE
RED/LT. GREEN
Ignition Harness
ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Down Low In Drivers Kick
POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN Harness
Down Low In Drivers Kick
PARKING LIGHTS (+)
BROWN
At Headlight Switch
HEADLIGHTS (+)
RED/YELLOW
At Headlight Switch
DOOR TRIGGER (+)
BLACK/LT.BLUE
Harness In Driver’s Kick Panel Or Under Dash
Light
DOME SUPERVISION (+)
Use Door Trigger Wire
TRUNK RELEASE (+)
PURPLE/YELLOW
At Trunk Release Switch
TACHOMETER WIRE
GRAY/ORANGE
At Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
YELLOW/LT. GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION: 1993 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
YELLOW
Ignition Harness
STARTER WIRE
RED/LT. BLUE
Ignition Harness
IGNITION WIRE
RED/LT. GREEN
Ignition Harness
ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Down Low In Drivers Kick
POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN Harness
Down Low In Drivers Kick
PARKING LIGHTS (+)
BROWN
At Headlight Switch
HEADLIGHTS (+)
RED/YELLOW
At Headlight Switch
DOOR TRIGGER (+)
BLACK/LT.BLUE
Harness In Driver’s Kick Panel Or Under Dash
Light
DOME SUPERVISION (+)
Use Door Trigger Wire
TRUNK RELEASE (+)
PURPLE/YELLOW
At Trunk Release Switch
TACHOMETER WIRE
GRAY/ORANGE
At Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
YELLOW/LT. GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
4
WIRING INFORMATION: 1994 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
YELLOW
Ignition Harness
STARTER WIRE
RED/LT. BLUE
Ignition Harness
IGNITION WIRE
RED/LT. GREEN
Ignition Harness
ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Down Low In Drivers Kick
POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN Harness
Down Low In Drivers Kick
PARKING LIGHTS (+)
BROWN
At Headlight Switch
HEADLIGHTS (+)
RED/YELLOW
At Headlight Switch
DOOR TRIGGER (+)
BLACK/LT.BLUE
Harness In Driver’s Kick Panel Or Under Dash
Light
DOME SUPERVISION (+)
Use Door Trigger Wire
TRUNK RELEASE (+)
PURPLE/YELLOW
At Trunk Release Switch
TACHOMETER WIRE
GRAY/ORANGE
At Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
YELLOW/LT. GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
5
WIRING INFORMATION: 1995 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
YELLOW, BROWN, GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
ACCESSORY WIRE
PINK/BLACK
Ignition Harness
SECOND ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
THIRD ACCESSORY WIRE
BLACK/LT. GREEN
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness In Driver’s Kick Panel
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness In Driver’s Kick Panel
PARKING LIGHTS (+)
BROWN
Harness In Drivers Kick Panel
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Driver’s Side
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Driver’s Side
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
FACTORY ALARM DISARM (-)
DK. GREEN/PURPLE
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
TAN/LT.GREEN, TAN/WHITE, TAN/LT.BLUE,
or TAN/ORANGE
At Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
YELLOW/LT.GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
6
WIRING INFORMATION: 1996 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
YELLOW, BROWN, GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
ACCESSORY WIRE
PINK/BLACK
Ignition Harness
SECOND ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
THIRD ACCESSORY WIRE
BLACK/LT. GREEN
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness In Driver’s Kick Panel
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness In Driver’s Kick Panel
PARKING LIGHTS (+)
BROWN
Harness In Drivers Kick Panel
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Driver’s Side
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Driver’s Side
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
FACTORY ALARM DISARM (-)
DK. GREEN/PURPLE
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
TAN/LT.GREEN, TAN/WHITE, TAN/LT.BLUE,
or TAN/ORANGE
At Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
YELLOW/LT.GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
7
WIRING INFORMATION: 1997 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
YELLOW, BROWN, GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
ACCESSORY WIRE
PINK/BLACK
Ignition Harness
SECOND ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
THIRD ACCESSORY WIRE
BLACK/LT. GREEN
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness In Driver’s Kick Panel
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness In Driver’s Kick Panel
PARKING LIGHTS (+)
BROWN
Harness In Drivers Kick Panel
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Driver’s Side
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Driver’s Side
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
FACTORY ALARM DISARM (-)
DK. GREEN/PURPLE
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
TAN/LT.GREEN, TAN/WHITE, TAN/LT.BLUE,
or TAN/ORANGE
At Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
YELLOW/LT.GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
8
WIRING INFORMATION: 1998 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
BROWN and LT.GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
SECOND IGNITION WIRE
GRAY/YELLOW
Ignition Harness
ACCESSORY WIRE
BLACK/LT.GREEN
Ignition Harness
SECOND ACCESSORY WIRE
PINK/BLACK
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness Coming Into Vehicle From Driver’s
Door
PARKING LIGHTS (+)
BROWN
Module Under Dash On Right Side Of
Steering Column
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Right Side Of
Steering Column
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Right Side Of
Steering Column
DOME SUPERVISION (+)
BLACK/LT. BLUE
Module Under Dash On Right Side Of
Steering Column
TRUNK TRIGGER (-)
BROWN/WHITE
Module Under Dash On Right Side Of
Steering Column
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
WHITE/PINK
At Power Train Module On Driver’s Side Of
Engine Bay
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
DK.BLUE
Module Under Dash On Right Side Of
Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
This vehicle is equipped with the PATS anti-theft system. This must be bypassed when installing a remote start system.
Copyright 2002-2004 Triple S Customs
9
WIRING INFORMATION: 1999 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
BROWN and LT.GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
SECOND IGNITION WIRE
GRAY/YELLOW
Ignition Harness
ACCESSORY WIRE
BLACK/LT.GREEN
Ignition Harness
SECOND ACCESSORY WIRE
PINK/BLACK
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness Coming Into Vehicle From Driver’s
Door
PARKING LIGHTS (+)
BROWN
Module Under Dash On Right Side Of
Steering Column
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Right Side Of
Steering Column
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Right Side Of
Steering Column
DOME SUPERVISION (+)
BLACK/LT. BLUE
Module Under Dash On Right Side Of
Steering Column
TRUNK TRIGGER (-)
BROWN/WHITE
Module Under Dash On Right Side Of
Steering Column
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
WHITE/PINK
At Power Train Module On Driver’s Side Of
Engine Bay
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
DK.BLUE
Module Under Dash On Right Side Of
Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
This vehicle is equipped with the PATS anti-theft system. This must be bypassed when installing a remote start system.
Copyright 2002-2004 Triple S Customs
10
WIRING INFORMATION: 2000 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
BROWN and LT.GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
SECOND IGNITION WIRE
GRAY/YELLOW
Ignition Harness
ACCESSORY WIRE
BLACK/LT.GREEN
Ignition Harness
SECOND ACCESSORY WIRE
PINK/BLACK
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Coming Into Vehicle From Driver’s Door
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness Coming Into Vehicle From Driver’s Door
PARKING LIGHTS (+)
BROWN
Module Under Dash On Right Side Of Steering
Column
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Right Side Of Steering
Column
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Right Side Of Steering
Column
DOME SUPERVISION (+)
BLACK/LT. BLUE
Module Under Dash On Right Side Of Steering
Column
TRUNK TRIGGER (-)
BROWN/WHITE
Module Under Dash On Right Side Of Steering
Column
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s Door
TACHOMETER WIRE
WHITE/PINK
At Power Train Module On Driver’s Side Of Engine
Bay
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
DK.BLUE
Module Under Dash On Right Side Of Steering
Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
This vehicle is equipped with the PATS anti-theft system. This must be bypassed when installing a remote start system.
Copyright 2002-2004 Triple S Customs
11
WIRING INFORMATION: 2001 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
BROWN and LT.GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
SECOND IGNITION WIRE
GRAY/YELLOW
Ignition Harness
ACCESSORY WIRE
BLACK/LT.GREEN
Ignition Harness
SECOND ACCESSORY WIRE
PINK/BLACK
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Coming Into Vehicle From Driver’s Door
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness Coming Into Vehicle From Driver’s Door
PARKING LIGHTS (+)
BROWN
Module Under Dash On Right Side Of Steering
Column
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Right Side Of Steering
Column
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Right Side Of Steering
Column
DOME SUPERVISION (+)
BLACK/LT. BLUE
Module Under Dash On Right Side Of Steering
Column
TRUNK TRIGGER (-)
BROWN/WHITE
Module Under Dash On Right Side Of Steering
Column
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s Door
TACHOMETER WIRE
WHITE/PINK
At Power Train Module On Driver’s Side Of Engine
Bay
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
DK.BLUE
Module Under Dash On Right Side Of Steering
Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
This vehicle is equipped with the PATS anti-theft system. This must be bypassed when installing a remote start system.
Copyright 2002-2004 Triple S Customs
12
WIRING INFORMATION: 2002 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
BROWN and LT.GREEN
Ignition Harness
STARTER WIRE
WHITE/PINK
Ignition Harness
IGNITION WIRE
BROWN/PINK
Ignition Harness
SECOND IGNITION WIRE
GRAY/YELLOW
Ignition Harness
ACCESSORY WIRE
BLACK/LT.GREEN
Ignition Harness
SECOND ACCESSORY WIRE
PINK/BLACK
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness Coming Into Vehicle From Driver’s
Door
PARKING LIGHTS (+)
BROWN
Module Under Dash On Right Side Of
Steering Column
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Right Side Of
Steering Column
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Right Side Of
Steering Column
DOME SUPERVISION (+)
BLACK/LT. BLUE
Module Under Dash On Right Side Of
Steering Column
TRUNK TRIGGER (-)
BROWN/WHITE
Module Under Dash On Right Side Of
Steering Column
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
WHITE/PINK
At Power Train Module On Driver’s Side Of
Engine Bay
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
DK.BLUE
Module Under Dash On Right Side Of
Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
This vehicle is equipped with the PATS anti-theft system. This must be bypassed when installing a remote start system.
Copyright 2002-2004 Triple S Customs
13
WIRING INFORMATION: 2003 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
BROWN and LT.GREEN
Ignition Harness
STARTER WIRE
RED/LT.BLUE
Ignition Harness
IGNITION WIRE
WHITE/YELLOW
Ignition Harness
ACCESSORY WIRE
BLACK/LT.GREEN
Ignition Harness
SECOND ACCESSORY WIRE
PINK/BLACK
Ignition Harness
THIRD ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness Coming Into Vehicle From Driver’s
Door
PARKING LIGHTS (+)
BROWN
Module Under Dash On Right Side Of
Steering Column
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Right Side Of
Steering Column
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Right Side Of
Steering Column
TRUNK TRIGGER (-)
BROWN/WHITE
Module Under Dash On Right Side Of
Steering Column
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
Wire that is NOT RED or RED/GREEN
Any Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
DK.BLUE
Module Under Dash On Right Side Of
Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
This vehicle is equipped with the PATS anti-theft system. This must be bypassed when installing a remote start system.
Copyright 2002-2004 Triple S Customs
14
WIRING INFORMATION: 2004 Mercury Grand Marquis
WIRE
WIRE COLOR
WIRE LOCATION
12V CONSTANT WIRE
BROWN and LT.GREEN
Ignition Harness
STARTER WIRE
RED/LT.BLUE
Ignition Harness
IGNITION WIRE
WHITE/YELLOW
Ignition Harness
ACCESSORY WIRE
BLACK/LT.GREEN
Ignition Harness
SECOND ACCESSORY WIRE
PINK/BLACK
Ignition Harness
THIRD ACCESSORY WIRE
GRAY/YELLOW
Ignition Harness
POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)
PINK/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)
PINK/GREEN
Harness Coming Into Vehicle From Driver’s
Door
PARKING LIGHTS (+)
BROWN
Module Under Dash On Right Side Of
Steering Column
DRIVER DOOR TRIGGER (-)
BLUE
Module Under Dash On Right Side Of
Steering Column
PASSENGER DOORS TRIGGER (-)
BLACK/ORANGE
Module Under Dash On Right Side Of
Steering Column
TRUNK TRIGGER (-)
BROWN/WHITE
Module Under Dash On Right Side Of
Steering Column
TRUNK RELEASE (5-wire)
PURPLE/YELLOW
Harness Coming Into Vehicle From Driver’s
Door
TACHOMETER WIRE
Wire that is NOT RED or RED/GREEN
Any Ignition Coil
BRAKE WIRE (+)
LT. GREEN
At Brake Pedal Switch
HORN TRIGGER (-)
DK.BLUE
Module Under Dash On Right Side Of
Steering Column
LEFT FRONT WINDOW UP
YELLOW
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
WHITE/BLACK
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
TAN/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GRAY/ORANGE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
TAN/BLUE or YELLOW/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
RED/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
YELLOW/BLACK
Harness In Driver’s Kick From Driver Door
This vehicle is equipped with the PATS anti-theft system. This must be bypassed when installing a remote start system.
Wyszukiwarka
Podobne podstrony:
PN EN 1991 1 1 2004 Ap1 2010
Eurocod 1, 1 1 Ciężar objętościowy, ciężar własny, obciążenia użytkowe PN EN 1991 1 1 2004 a
Eurocode 1 Part 1,6 prEN 1991 1 6 2004
PN EN 1991 1 1 2004
NISSAN PATHFINDER 1991 2004
PN EN 1991 1 1 2004 Ap1 2010
PN EN 1991 1 1 2004
Śniadania w Hotelu Mercure Grand
PN EN 1991 1 1 2004 AC 2009
Eurocode 1 Part 1,4 prEN 1991 1 4 2004
Instrukcja obsługi suzuki grand vitara I 1998 2004
PN EN 1991 1 1 2004 AC 2009
JEEP GRAND CHEROKEE 1992 2004
CADILLAC SEVILLE 1991 2004
CHEVROLET CAVALIER 1991 2004
PN EN 1991 1 1 2004 Ap1 2010
Eurocod 1, 1 1 Ciężar objętościowy, ciężar własny, obciążenia użytkowe PN EN 1991 1 1 2004 a
Eurocode 1 Part 1,6 prEN 1991 1 6 2004
DODGE DAKOTA 1991 2004
więcej podobnych podstron
