WIRING INFORMATION 1993 Honda Del Sol

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

WHITE

Ignition harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition harness

STARTER WIRE

BLACK/WHITE

Ignition harness

ACCESSORY WIRE

YELLOW

Ignition harness

PARKING LIGHTS (+)

BLACK

Harness On Top Of Fuse Box

POWER DOOR LOCK (-)

GREEN/WHITE

At Lock Switch In Driver’s Door

POWER DOOR UNLOCK (-)

GREEN/RED

At Lock Switch In Driver’s Door

DOOR TRIGGER (-)

GREEN/RED

Harness In Driver’s Kick Panel Or Harness
At Fuse Box

DOMELIGHT SUPERVISION (-)

Use door trigger wire

Use door trigger wire

TRUNK TRIGGER (-)

GREEN/BLACK

Harness In Driver’s Kick Panel Or Harness
At Fuse Box

TACHOMETER WIRE

BLUE

At Distributor

BRAKE WIRE (+)

GREEN/WHITE

Harness At Brake Pedal Switch

LEFT FRONT WINDOW UP

BLUE/RED

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLUE/WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

BLUE/GREEN

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION 1994 Honda Del Sol

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

WHITE

Ignition harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition harness

STARTER WIRE

BLACK/WHITE

Ignition harness

ACCESSORY WIRE

YELLOW

Ignition harness

PARKING LIGHTS (+)

BLACK

Harness At Fuse Box

POWER DOOR LOCK (-)

GREEN/WHITE

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

POWER DOOR UNLOCK (-)

GREEN/RED

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

DOOR TRIGGER (-)

GREEN/RED

Harness In Driver’s Kick Panel Or Harness
At Fuse Box

DOMELIGHT SUPERVISION (-)

Use door trigger wire

Use door trigger wire

TRUNK TRIGGER (-)

GREEN/BLACK

Harness Above Fuse Box

TACHOMETER WIRE

BLUE

At Distributor

BRAKE WIRE (+)

GREEN/WHITE

Harness At Brake Pedal Switch

LEFT FRONT WINDOW UP

BLUE/RED

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLUE/WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

BLUE/GREEN

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION 1995 Honda Del Sol

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

WHITE

Ignition harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition harness

STARTER WIRE

BLACK/WHITE

Ignition harness

ACCESSORY WIRE

YELLOW

Ignition harness

PARKING LIGHTS (+)

BLACK

Harness At Fuse Box

POWER DOOR LOCK (-)

GREEN/WHITE

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

POWER DOOR UNLOCK (-)

GREEN/RED

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

DOOR TRIGGER (-)

GREEN/RED

Harness In Driver’s Kick Panel Or Harness
At Fuse Box

DOMELIGHT SUPERVISION (-)

Use door trigger wire

Use door trigger wire

TRUNK TRIGGER (-)

GREEN/BLACK

Harness Above Fuse Box

TACHOMETER WIRE

BLUE

At Distributor

BRAKE WIRE (+)

GREEN/WHITE

Harness At Brake Pedal Switch

LEFT FRONT WINDOW UP

BLUE/RED

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLUE/WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

BLUE/GREEN

Harness In Driver’s Kick From Driver Door

background image

Copyright 2002-2004 Triple S Customs

3

WIRING INFORMATION 1996 Honda Del Sol

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

WHITE

Ignition harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition harness

STARTER WIRE

BLACK/WHITE

Ignition harness

ACCESSORY WIRE

YELLOW

Ignition harness

PARKING LIGHTS (+)

BLACK

Harness At Fuse Box

POWER DOOR LOCK (-)

GREEN/WHITE

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

POWER DOOR UNLOCK (-)

GREEN/RED

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

DOOR TRIGGER (-)

GREEN/RED

Harness In Driver’s Kick Panel Or Harness
At Fuse Box

DOMELIGHT SUPERVISION (-)

Use door trigger wire

Use door trigger wire

TRUNK TRIGGER (-)

GREEN/BLACK

Harness Above Fuse Box

TACHOMETER WIRE

BLUE

At Distributor

BRAKE WIRE (+)

GREEN/WHITE

Harness At Brake Pedal Switch

LEFT FRONT WINDOW UP

BLUE/RED

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLUE/WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

BLUE/GREEN

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION 1997 Honda Del Sol

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

WHITE

Ignition harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition harness

STARTER WIRE

BLACK/WHITE

Ignition harness

ACCESSORY WIRE

YELLOW

Ignition harness

PARKING LIGHTS (+)

BLACK

Harness At Fuse Box

POWER DOOR LOCK (-)

GREEN/WHITE

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

POWER DOOR UNLOCK (-)

GREEN/RED

Harness Behind Silver Module In Driver’s
Kick Panel Or Door Lock Switch Inside
Driver’s Door

DOOR TRIGGER (-)

GREEN/RED

Harness In Driver’s Kick Panel Or Harness
At Fuse Box

DOMELIGHT SUPERVISION (-)

Use door trigger wire

Use door trigger wire

TRUNK TRIGGER (-)

GREEN/BLACK

Harness Above Fuse Box

TACHOMETER WIRE

BLUE

At Distributor

BRAKE WIRE (+)

GREEN/WHITE

Harness At Brake Pedal Switch

LEFT FRONT WINDOW UP

BLUE/RED

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLUE/WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

BLUE/GREEN

Harness In Driver’s Kick From Driver Door
