BF423 BF421

background image

1

Motorola Small–Signal Transistors, FETs and Diodes Device Data

PNP Silicon

MAXIMUM RATINGS

Rating

Symbol

BF421

BF423

Unit

Collector – Emitter Voltage

VCEO

–300

–250

Vdc

Collector – Base Voltage

VCBO

–300

–250

Vdc

Emitter – Base Voltage

VEBO

–5.0

Vdc

Collector Current — Continuous

IC

–500

mAdc

Total Device Dissipation

@ TA = 25

°

C

Derate above 25

°

C

PD

625

5.0

mW

mW/

°

C

Total Device Dissipation

@ TC = 25

°

C

Derate above 25

°

C

PD

1.5

12

Watts

mW/

°

C

Operating and Storage Junction

Temperature Range

TJ, Tstg

– 55 to +150

°

C

THERMAL CHARACTERISTICS

Characteristic

Symbol

Max

Unit

Thermal Resistance, Junction to Ambient

R

q

JA

200

°

C/W

Thermal Resistance, Junction to Case

R

q

JC

83.3

°

C/W

ELECTRICAL CHARACTERISTICS

(TA = 25

°

C unless otherwise noted)

Characteristic

Symbol

Min

Max

Unit

OFF CHARACTERISTICS

Collector – Emitter Breakdown Voltage (1)

(IC = –1.0 mAdc, IB = 0)

BF421
BF423

V(BR)CEO

–300
–250


Vdc

Collector – Base Breakdown Voltage

(IC = –100

m

Adc, IE = 0)

BF421
BF423

V(BR)CBO

–300
–250


Vdc

Emitter – Base Breakdown Voltage

(IE = –100

m

Adc, IC = 0)

BF421
BF423

V(BR)EBO

–5.0
–5.0


Vdc

Collector Cutoff Current

(VCB = –200 Vdc, IE = 0)

BF421
BF423

ICBO


–0.01

m

Adc

Emitter Cutoff Current

(VEB = –5.0 Vdc, IC = 0)

BF421
BF423

IEBO


–100

nAdc

1. Pulse Test: Pulse Width

v

300

m

s; Duty Cycle

v

2.0%.

Order this document

by BF421/D

SEMICONDUCTOR TECHNICAL DATA

CASE 29–04, STYLE 14

TO–92 (TO–226AA)

1

2

3

Motorola, Inc. 1996

COLLECTOR

2

3

BASE

1

EMITTER

background image

2

Motorola Small–Signal Transistors, FETs and Diodes Device Data

ELECTRICAL CHARACTERISTICS

(TA = 25

°

C unless otherwise noted) (Continued)

Characteristic

Symbol

Min

Max

Unit

ON CHARACTERISTICS

DC Current Gain

(IC = –25 mA, VCE = –20 Vdc)

BF421
BF423

hFE

50
50


Collector – Emitter Saturation Voltage

(IC = –20 mAdc, IB = –2.0 mAdc)

VCE(sat)

–0.5

Vdc

Base – Emitter Saturation Voltage

(IC = –20 mA, IB = –2.0 mA)

VBE(sat)

–2.0

Vdc

SMALL– SIGNAL CHARACTERISTICS

Current – Gain — Bandwidth Product

(IC = –10 mAdc, VCE = –10 Vdc, f = 20 MHz)

fT

60

MHz

Common Emitter Feedback Capacitance

(VCB = –30 Vdc, IE = 0, f = 1.0 MHz)

Cre

2.8

pF

background image

3

Motorola Small–Signal Transistors, FETs and Diodes Device Data

Figure 1. DC Current Gain

IC, COLLECTOR CURRENT (mA)

150

–1.0

15

h

FE

, DC CURRENT

GAIN

TJ = +125

°

C

+25

°

C

–55

°

C

VCE = –10 Vdc

20

30

50

70

100

–2.0

–3.0

–5.0

–7.0

–10

–20

–30

–50

–80

–100

C, CAP

ACIT

ANCE (pF)

Figure 2. Capacitances

VR, REVERSE VOLTAGE (VOLTS)

–0.1

100

50

20

1.0

Ccb

10

2.0

5.0

Cib

Figure 3. Current–Gain — Bandwidth Product

IC, COLLECTOR CURRENT (mA)

–50

–20

–10

–5.0

–2.0

100

60

40

30

20

0

TJ = 25

°

C

VCE = –20 Vdc

f

, CURRENT–GAIN — BANDWIDTH PRODUCT

(MHz)

T

–1.0

IC, COLLECTOR CURRENT (mA)

Figure 4. “On” Voltages

V

, VOL

TAGE (VOL

TS)

–1.0

0

VCE(sat) @ IC/IB = 10 mA

VBE @ VCE = –10 V

–0.8

–0.6

–0.4

–0.2

VCE, COLLECTOR–EMITTER VOLTAGE (VOLTS)

I C

, COLLECT

OR CURRENT

(mA)

BF423

Figure 5. Active Region — Safe Operating Area

BONDING WIRE LIMITATION
SECOND BREAKDOWN
LIMITATION

BF421

100

µ

s

1.0 ms

TJ = 150

°

C

1.5 WATT THERMAL
LIMITATION @ TC = 25

°

C

625 mW THERMAL
LIMITATION @ TA = 25

°

C

–500

–5.0

–10

–20

–50

–100

–200

–0.2 –0.5 –1.0 –2.0 –5.0 –10 –20

–50 –100 –200 –500 –1000

80

–100

–50

–20

–10

–5.0

–2.0

–1.0

–100

–3.0

–5.0

–10

–20 –30

–50

–100

–200 –300

1.0 s

background image

4

Motorola Small–Signal Transistors, FETs and Diodes Device Data

PACKAGE DIMENSIONS

NOTES:

1. DIMENSIONING AND TOLERANCING PER ANSI

Y14.5M, 1982.

2. CONTROLLING DIMENSION: INCH.
3. CONTOUR OF PACKAGE BEYOND DIMENSION R

IS UNCONTROLLED.

4. DIMENSION F APPLIES BETWEEN P AND L.

DIMENSION D AND J APPLY BETWEEN L AND K
MINIMUM. LEAD DIMENSION IS UNCONTROLLED
IN P AND BEYOND DIMENSION K MINIMUM.

R

A

P

J

L

F

B

K

G

H

SECTION X–X

C

V

D

N

N

X X

SEATING
PLANE

DIM

MIN

MAX

MIN

MAX

MILLIMETERS

INCHES

A

0.175

0.205

4.45

5.20

B

0.170

0.210

4.32

5.33

C

0.125

0.165

3.18

4.19

D

0.016

0.022

0.41

0.55

F

0.016

0.019

0.41

0.48

G

0.045

0.055

1.15

1.39

H

0.095

0.105

2.42

2.66

J

0.015

0.020

0.39

0.50

K

0.500

–––

12.70

–––

L

0.250

–––

6.35

–––

N

0.080

0.105

2.04

2.66

P

–––

0.100

–––

2.54

R

0.115

–––

2.93

–––

V

0.135

–––

3.43

–––

1

CASE 029–04

(TO–226AA)

ISSUE AD

STYLE 14:

PIN 1. EMITTER

2. COLLECTOR
3. BASE
