GF00.19-S-1100-01A

Assignment of connectors and sockets

MODEL 638

Item

Designation

Cable colors

Cable colors

Notes

X2

Wheel speed sensor connector

1

BR

br

2

ws

gn/ge

X6

Luggage compartment socket

1

br

2

rt/ge

X18

12 V 13-pin trailer socket (DIN 72570)

1

sw/ws

2

ge/sw

3

br

4

sw/gn

5

gr/rt sw

6

sw/vi ws

7

gr/sw ws

8

ws/rt

9

rt/bl

10

11

12

13

br

X27

Right side central locking contact plate

1/1

gr/rt

ws/rt

1/2

ws

bl/rt

2/1

gr/rt

ge/sw

2/2

ws

gn/sw

X28

Left side central locking contact plate

1/1

gr/rt

ws/rt

1/2

ws

bl/rt

2/1

gr/rt

ge/sw

2/2

ws

gn/sw

X35

Connector for central locking/D-pillar I

1

bl/rt

bl/rt

2

ws/rt

ws/rt

3

ge/sw

ge/sw

4

gn/sw

gn/sw

X36

Connector for central locking/D-pillar I

1

bl/rt

bl/rt

2

ws/rt

ws/rt

3

ge/sw

ge/sw

4

gn/sw

gn/sw

X37

Connector for central locking /rear door

1

bl/rt

bl/rt

2

ws/rt

ws/rt

3

ge/sw

ge/sw

4

gn/sw

gn/sw

X42

2-pin coolant temperature sensor connector

1

OM601 without

bl/vi

bl/vi

electronic idle
speed control

2

OM601 without

bl/gr

bl/gn

electronic idle
speed control

X50

Driver door connector 1

1

Outside mirror

sw/rt

sw/rt

heater

2

Front passenger

ws/rt

ws/rt

mirror adjustment

3

Front passenger

sw/gn

sw/gn

mirror adjustment,
up/down

4

Front passenger

bl/rt

bl/rt

mirror adjustment,
left/right

5

Outside mirror

BR

br

heater

rt / ge ws (rd / ye

6

Central locking with

rt / ge ws (rd /

convenience locking

wh)

ye wh)

system, power
window

6

Central locking

sw/ge

sw/ge

without
convenience locking
system, power
window

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

1

7

Central locking with

sw/ge ws

sw/ge ws

convenience locking
system, power
window

7

Central locking

rt/gn

rt/gn

without
convenience locking
system, front
passenger power
window

8

Central locking with

ge/sw ws

ge/sw ws

convenience locking
system, power
window

8

Central locking

sw/ge rt

sw/ge rt

without
convenience locking
system, front
passenger power
window

9

Central locking with

ge/rt sw

ge/rt sw

convenience locking
system, power
window

9

Central locking

sw/ge ws

sw/ge ws

without
convenience locking
system, front
passenger power
window

10

Central locking with

gn/sw ge

gn/sw ge

convenience locking
system, power
window

10

Central locking

without
convenience locking
system

11

Central locking with

gn/ge sw

gn/ge sw

convenience locking
system, front
passenger power
window

11

Central locking

without
convenience locking
system

12

Central locking with

gn/bl ws

gn/bl ws

convenience locking
system

12

Central locking with

gn/ge sw

gn/ge sw

convenience locking
system, front
passenger power
window

12

Central locking

without
convenience locking
system

13

Central locking with

gn/ws bl

gn/ws bl

convenience locking
system

13

Central locking with

gr/gn rt

gr/gn rt

convenience locking
system, front
passenger power
window

13

Central locking

without
convenience locking
system

14

X51

Passenger door plug connection

1

Power window with

rt/gn vi

rt/gn vi

convenience locking
system

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

2

1

Power window

sw/ge rt

sw/ge rt

without
convenience locking
system

2

Power window with

sw/gn gr

sw/gn gr

convenience locking
system

2

Power window

rt/gn

rt/gn

without
convenience locking
system

3

Power window with

gn/bl ws

gn/bl ws

convenience locking
system

3

Power window

sw/ge ws

sw/ge ws

without
convenience locking
system

4

Power window with

gn/ws bl

gn/ws bl

convenience locking
system

4

Power window

without
convenience locking
system

5

Outside mirror

BR

br

heater

6

Outside mirror

sw/rt

sw/rt

heater

7

Mirror adjustment

ws/rt

ws/rt

8

Front passenger

sw/gn

sw/gn

mirror adjustment,
up/down

9

Front passenger

bl/rt

bl/rt

mirror adjustment,
left/right

10

11

Only V-Class as of

rt/gn

rt/gn

1/1/98

11

Foldable outside

sw/gn

rt/gn

mirror

12

Only V-Class as of

br/gn

br/gn

1/1/98

12

Foldable outside

blue

bl

mirror

13

14

Power window with

gr/gn rt

gr/gn rt

convenience locking
system

X53

Left front door central locking connector

1

ge/sw

ge/sw

2

gn/sw

gn/sw

X54

Left front door central locking motor connector

1

sw

ws/rt

2

bl/rt

bl/rt

X55

Right front door central locking connector

1

ge/sw

ge/sw

2

gn/sw

gn/sw

X56

Right front door central locking motor connector

1

sw

ws/rt

2

bl/rt

bl/rt

X58

Main wiring harness/frame wiring harness I connector

1

Rear wiper

rt/vi

rt/vi

combination relay,
circuit 15

2

Rear wiper

sw/bl vi

sw/bl vi

combination relay,
diagnosis

3

Front wiper, circuit

black

sw

53

4

Front wiper, circuit

sw/gn gr

sw/gn gr

53B

5

Taillamp: rear

gr/rt

gr/rt

lamps

6

Radio with APS

ws/rt

ws/rt

7

Backup lamp

ws/rt

ws/rt

8

Right rear turn

sw/gn

sw/gn

signal lamp

9

License plate lamp

gr/gn rt

gr/gn rt

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

3

10

Rear window

vi/bl

vi/bl

washer system

11

Rear window heater

gr

gr

12

Rear window heater

gr/sw

gr/sw

function indicator

13

Rear window

vi/ws

vi / ws

washer system
pump

14

Left rear turn signal

sw/ws

sw/ws

lamp

15

Panel van, sliding

rt/ge

rt/ge

door interior lamp

15

Power outlet for

rt/ge

rt/ge

luggage
compartment/
interior lamp and
power outlet for
luggage
compartment

16

Passenger

br/sw

br/sw

compartment lamps

17

Rear left taillamp

gr/ws

gr/ws

18

Rear left brake

br/ge

br/ge

lining wear indicator

19

Center high-

sw/vi ws

sw/vi ws

mounted stop lamp

20

Spare lamp

bl/sw

bl/sw

21

Rear-end door

br/bl ws

br/bl ws

contact

X59

Main wiring harness/frame wiring harness II connector

1

Rear left ABS

ws

ws

2

Rear left ABS

br

br

3

ABS

ge

ge

3

Rear right ABS

sw

ge

4

Rear right ABS

BR

br

5

Air suspension,

rt/ge

rt/ge

circuit 30

6

Air suspension,

sw/bl

sw/bl

circuit 15

7

Air suspension,

sw/ge

sw/ge

circuit 50

8

Air suspension,

rt/bl

red/blue

circuit D+

9

Air suspension

sw/vi ws

sw/vi ws

10

Air suspension, V-

bl/sw

bl/sw

signal IN

11

Air suspension,

br/bl ws

br/bl ws

door contacts

12

Air suspension,

ws/bl

ws/bl

diagnosis

13

Air suspension,

br/vi

br/vi

service button

14

Air suspension,

rt/gn

rt/gn

fault

15

Air suspension

br/sw

br/sw

compressor relay

16

sw/bl

sw/bl

17

Left rear stop lamp

sw/vi ws

sw/gn ws

18

Right rear stop

ge/sw ws

ge/sw ws

lamp

19

Left rear fog lamp

br/vi

br/vi

20

Gasoline powered

rt/ge

rt/ge

car only

21

Backup assist,

bl/rt ws

bl/rt ws

PWM signal

22

Backup assist,

bl/ws

bl/ws

diagnosis

X60

Left instrument panel/main wiring harness I connector

1

Circuit 58K

gr/gn rt

gr/gn rt

2

Electric cigarette

rt/ge

rt/ge

lighter

3

Radio

sw/ge

sw/ge

4

Rear side door

br/bl ws

br/bl ws

contacts

4

M104 (AG), selector

sw/vi ws

sw/vi ws

lever

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

4

5

M104 (AG), selector

sw/ws

sw/ws

lever

5

Only panel van,

br/sw

br/sw

sliding door interior
lamp

6

br

br

7

Air suspension,

br/vi

br/vi

service button

8

Glove compartment

sw/bl gn

sw/bl gn

9

Rear window heater

gr

gr

10

Rear window heater

gr/sw

gr/sw

function indicator

11

Rear window heater

rt/bl

red/blue

12

up to 31.1.98

gn/sw

gn/sw

12

M111 and OM611,

sw/ws

sw/ws

ASR function key

13

up to 31.1.98

gn/ge

gn/ge

13

Radio, V-signal

bl/sw

gn/rt

13

Radio, V-signal

bl/sw

bl/sw

14

D-net or portable

sw/rt

sw/rt

CTEL

15

up to 31.1.98

sw/vi ws

sw/vi ws

15

M111 and OM611,

sw/gn

sw/gn

ASR function key

16

vi/ge

vi/ge

17

Climate control and

sw/gn

sw/gn

automatic
transmission for
commercial vehicles

17

Radio with APS

ws/rt

ws/rt

18

Climate control and

sw/gn ws

sw/gn ws

automatic
transmission for
commercial vehicles

X61

Left instrument panel/main wiring harness II connector

1

gn/rt

gn/rt

1

Automatic heater/

vi / ws

vi / ws

temperature control,
supply (circuit 15)

2

br/vi

br/vi

2

Automatic heater/

red/blue

red/blue

temperature control,
(circuit D+)

3

gr

gray

3

Automatic heater/

br

brown

temperature control,
(circuit 31)

4

M111 with climate

bl/ge

bl/ge

control

4

Automatic heater/

ws

ws

temperature control,
CAN H

5

Automatic heater/

gray

gr

temperature control,
CAN L

6

7

KLR

bl/ge gn

bl/ge gn

7

Stationary heater

bl/gn rt

bl/gn rt

8

Climate control or

gn/ge

gn/ge

climate control/
electronic idle
speed control or
climate control/
exhaust gas
recirculation

8

OM601 with climate

gn/ge

sw/bl ge

control and/or
automatic
transmission for
commercial vehicles

8

Air recirculation

BR

br

valve

9

M104 (climate

sw/gn ws

sw/gn

control)

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

5

9

M111 (climate

gn

gn

control)

9

OM601 with climate

gn

sw/bl ge

control and/or
automatic
transmission for
commercial vehicles

9

Air conditioning

br/vi

br/vi

pulsed valve

10

M111, OM601

br/bl

br/bl

10

M104

bl/ge gn

bl/ge gn

10

Heater booster

ge/gn

ge/gn

mode

11

KLR

sw/ws

sw/ws

11

Water pump

gn/rt

gn/rt

12

KLR

bl/gn

rt/gn

12

MRA

blue

bl

12

M111, OM611

bl/gn

bl/gn

compressor clutch

12

M104 compressor

bl/gn

rt/gn

clutch

13

MRA

sw/gn

sw/gn

13

Water separator

rt

rt

14

MRA

vi/ws

vi / ws

14

Auxiliary heater,

sw/gn

sw/gn

speed 1

15

MRA

rt/ge

rt/ge

15

OM611, cooling

br/ws

br/ws

module, speed 2

16

Water separator

rt/gn

rt/gn

17

MRA

gn/ws

gn / ws

17

Automatic

rt/gr

rt/gr

temperature control
supply, circuit 30

18

M104, engine

sw/gn ws

sw/gn ws

cooling system

19

Radio, EOBD

ge/gn

br/gn

20

Refrigerant

br/bl

br/bl

pressure sensor
ground for
automatic
temperature control

21

Pressure sensor

bl/rt

bl/rt

signal

22

Pressure sensor

gn/ws

gn/ws

X65

Group channel communication set connector

1

rt / br

2

br

X91

Battery (+) connector

1

black

sw

X92

Connector for main wiring harness/frame wiring harness

1

Left turn signal

sw/ws

sw/ws

III (trailer socket)

2

Rear fog light

ge/sw

ge/sw

3

Right turn signal

sw/gn

sw/gn

4

K 58R

gr/rt sw

gr/rt sw

5

Stop lamp

sw/vi ws

sw/vi ws

6

Circuit 58L

gr/sw ws

gr/sw ws

7

Tml. 30

rt/bl

rt/bl

8

X94

Connector for heater blower speed 1

1

sw/gn

sw/gn

1

sw/vi

sw/vi

X97

Plug connection of main wiring harness/engine I

1

M111, OM601,

white/blue

bl

OM611

1

M104

sw/rt

sw/bl gn

2

M104

ws/bl

ws/gr

2

M111,OM601

sw/ge

sw/ge

3

M104

br/gn

br

3

M111

BR

br

3

OM601

3

M611, air

br/vi

bl/gn

conditioning
compressor clutch

4

M104 (AG)

sw/ge

sw/ge

4

M111

sw

sw

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

6

4

OM601

bl/gr

bl/gr

4

M611

sw/bl

sw/bl

5

M111

bl/gn

bl/vi

5

M104

blue

bl

6

M104 up to 1.3.99

BR

rt / br

6

M104

rt/br

br

as of 1.3.99, up to
23.10.01

6

M104 as of

rt/gn

rt/gn

23.10.01

6

M111

bl/gn

bl/gn

6

M601

br/ge

br/ge

6

Secondary air pump

rt/ws

rt/ws

7

M104 up to

rt/gn

rt/gn

23.10.01

7

M104 as of

rt / br

br

23.10.01

7

M111, OM601

br/bl

br/bl

8

M111

bl/gr

bl/gr

8

M104 (AG) (B91
shielding)

9

M104 (AG)

ge

ws

10

M104 (AG)

sw

ge

11

M104 (AG)

sw

gr

12

M104 (AG)

ge

bl

13

M104 (AG) (B92
shielding)

14

M104 (AG)

sw

sw

15

M104 (AG)

sw/ws

sw/ws

16

M104 (AG)

ge

ge

17

M104 (AG)

gn

gn

18

M104 (AG)

red

rt

19

M104 (AG)

bl/ws

bl/ws

20

M104 (AG)

gn/ws

gn/ws

21

M104 (AG)

gray

gr

22

M104 (AG)

blue

bl

23

M104 (AG)

rt/ws

rt/ws

X98

Main wiring harness/engine II connector

1

M111

bl/vi

bl/vi

1

M104, intake

vi/br

vi/bl

manifold valve
adjustment

2

M104, crankcase

br/gn

br

heater

2

M111, air

blue

bl/gn

conditioning
compressor clutch

3

M104

rt/ws

rt/ws

4

M104, throttle valve

black

sw

actuator

5

M104, throttle valve

sw/ws

sw/ws

actuator

6

M104, throttle valve

ws

ws

actuator

7

M104, throttle valve

sw/gr

sw/gr

actuator

8

M104, ignition coil 1

black

sw/gr

9

M104, ignition coil 1

sw/vi

sw/vi

10

M104, throttle valve

gn/ws

gn/ws

actuator

11

M104, throttle valve

br/bl

br/bl

actuator

12

M104, throttle valve

rt/gr

rt/gr

actuator

13

M104, ignition coil 1

sw/blue

sw/bl

14

M104, water pump

br/gn

br

15

M104, EGR pulsed

gn/gr

gr/gn

valve

16

M104

17

M104, ignition coil 1

brown

br

18

M104, ignition coil 1

sw/br

sw/br

19

M104, water pump

rt/sw

gn/rt

20

M104, camshaft

sw/rt

sw/gr

position sensor

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

7

21

M104, camshaft

ws/rt

ws/rt

position sensor

22

M104

bl/ws

bl/ws

23

M104

blue

bl

24

M104, camshaft

br/bl

br/bl

position sensor

25

M104, intake air

bl/gn

bl/gn

temperature sensor

26

M104

br/rt

br/rt

27

M104, double-

br/bl

br/bl

temperature sensor

28

M104, intake air

br/bl

br/bl

temperature sensor

X99

Connector for roof wiring harness/main wiring harness I

1

sw/rt

sw/rt

2

KSA

gr/gn rt

gr/gn rt

3

M111, OM601

sw/bl gn

sw/bl gn

3

Radio remote

bl/vi

bl/vi

control

4

KSA

br/ge sw

br/ge sw

5

KSA

bl/gn rt

bl/gn rt

5

Central locking,

gr/gn

gr/gn

diagnosis

5

Convenience

bl/gn rt

gr/gn

locking system,
diagnosis

6

Rear-end door

br/bl ws

br/bl ws

contact switch

7

Taxi

br/sw

br/sw

8

Convenience

ws/rt

ws/rt

locking system as
of 1.1.98

X100

Connector for roof wiring harness/main wiring harness II

1

up to 31.1.98

sw

sw

2

up to 31.1.98

rt/ge

sw

X103

Main harness / airbag connector

1

Tml.15

rs/ge

rt/gn

2

Indicator lamp

ge

ge

3

Diagnosis

ge/sw

ge/sw

4

Without airbag

BR

sw/rs

4

with airbag (crash

sw/rs

sw/rs

signal)

X105

Connector for roof wiring harness/instrument panel

1

Passenger

br/sw

br/sw

compartment lamp
switch

2

KSA

br/ws

br/ws

2

CL

ws/sw

ws/sw

3

Left rear speaker

gray

gray

4

Left rear speaker

gr/rt

gr/sw

5

Right rear speaker

vi

vi

6

Right rear speaker

vi/ws

vi/ws

7

M111, OM601 up to

white

white

31.1.98

7

Only V-Class

sw/rt

sw/rt

7

CL

ws/gn

ws/gn

8

M111, OM601 up to

ws/sw

ws/sw

31.1.98

8

Only V-Class

rt/gn

rt/gn

9

M111, OM601 up to

gn

green

31.1.98

9

Only V-Class

br/gn

br/gn

10

up to 31.1.98

gn/sw

gn/sw

10

Heater blower

sw/vi

sw/vi

speed 1

11

up to 31.1.98

rt/gr

rt/gr

11

Auxiliary heater

sw/gn

sw/gn

speed 1

12

D-net or portable

rt / br

rt / br

CTEL

13

up to 31.1.98

sw/rt

sw/rt

14

Anti-theft alarm

gr/rt

gr/rt

system, panic
switch

15

Anti-theft alarm

gn/ge

gn/ge

system, panic
switch

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

8

16

Anti-theft alarm

rt/sw

rt/sw

system, panic
switch

17

KSA

rt/ge

rt/ge

17

CL

ws/bl

ws/bl

18

KSA

bl/ge

bl/ge

18

CL

ws/rt

ws/rt

X106

Connector for automatic transmission position switch

A

AGN

ws/bl

ws/bl

B

AGN

ws/bl rt

ws/bl rt

C

AGN

ws/ge

ws/ge

D

AGN

ws/gr

ws/gr

E

AGN

sw/ws

sw/ws

F

AGN

G

AGN

ws/rt

ws/rt

H

AGN

ws/rt

ws/rt

I

AGN

sw/ge

sw/ge

K

AGN

sw/gn

sw/gn

X107

Left seat connector

1

ws

ws

2

ge

ge

3

blue

bl

4

gn

gn

5

br/ws

br/ws

6

BR

br

7

sw/ge

sw/ge

8

br/bl

br/bl

X107.1

Left seat heated cushion connector

1

BR

br

2

blue

sw

3

blue

sw

4

BR

br/sw

X108

D-net telephone connector

1

up to 31.1.98

ge/sw

ge/sw

2

up to 31.1.98

bl/ge

bl/ge

3

up to 31.1.98

bl/gn

bl/gn

4

up to 31.1.98

rt / br

rt/gr

5

D-net up to 31.1.98

sw/rt

rs/ge gn

5

Portable CTEL up

sw/rt

sw/rt

to 31.1.98

6

up to 31.1.98

brown

brown

X109

Right seat connector

1

ws

ws

2

ge

ge

3

blue

bl

4

gn

gn

5

br/ws

br/ws

6

BR

br

7

sw/ge

sw/ge

8

br/bl

br/bl

X109.1

Right seat heated cushion connector

1

BR

br

2

blue

sw/ge

3

blue

sw/ge

4

BR

br/bl

X112

Connector for frame wiring harness/rear-end door I

1

License plate lamp

gr/gn rt

gr/gn rt

2

3rd stop lamp

sw/vi ws

sw/vi ws

3

4

5

Rear window wiper

sw/vi

sw/vi

6

Rear window wiper

sw/rt

sw/rt

X113

Main wiring harness/airbag clock spring contact

1

ge

br/ge

connector

2

black

gr/sw

X114

Immobilizer connector

1

OM601

brown

brown

2

OM601

3

OM601

gray

gray

4

OM601

sw/gr

rs/rt

5

OM601

white

white

6

OM601

gn

green

X115

Drive switch/airbag connector

1

rt/vi

rs/ge

X116

Voltage supply connector for left seat adjustment/heated

1

rt/ws

rt/sw

seats

2

brown

brown

X117

Voltage supply connector for seat adjustment

1

rt/sw

rt/sw

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

9

2

brown

brown

X120

Connector for coolant temperature+electronic idle speed

1

OM601 with

bl/vi

bl/vi

control sensors

electronic idle
speed control

2

OM601 with

bl/gr

bl/gn

electronic idle
speed control

3

OM601 with

br/bl

br/bl

electronic idle
speed control

4

OM601 with

br/ws

br/ws

electronic idle
speed control

5

OM601 with

br/gr

sw/gr

electronic idle
speed control

6

OM601 with

electronic idle
speed control

X121

Backup assist connector I

1

Left rear RFH4

bl/ge

bl/ge

sensor

2

Sensor RFH3

bl/gn

bl/gn

3

Sensor RFH2

bl/vi

bl/vi

4

Right rear RFH1

bl/sw

bl/sw

sensor

5

Left rear RFH4

rt/ge

rt/ge

sensor

6

Left rear RFH4

blue

blue

sensor

X123

Driver door connector 2

1

Left vent window

gn/ge

gn/ws bl

switch

2

Left vent window

gr/sw

gr/sw

switch

3

Right vent window

sw/bl ge

sw/bl ge

switch

4

Right vent window

sw/bl rt

sw/bl rt

switch

5

Vent window

br/ws

br/ws

locking switch

6

Convenience

red

red

locking system,
driver door lock
open

7

black

sw

8

Driver door lock

brown

brown

switch

9

Only V-Class as of

rt/gn

rt/gn

1.1.98

9

Foldable front

sw/gn

sw/gn

passenger outside
mirrors

10

Only V-Class as of

br/gn

br/gn

1.1.98

10

Foldable front

blue

blue

passenger outside
mirrors

11
12
13

Left vent window

gr/gn rt

gr/gn rt

switch

14

Right vent window

gr/gn rt

gr/gn rt

switch

X124

Connector for main wiring harness/frame wiring harness

1

Rear wiper

rt/gn

rt/gn

IV

combination relay
supply (circuit 30)

X125

Contact spiral / airbag wiring harness connector

1

vi

vi

2

gn

green

X126

Connector for ignition squib line R2/ airbag wiring

1

bl/gn

bl/gn

harness

2

br/gn

br/gn

X130

Main wiring harness/engine III (air conditioning)

1

KLR

sw/gn

sw/gn

connector

2

KLR

bl/rt

bl/rt

3

KLR

bl/gn

bl/gn

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

10

3

Secondary air pump

rt/ws

rt/gn

4

KLR

sw/gn

sw/gn

4

Secondary air pump

brown

brown

5

KLR

sw/gn

sw/gn

5

Low pressure

ws/bl

ws/bl

switch

6

KLR

brown

brown

5

High pressure

ws/ge

ws/ge

switch

7

KLR

blue

blue

8

KLR

br/ws

br/ws

X131

Connector for roof wiring harness/main wiring harness III

1
2
3

4

5

Anti-theft alarm

bl/ws

bl/ws

system, horn

5

Anti-theft alarm

rt/gn

sw/bl

system 2,
rechargeable horn

6

Anti-theft alarm

ws/rt

ws/rt

system, left turn
signal lamp

7

Anti-theft alarm

sw/gn

sw/gn

system, right turn
signal lamp

8

Anti-theft alarm

br/ws

br/ws

system, front door
contacts

9

Anti-theft alarm

sw/blue

sw/bl

system, hood

10

Anti-theft alarm

gr/bl

gr/bl

system up to
31.1.98

11

Anti-theft alarm

rt/gr

rt/gr

system up to
31.1.98

11

with airbag, as of

sw/rs

sw/rs

1.2.00 (crash
signal)

12

Anti-theft alarm

gr/gn

gr/gn

system, diagnosis

13

Anti-theft alarm

sw/rt

sw/rt

system, circuit 15

14

Anti-theft alarm

sw/rt ws

sw/rt ws

system, trailer ID

15

16

Anti-theft alarm

br/bl ws

br/bl ws

system, front door
contacts

17

ATA

gr/gn rt

gr/gn rt

17

Convenience

bl/sw

bl/sw

locking system,
central locking (V-
signal)

18

Anti-theft alarm

rt/gn

rt/gn

system 2,
rechargeable horn

X138

Left passenger compartment socket

1

br

2

red/blue

X139

Right passenger compartment socket

1

br

2

red/blue

X141

Connector for frame wiring harness/rear door II

1

Heated rear window

ge

ge

X144

Roof wiring harness/roof sign connector (taxi)

1

NF

2

NF

X145

Connector, main wiring harness/taxi console I

1

rt

2

br

X146

Connector, main wiring harness/taxi console II

1

ws/ge

2

ws/sw

3

ws/bl

4

rt/ws

5

rt/ge

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

11

6

red/blue

7

rt/gr

8

Taxi switch

rt/gn

9

bl/sw

10

Taximeter

sw/bl gn

10

as of 1.2.00

vi / ws

11

Taxi switch

gr/gn rt

12

13

Left high beam

ws

14

Left high beam

ws/gn

15

Right high beam

ge

16

Right high beam

ge/ws

17

Two-way radio

br/gn

18

X147

Diagnostic socket/airbag wiring harness connector

1

ge/sw

ge/sw

X154

Connector, roof wiring harness/main wiring harness (taxi)

1

Taxi roof sign

nf

rt/gn

2

Taxi roof sign

NF

brown

X160

Transponder connector

1

bl/sw

bl/sw

2
3

bl/ws

bl/ws

X161

Driver reading lamp connector

4

bl/ge

bl/ge

9

sw/gn ws

sw/gn

X168

Refrigerator box connector (2-pin)

1

br

2

red/blue

X170

Hand brake switch connector, RHD

1

RL

br/sw

br/sw

2

RL

br

br

X173

Connector for additional caravan wiring harness

1

gr/rt

2

gr/sw

3

gray/brown

4

rt

5

sw

6

X175

Injectors connector

1

M104, injection

vi

vi

valve 1

2

M104, injection

vi / gn

vi / gn

valve 2

3

M104, injection

vi/rt

vi/rt

valve 3

4

M104, injection

vi/bl

vi/bl

valve 4

5

M104, injection

vi/gr

vi/gr

valve 5

6

M104, injection

vi/ge

vi/ge

valve 6

7

M104

rt/ge

rt/ge

8

M104

rt/ge

rt/ge

9

M104

10

M104

X177

Caravan connector

1

gr/gn rt

2

sw

3

Outside

br/ge

temperature sensor

4

Outside

br

temperature sensor

5

rt/bl

6

rt/ge

X178

Connector for caravan cutoff relay

1

red/blue

2

br

X179

Connector for caravan speaker

1

Right rear speaker

rt/gn

vi

2

Right rear speaker

br/sw

vi / ws

3

Left rear speaker

bl/gn

gr

4

Left rear speaker

br/rt

gr/sw

X180

Connector for instrument panel/main wiring harness

1

ws

ws

subwoofer

2

ws/sw

ws/sw

3

gn

gn

4

gn / sw

gn/sw

X182

Tachograph sensor connector

1

AG (M104)

sw

sw

2

AG (M104)

BR

br

3

AG (M104)

bl

bl

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

12

4

AG (M104)

ws

ws

X183

Main wiring harness/engine IV connector

A

EDS6

bl/vi

bl/vi

B

EDS6

bl/gn

bl/gn

C

EDS6

brown/blue

br/bl

D

EDS6

sw/rt

sw/rt

E

EDS6

gn / rt

gn/rt

F

EDS6

gn / ws

gn/ws

G

EDS6

gn / sw

gn/sw

H

EDS6

br/ws

br/ws

X185

CTEL [TEL] connector

1

D-net or portable

ge/sw

ge/sw

CTEL

2

D-net or portable

bl/ge

bl/ge

CTEL

3

D-net or portable

bl/gn

bl/gn

CTEL

4

D-net or portable

rt / br

rt/gr

CTEL

5

D-net or portable

sw/rt

rs/ge gn

CTEL

6

D-net or portable

BR

br

CTEL

X186

Connector for frame wiring harness/rear-end door III

1

sw/vi ws

sw/vi ws

2

see pin 4

sw/vi

sw/vi

3

see pin 5

sw/rt

sw/rt

4

Replaces pin 2

sw/vi

sw/vi

5

Replaces pin 3

sw/rt

sw/rt

5

Right windshield

sw/vi

sw/vi

wiper for rear
window

6

Right windshield

sw/rt

sw/rt

wiper for rear
window

X187

Connector for frame wiring harness/rear door IV

1

Right rear window

ws

ws

defroster

X188

Left instrument panel/main wiring harness III connector

1

AG

gn / sw

gn/sw

2

AG

gn/ge

gn/ge

3

AG

sw/ws

sw/ws

4

AG

sw/vi ws

sw/vi ws

5

AG

6

AG

X191

Connector for central locking of hinged rear door

1

KSA

ws/rt

ws/rt

2

KSA

bl/rt

bl/rt

X192

Connector for central locking of hinged rear door

1

KSA

ge/sw

ge/sw

2

KSA

gn / sw

gn/sw

X194

EDW2 connector

1

ATA

ge

ge

2

ATA

ws

ws

3

ATA

br/ws

br/ws

4

Rear air

red/blue

rt/bl

conditioning

5

Rear air

rt/ge

rt/ge

conditioning

6

Rear air

gn / ws

gn/ws

conditioning

X195

Connector for CDI control unit

8

sw/ge

X197

APS processor connector

2

APS

bl/gnrt

bl/gnrt

3

APS

gn / sw

gn/sw

4

APS

gr/rt

gr/rt

X198

Connector for automatic child seat recognition check

1

rt/ge

rs/ge

2

gn

gn

X202

Connector for automatic child seat recognition sensor

1

rs/ge

rs/ge

(ACSR)

2
3

br/ws

br/ws

4

BR

br

X203

Right seat heated cushion connector

1

BR

br

2

blue

sw/ge

3

blue

sw/ge

4

BR

br/bl

X204

Left seat heated cushion connector

1

BR

br

2

blue

sw

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

13

3

blue

sw

4

BR

br/sw

X221

Connector for water separator fill level sensor

1

BR

br

2

rt/gn

rt/gn

3

rt

rt

X224

Rear air conditioning connector

1

rt/bl

2

rt/ge

3

gn / ws

4

br

X229

Connector for preinstallation of el. roof sign

1

rt/bl

2

br

Авторское

право

Daimler AG 01.11.10 G/06/08.

Актуализация

данной

распечатки

из

WIS

службой

учёта

и

внесения

изменений

не

производится

.

Страница

14
