Ordering number:EN5683

SB05-18V

Schottky Barrier Diode

180V, 500mA Rectifier

Specifications

Absolute Maximum Ratings

at Ta = 25˚C

Electrical Characteristics

at Ta = 25˚C

Package Dimensions

unit:mm

1289

[SB05-18V]

Applications

· High frequency rectification (switching regulators,

converters, choppers).

Features

· Low forward voltage (V

F

max=0.85V).

· Fast reverse recovery time (t

rr

max=20ns).

· Low switching noise.
· Low leakage current and high reliability due to

highly reliable planar structure.

1:Anode

2:Cahode

3:No Contact

SANYO:NMP
