GEO STORM 1990 1993

background image

Copyright 2002-2004 Triple S Customs

GEO STORM 1990-1993

V

V

E

E

H

H

I

I

C

C

L

L

E

E

W

W

I

I

R

R

I

I

N

N

G

G










background image

Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION 1990 Geo Storm

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

WHITE/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition Harness

SECOND IGNITION WIRE

BLACK/RED

Ignition Harness

ACCESSORY WIRE

BLUE

Ignition Harness

STARTER WIRE

BLACK/WHITE

Ignition Harness

PARKING LIGHTS (+)

GREEN/RED

Blue Connector At Fuse Box

DOOR TRIGGER (-)

GRAY/WHITE

At Fuse Box

TRUNK TRIGGER (-)

BLACK/RED

At Light In Trunk

TACHOMETER WIRE

BLACK/RED

At Ignition Coil

BRAKE WIRE (+)

GREEN/YELLOW

At Brake Pedal Switch

HORN TRIGGER (-)

GREEN

Harness At Steering Column

WIRING INFORMATION 1991 Geo Storm

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

WHITE/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition Harness

SECOND IGNITION WIRE

BLACK/RED

Ignition Harness

ACCESSORY WIRE

BLUE

Ignition Harness

STARTER WIRE

BLACK/WHITE

Ignition Harness

PARKING LIGHTS (+)

GREEN/RED

Blue Connector At Fuse Box

DOOR TRIGGER (-)

GRAY/WHITE

At Fuse Box

TRUNK TRIGGER (-)

BLACK/RED

At Light In Trunk

TACHOMETER WIRE

BLACK/RED

At Ignition Coil

BRAKE WIRE (+)

GREEN/YELLOW

At Brake Pedal Switch

HORN TRIGGER (-)

GREEN

Harness At Steering Column

WIRING INFORMATION 1992 Geo Storm

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

WHITE/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition Harness

SECOND IGNITION WIRE

BLACK/RED

Ignition Harness

ACCESSORY WIRE

BLUE

Ignition Harness

STARTER WIRE

BLACK/WHITE

Ignition Harness

PARKING LIGHTS (+)

GREEN/RED

Blue Connector At Fuse Box

DOOR TRIGGER (-)

GRAY/WHITE

At Fuse Box

TRUNK TRIGGER (-)

BLACK/RED

At Light In Trunk

TACHOMETER WIRE

BLACK/RED

At Ignition Coil

BRAKE WIRE (+)

GREEN/YELLOW

At Brake Pedal Switch

HORN TRIGGER (-)

GREEN

Harness At Steering Column

WIRING INFORMATION 1993 Geo Storm

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

WHITE/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK/YELLOW

Ignition Harness

SECOND IGNITION WIRE

BLACK/RED

Ignition Harness

ACCESSORY WIRE

BLUE

Ignition Harness

STARTER WIRE

BLACK/WHITE

Ignition Harness

PARKING LIGHTS (+)

GREEN/RED

Blue Connector At Fuse Box

DOOR TRIGGER (-)

GRAY/WHITE

At Fuse Box

TRUNK TRIGGER (-)

BLACK/RED

At Light In Trunk

TACHOMETER WIRE

BLACK/RED

At Ignition Coil

BRAKE WIRE (+)

GREEN/YELLOW

At Brake Pedal Switch

HORN TRIGGER (-)

GREEN

Harness At Steering Column
