Management node. The only executable program required on a Computer used for hosting a

MySQL Cluster management node isthe management server program

ndb_mgmd.exe. However, in

order to administer the MySQL Cluster once it has been started, you should also install the MySQL

Cluster management Client program ndb_mgm.exe on the same machinę as the management sen/er.

Locate these two programs on the machinę where you downloaded and extracted the

no-install

archive; this should be the directory C: \mysql\bin on the SQL node host. Create the directory C:

\mysql\bin on the Computer havingthe IP address 192.168.0.10, then copy both

programs to this

directory.

You should now create tvso configuration files for use by ndb_mgmd.exe:

1.    A local configuration file to supply configuration data specific to the management node itself.

Typically, this file needs only to supply the location of the MySQL Cluster global configuration file (see item 2).

To create this file. start a new text file in Notepad or another text editor, and enter the

following

information:

[mysql_cluster]

•    Options for management node process config-file-C:/mysql/bin/config.ini

Save this file as the plaintext file C: \mysql\bin\my. ini.

2.    A global configuration file from which the management node can obtain configuration information

governing the MySQL Cluster as a whole. At a minimum, this file must contain a section for each

node in the MySQL Cluster, and the IP addresses or hostnames for the management node and

all data nodes (HostName configuration parameter). It is also advisable to include the following additional information:

•    The IP address or hostname of any SQL nodes

•    The data memory and index memory allocated to each data node (DataMemory [2204] and

IndexMemory [2205] configuration parameters)

•    The number of replicas, using the NoOf Replicas [2202] configuration parameter (see

Section 17.1.2, “MySQL Cluster Nodes, Node Groups, Replicas, and Partitions")
