F G 093

background image

We reserve the right to change the design of our products without incurring an obligation to modify previously manufactured product.

TO:

ALL HYSTER INDUSTRIAL TRUCK DEALER PRINCIPALS, SERVICE MANAGERS,
PARTS MANAGERS AND TRAINING MANAGERS

Subject: Voltage Conversion for SEM Controllers (Separately Excited Motors)

Description:

D114 and F108 series units are designed to operate efficiently on either 36 or 48 volt
batteries. To convert the voltage of a truck, the following parts must be used. There are no
other changes required.

For Trucks Equipped with SEM Controller –

Starting with S/N’s:

DII4V03842W to also include D114V03719V and D114V03837W

F108V15841W to also include F108V14946V and F108V15838W

Parts Required

From 48 to 36 Volts

From 36 to 48 Volts

Battery connector

195293

195296

Horn

1360566

1360568

Warranty Reimbursement:

The information contained herein is for information purposes only and will not be considered
for warranty reimbursement.

PARTS - SERVICE

GRAM

FG00093

6/7/99

D114: E25-40XMS
F108: E45-65XMS
