F [kHz] | 2Uwe [V] | 2Uwy [V] | Δt [ms] | KU [-] | KUdB [dB] | Φ [o] | ||||||||
0.03 | 13.8 | 0.424 | -7.6 | 0.0307 | -30.2503 | 82.08 | ||||||||
0.1 | 13.9 | 1.32 | -2 | 0.0950 | -20.4488 | 72 | ||||||||
0.2 | 13.9 | 2.42 | -0.8 | 0.1741 | -15.1840 | 57.6 | ||||||||
0.75 | 13.9 | 4.48 | -0.04 | 0.3223 | -9.8347 | 10.8 | ||||||||
2 | 14.2 | 4.24 | -0.036 | 0.2986 | -10.4984 | 25.92 | ||||||||
10 | 14.2 | 1.39 | 0.02 | 0.0979 | -20.1855 | -72 | ||||||||
15 | 14.2 | 0.928 | 0.014 | 0.0654 | -23.6948 | -75.6 | ||||||||
33 | 14.1 | 0.448 | 0.0062 | 0.0318 | -29.9588 | -73.656 | ||||||||
50 | 14 | 0.32 | 0.0042 | 0.0229 | -32.8196 | -75.6 | ||||||||
75 | 14 | 0.198 | 0.0032 | 0.0141 | -36.9893 | -86.4 | ||||||||
100 | 14 | 0.15 | 0.0022 | 0.0107 | -39.4007 | -79.2 | ||||||||
150 | 13.8 | 0.102 | 0.00164 | 0.0074 | -42.6256 | -88.56 | ||||||||
200 | 13.9 | 0.0778 | 0.0012 | 0.0056 | -45.0407 | -86.4 | ||||||||
250 | 13.9 | 0.064 | 0.00096 | 0.0046 | -46.7367 | -86.4 | ||||||||
275 | 13.9 | 0.0576 | 0.00092 | 0.0041 | -47.6518 | -91.08 | ||||||||
300 | 13.8 | 0.0528 | 0.00084 | 0.0038 | -48.3449 | -90.72 | ||||||||
350 | 13.9 | 0.046 | 0.00072 | 0.0033 | -49.6051 | -90.72 | ||||||||
400 | 13.9 | 0.04 | 0.00064 | 0.0029 | -50.8191 | -92.16 | ||||||||
450 | 13.8 | 0.036 | 0.00056 | 0.0026 | -51.6715 | -90.72 | ||||||||
500 | 13.8 | 0.0344 | 0.00048 | 0.0025 | -52.0664 | -86.4 | ||||||||
