Dear Mr. Zurek,

thank you very much for your mail and your interest in our technology.

I apologize for not reacting on your inquiry, which is due to holydays in our team.

In which application do you plan to install an ORC-unit?

Is it a Biomass-boiler, a stationary engine or a heat source within your production facilities?

Can you send us some data of the heat source? (temperatures (°C), volume-flows (kg/h), available heat
(kWth)

Data sheets in case of stationary engines would also be fine.

Please understand, that we cannot give budget prices without knowing the characteristics of the heat source,
which determines the dimensioning of the heat exchangers.

Thank you in advance for your support.

Mit freundlichen Grüßen/Best regards

Jochen Fink
Director Sales & Operation

Dürr Cyplan Ltd.

Carl-Benz-Str. 34
74321 Bietigheim-Bissingen
Germany

Phone [phone]
Fax [phone]

E-mail

[e-mail]

Internet

www.durr-cyplan.com

Geschäftsführer: Frank Eckert, Jochen Fink

Sitz der Gesellschaft: Bietigheim-Bissingen, eingetragen im Amtsgericht Stuttgart HRB 738957

Bitte denken Sie an die Umwelt, bevor Sie diese E-Mail drucken / Please think about our Environment before printing this e-mail

Von:

Radek Żurek [mailto:[e-mail]]

Gesendet:

Montag, 3. September 2012 14:04

An:

Info; Fink, Jochen

Betreff:

Instalation 300 kW - offert

Hello,
I wrote to you 2 weeks ago. I didn't have any answer from you so, I have to try again.
I represente one of the polish tabacco firm locate near of Warsaw. We want to build instalation ORC
technology.
Can you prepare us price offert to completly instalation of 300 KW power?
I'm interesting in 300 kW ORC in 3 kinds :

- High-temperature systems without heat utilization and price for it
- High-temperature systems with heat utilization and price for it

- Low temperature systems without heat utilization and price for it

How long I will wait for this instalation? Can you mount it in Poland or in Germany?

Best regards
Radosław

Żurek

Mechanicall Engineer
Sanzut Sp. zo.o.
mobile: [phone]

We only offer 90-140 C IT250. The price is $500,000 USD.

Below is some general information on what equipment we provide and
operational parameters.

INFINITY TURBINE OFFERS THE FOLLOWING:

1. Complete ORC systems: Infinity offers the ITmini Turbine, ITxr
Turbine, ITxa Large Turbine, IT10xr ORC System and IT50 ORC System in
complete assembled versions ready to operate. We can also do a custom
build for the IT250.

2. Build Your Own Brand: Infinity is now offering a unique program
that allows you to order the turbine from us, then complete the
package with your own components. We supply the parts list, assembly
manual and operations manual with consulting to answer your questions.
This allows you to brand and sell your own equipment.

3. Parts / Plans / Consulting: Infinity offers the ITmini turbine,
ITxr turbine, ITxa turbine only, and the IT01, IT10, IT50, IT250
turbine generator ORC full build packages. We also offer plans and
consulting for the ITmini, ITxr (IT10), IT50 and IT250 units. In
addition, we can offer training, start-up and commissioning. And
starting now, we are offering experimental S CO2 Brayton Cycle
Systems.

4. Innovation Leading Designs: Infinity updates its turbines every
six months, so that you have the most efficient turbine available.
Within a year, we will be offering smaller turbines that utilize R744
(Supercritical CO2) that are 40 percent efficient and use simple dry
ice (CO2) to load as the working fluid. This is a huge cost savings
over conventional refrigerants (R134a / R245fa).

GENERAL POWER CALCULATIONS (Using R134a and R245fa as working fluid)

How do I figure out the amount of power I can generate from my waste heat ?

Take your waste heat, in the form of Btu/hr and divide by 40,000 Btu
(this is a general figure and can range from 30,000 btu to 50,000
btu).

For example: Total waste heat 3,000,000 Btu / 40,000 Btu = 75 kWe / hr
Note: 3,000,000 btu (3,412 btu/kWt) = 879 kWthermal

If I have a hot liquid flow of around (100 C) 212 F, how do I
calculate the amount of power I can generate ? Take your hot liquid
flow rate in gpm, and divide by 2-3.

For example: Total waste heat (568 L) 150 gpm / 2 or 3 = 50 to 75 kW/hr

Why are the examples not totally exact ? There are a great number of
factors including type of refrigerant used, the temperature of the
condenser flow water, etc. So we prefer you work with a range of
possible output.

BUILD YOUR OWN BRAND

Build Your Own Brand:

If you would like to build your own brand around our turbine, you may
purchase our plans and consulting to build out your system with your

brand.

For more information please click on this link:

http://www.infinityturbine.com

We're now promoting the Build-Your-Own-Brand display program on our
website. Under this program, you may purchase space on our website for
your company and brand if you are using our Infinity Turbine as the
core expander for your equipment line. The advantage to utilizing the
Infinity Turbine website is that you already have over three years of
exposure and Google Ad links.

This is a fee based system, but can give you the competitive advantage
to provide immediate marketing of your system using our website as
your launch pad:

http://www.infinityturbine.com/ORC/Market_and_Display_Your_Brand_Here.html

HEAT RATE AND EFFICIENCY

Note: If you have to pay for your heat or fuel, the ORC process does
not make any financial sense to install. ORC is a bottoming cycle,
and designed for waste heat (free heat).

Heat Rate: In general waste heat is recovered via thermal oil, water
or glycol solution. Our ORC systems can use heat in the range of
80-130 C input heat. If it is lower than 100 deg C, then figure on
40,000 BTU / kWe. The heat rate is better as temperature goes up.
The smaller a system (1-10 kw) the heat rate is even higher.

Our standard system is the R 245fa (using Genetron) system which
operates between 80-130 C within our parameters. This represents 8-11
percent efficiency.

Input Fluid: Using water, glycol or thermal oil (for higher temps)
you can expect a flow rate of 2-3 gpm (7.6 to 11.4 liters/min) per
rated kW. So a 60 kW rated system needs around 150 gpm. Expect a
temperature drop of 15-20 C between the input and exit of the
evaporator.

Condenser: The standard systems use a water cooled condenser. Expect
a temperature increase of 5-10 C from the input and exit water flow.

2012 Turbine Advanced Design Features

1. Smaller design
2. Magnetic disc coupling lead
3. Magnetic disc coupling follower ( 10 mm for ITmini, 17 mm for ITxr
shaft bore - attach to direct drive your DC generator)
4. More efficient turbine rotor which allows more start-up torque
5. Ceramic bearings
6. Stainless steel turbine rotor and housing liner
7. Multiple 3/8 inch threaded bores for attach points to mount turbine
8. Larger single exit port (allows the turbine to produce more power)
9. Improved bearing pocket design
10. Turbines in mid 2012 designed for Supercritical CO2 operation.

A. STANDARD ORC TURBINES AND SYSTEMS FROM INFINITY TURBINE CURRENTLY
IN PRODUCTION (All prices in USD and do not include shipping/handling)
:

ITmini - Turbine Only - Magnetic Coupling - 2012 Version:

Turbine Mag Coupling: Please see price sheet for current prices:
( 02_Price_List.pdf )
Power: Can drive a 600 - 3,000 watt DC direct drive generator with 10
mm shaft.
Power Potential: Our new 2012 version has a 1.5 inch (NPT) exit port.
This will allow the ITmini, with proper flow and pressure, to run up
to a 3 kW high speed DC generator.
Initial Testing: Mass Flow Per kW System = 7 lbs/min (3.18 kg/min) or
.117 lbs/sec (.053 kg/sec)
Inlet Port: 3/8 inch NPT
Outlet Port: 1.5 inch NPT
Working Fluid: R134a, R245fa, and compressed air. We have not tried
other pressurized gases.
Pressure: 50-300 psi working pressure (up to 20 bar, 2 Mpa, 2,000 Kpa
tested). We have not tried higher pressures in operation.
RPM's: 5,000-20,000
Magnetic Coupling: Power out is function of RPM. More flow and
pressure, more RPM. The magnetic coupling is good to 140 C in
temperature.
Material of Turbine Assembly: 304 stainless steel for the turbine
assembly, aluminum and/or stainless steel for the housing. High speed
bearings.
Mounting Bolts: 4 mounting bores on bottom of unit. Size 10/32 threaded bore.
Seals: Unit is hermetically sealed. Entire unit sealed. One size o-ring.
Availability: In inventory and ready to ship.
Measurements: 3 inches long by 3 inch hexagonal. (76 mm x 76 mm x 76 mm)
Weight: 3.5 lbs. (1.6 kg)
Shipping: We can ship this via air freight or priority air.
Type: Not CE Certified. Experimental.
Generator Options: Since this is a magnetic coupling, there is a
received magnetic rotor which has a 10 mm shaft bore, that allows you
to attach the mag rotor directly to your generator with a 10 mm shaft.
As an option, you can source a copper coil to put on the back block
(outside) which uses the spinning interior mag rotor to supply the
magnetic flux. If you need us to source a DC generator for you, we can
supply that and mount it to a rail assembly with the ITmini (see price
sheet for prices).

ITmini ORC System - Fully Completed ORC Unit: Measures a compact 2 x
2 x 2 ft. Includes 200,000 btu/hr evaporator and condenser flat plate
heat exchangers, feedpump, ITmini turbine and DC generator. All piping
included in a steel frame. Manually controlled. Available 6 weeks.
Price: See our Price list for current pricing: 02_Price_List.pdf

ITxr (single module) Turbine Only - Magnetic Coupling - 2012 Version:

Turbine Mag Coupling: Please see our current pricing at: 02_Price_List.pdf
Power: Can drive a generator up to 10,000 watts DC power out. May
have higher output with increased rpm.
Inlet Port: 1 inch SAE or 2 inch SAE
Inlet Port 1 inch version power: Can drive up to 10-20 kW Generator
Inlet Port 2 inch version power: Can drive up to 30-60 kW Generator
Outlet Port: 4 inch NPT
Working Fluid: R134a, R245fa, compressed air. We have not tried other
pressurized gases or fluids.
Pressure: 50-300 psi working pressure (up to 20 bar, 2 Mpa, 2,000 Kpa
tested). We have not tried higher pressures in operation.
RPM's: 5,000-20,000
Material of Turbine Assembly: 304 stainless steel turbine assembly.

High speed ceramic bearings. The housing is made from high quality
aluminum with a stainless steel core which surrounds the turbine
blades.
Mounting Bolts: 6 mounting bores on bottom of unit. Size 3/8 threaded bore.
Seals: Unit is hermetically sealed. Entire unit sealed. Two sizes of o-rings.
Availability: 4-6 weeks estimated.
Measurements: See price sheet.
Weight: See price sheet.
Shipping: Optional via air freight, surface or priority international air.
Type: Not CE Certified. Experimental.
Generator Options: Since this is a magnetic coupling, there is a
received mag rotor which has a 17 mm shaft bore, that allows you to
attach the mag rotor directly to your generator. As an option, you
can source a copper coil to put on the back block (outside) which uses
the spinning interior mag rotor to supply the magnetic flux.
Shipping: (1) crate holds product of 67 lbs net, 106 lbs gross.
dimensions are 29 1/2" L x 14 3/4" W x 13" H finished crate.

Shipping - Turbine Only: (1) crate 3"x13"x13" and it weighs 47 lbs.

IT10xr ORC System. Framed system includes two flat plate heat
exchangers (ASME or CE approved), expansion tank, ITxr
turbine-generator (DC power output), feedpump. System is fully piped
and pressure tested. Ships without refrigerant. Manually
controlled.
Dimensions and weight: Please see price list.
Crating charge: Please see price list. Shipping not included.
Approximate mfg. time is 6 weeks.
Pricing: Please see our current pricing at: 02_Price_List.pdf
Shipping: Weight: 680 lbs of product, 930 lbs gross (422 kg).
Dimensions are 60 1/2" (1550 mm) L x 30 1/2" (788 mm) W 68 1/2" (1753
mm) H finished crate.
Heat treated and certified crate is 7/16 OSB.

ITxa (single module) Turbine Only - Magnetic Coupling - New for 2012:

Turbine Mag Coupling: Please see our current pricing at: 02_Price_List.pdf
Power: Can drive a generator up to 300 kW+. May have higher output
with increased rpm.
Inlet Port: 8 inch flanged input.
Outlet Port: 16 inch flanged output.
Working Fluid: R134a, R245fa, compressed air. We have not tried other
pressurized gases or fluids.
Pressure: 50-300 psi working pressure (up to 20 bar, 2 Mpa, 2,000 Kpa
tested). We have not tried higher pressures in operation.
RPM's: 5,000-20,000
Material: 304 stainless steel. High speed ceramic bearings.
Mounting Bolts: 6 mounting bores on bottom of unit. Size 1/2 threaded bore.
Seals: Unit is hermetically sealed. Entire unit sealed.
Availability: 6 months estimated.
Measurements: See price sheet.
Weight: See price sheet.
Shipping: Optional via air freight, or surface.
Type: Not CE Certified. Experimental.
Generator Options: Since this is a magnetic coupling, there is a
received mag rotor which has a 2 inch shaft bore, that allows you to
attach the mag rotor directly to your gearbox or high speed generator.
As an option, you can source a copper coil to put on the back block
(outside) which uses the spinning interior mag rotor to supply the
magnetic flux.

Supercritical CO2 - Experimental Platforms:

Description of Supercritical CO2 System From Infinity Turbine:
Infinity Turbine LLC is now making available a partial S CO2 (R744)
system. This is a experimental platform and is not CE approved. Using
a standard tank of liquid CO2, you can test (one way) the heating of
the liquid to supercritical CO2, through a high pressure rated (CE
rated) heat exchanger (max 140 bar or 2,000 psi), and spin the turbine
generator. The outlet is vented to the atmosphere. We supply a
standard gear feedpump and DC controller which is a place holder for a
CO2 rated pump which will be available in the near future. The frame
mounted assembly does not include a liquid CO2 holding tank, which
will be available in the near future. The system is sold as a one-way
system and experimental. When the pump and tank become available, you
can add those to the system for a fully functioning system.

ITmini Super CO2:
-Evaporator and Condenser Heat Exchangers. 2,000 psi (140 bar) flat
plate heat exchanger (CE rated). Maximum heat or cool flow 480,000
btu/hr. Rated to 180 C.
-ITmini Turbine. Stainless steel turbine with magnetic coupling rated to 140 C.
-DC Direct Drive Generator. Standard direct drive Amp Flow Generator,
with brushes. Output from 500 watts to 3,000 watts DC. Includes
follower magnetic coupling which can be put on any rotary shaft
device. Alternatively, you can put a copper coil directly on back of
turbine to produce power (coil is sourced separately).
-System Frame. Steel frame to contain all components.
-Piping. High pressure piping from evaporator to turbine. Condenser
heat exchanger is sealed off with removable plugs.
-Feedpump. Standard R245fa gearpump with DC motor controller. This is
a placeholder only, and will be replaced with a liquid CO2 feedpump
head when available.
-Attach Points. For liquid CO2 tank (available in future).
-Paint. Infinity Turbine yellow paint of frame.
-Performance. This is an experimental test platform. Given proper
CO2 flow and pressure conditions, expect a power output able to direct
drive a generator from 1-10 kW. The small DC generator included is
design for 1 kW but can go up to 3 kW.
-Startup Operation Consulting. Offered as an option by our support technician.
-Ratings. Experimental.
-Availability. 2-4 weeks from time of deposit. System is crated for
shipment via surface or air freight.
-Price. Please email Infinity Turbine for current pricing and availability.
-Terms. Our Super CO2 systems are prepaid. Crate is additional and
shipping is optional.
-Demo. Due to the high demand of visits and demonstrations, we are
requesting only serious inquiries. Demo fee is $3,000 for two 6-hour
sessions (one day live demo and one day consulting with our support
technician).

IT10Super CO2:
-Evaporator and Condenser Heat Exchangers. 2,000 psi (140 bar) flat
plate heat exchanger (CE rated). Maximum heat or cool flow 480,000
btu/hr. Rated to 180 C.
-ITxr Turbine. Stainless steel turbine with magnetic coupling rated to 140 C.
-DC Direct Drive Generator. Standard direct drive PMA Generator, with
brushes. Output from 2,000 watts to 20,000 watts DC (intermittent)
depending on RPM. Includes follower magnetic coupling which can be put
on any rotary shaft device. Alternatively, you can put a copper coil
directly on back of turbine to produce power (coil is sourced
separately).
-System Frame. Steel frame to contain all components.
-Piping. High pressure piping from evaporator to turbine. Condenser
heat exchanger is sealed off with removable plugs.
-Feedpump. Standard R245fa gearpump with DC motor controller. This is

a placeholder only, and will be replaced with a liquid CO2 feedpump
head when available.
-Attach Points. For liquid CO2 tank (available in future).
-Paint. Infinity Turbine yellow paint of frame.
-Performance. This is an experimental test platform. Given proper
CO2 flow and pressure conditions, expect a power output able to direct
drive a generator from 10 to 60 kW. The PMA included with magnetic
coupling is designed for 1-20 kW DC.
-Startup Operation Consulting. Offered as an option by our support technician.
-Ratings. Experimental.
-Availability. 2-4 weeks from time of deposit. System is crated for
shipment via surface or air freight.
-Price. Please email Infinity Turbine for current pricing and availability.
-Terms. Our Super CO2 systems are prepaid. Crate is additional and
shipping is optional.
-Demo. Due to the high demand of visits and demonstrations, we are
requesting only serious inquiries. Demo fee is $3,000 for two 6-hour
sessions (one day live demo and one day consulting with our support
technician).

New Turbine Blueprint Licensing Option (all prices in Euro):

Infinity Turbine is now offering a build-your-own turbine blueprint
license option. Under this program, you pay a one-time fee for the
blue-copy (blueprint) of the turbine. You are welcome to produce as
many units as you wish, there is no royalty fee. Of course we'll
update the turbine every year, and if you want access to that update,
you have the option of purchasing updates.

The ITxa is a larger diameter turbine, for large applications. The
unit is designed to be integrated with a direct drive high speed AC
generator. The ITxa is for 100-400+ kW/hr outputs. The input port can
be configured to 4-8 inches.

Turbine Design Blue-Copy License Fee Schedule:

ITmini Turbine - Magnetic Coupling:
One-time licensing fee, Monthly Consulting (email/Skype - includes any
updates to design), Yearly Design Update, Webpage.
Available: Now.
Please see our current pricing at: 02_Price_List.pdf

ITxr Turbine - Magnetic Coupling:
One-time licensing fee, Monthly Consulting (email/Skype - includes any
updates to design), Yearly Design Update, Webpage.
Available: Now.
Please see our current pricing at: 02_Price_List.pdf

ITxa (Large Format Turbine) Magnetic Coupling:
One-time licensing fee, Monthly Consulting (email/Skype - includes any
updates to design), Yearly Design Update, Webpage.
Available: Now.
Please see our current pricing at: 02_Price_List.pdf

B. IT50 Series Frame Mounted Waste Heat to Energy Platform: 50 kW Net Output

IT50xr ORC System (flat plate heat exchangers / multiple ITxr / DC to
AC inverter Stand Alone or Grid Connect):

System Availability: 12+ weeks.
Complete IT50xr ORC System: Please see our current pricing at:
02_Price_List.pdf

Generator to Inverter Output: 60 kw gross output, 50 kw system net output power.
Description: ORC system for engine waste heat, biomass, or hot springs
geothermal. ITxr turbine generators. Designed for ORC refrigerant
working fluid. Design working pressure 150-200 psi.
Heat Exchanger Ports: 2 inch Female NPT inlet and outlet.
Initial Fill and Extra Refrigerant: 600 lbs. This is not included in
any system, and must be provided by the buyer.
Quantity Discount: For orders more than 10 units at one time, please inquire.
Plans and Consulting for complete ORC System: (one month unlimited
consulting up to 140 hours per month). Turbine-generator blueprints
are separate and listed below.
IT50xr Turbine-DC Generator Only: Please see ITxr 2 inch inlet above.
Minimum 1 Month Consulting includes plans, parts list, manual.
Additional Consulting: or additional hours available per hour.
Additional CAD/Cam drawing and drafting.
Please see our current pricing at: 02_Price_List.pdf

C. CONSULTING:

Infinity Turbine LLC offers a Build Your Own Brand System consulting.
This gives you the system drawings, suppliers, components list and
heat exchanger drawings. It does not include the turbine blueprints
which are offered above. These plans/consulting allow you to build
your own ORC system and put your logo and brand on the systems. You
can buy the turbines from us, or build your own from the blueprints
offered above.

Small System IT01-IT10 (300 watts - 10 kW) ORC Plans/Consulting

Additional Plans/Consulting: $5,000 per month, or additional hours at
$350 per hour. Minimum deposit $2,500. CAD/Cam drawing and drafting:
$60 per hour
Your Brand Name Machined on Turbine, along with Infinity Turbine: $500/each

IT50xr

Plans and Consulting for complete ORC System: $30,000 (one month
unlimited consulting up to 140 hours per month). Turbine-generator
blueprints are separate and separately. Must order 2 month minimum.

IT250

Plans and Consulting for complete ORC System: $30,000 (one month
unlimited consulting up to 140 hours per month). Must order 3 month
minimum. Turbine-generator blueprints are separate and listed
separately.

GENERAL ORC INFORMATION

Our Organic Rankine Cycle (ORC) Infinity Turbines can use any thermal
fluid to power the system evaporator (which in turn evaporates the
high molecular mass fluid - an environmentally friendly refrigerant).
As for your waste heat, we recommend you run that through a heat

exchanger that has thermal oil as the fluid, which we can then run
into our system.

How it works: The organic Rankine cycle has three steps -

(a) Your heat is provided in the form of thermal liquid (water, glycol
or oil). If you already have heat exchanger equipment, then you can
just use water, glycol, or a better alternative is thermal oil. If
you don't have a heat exchanger to capture your waste heat, then we
recommend a hot air to thermal oil exchanger (they are available
everywhere). The source of the heat can be geothermal, engine waste
heat, gas turbine heat, solar collector, industrial waste heat, steam,
etc. Your heat source in the form of a liquid then goes through the
evaporator heat exchanger. This is where the working fluid for the
ORC turbine gets vaporized and pressurized. The heat source should be
at least 80 deg C. Once it passes through the evaporator, it comes
out at about 10-15 deg C cooler. This can then be used for additional
process heat (CHP hot water or chiller).

(b) The working fluid for the ORC closed system is pressurized by the
evaporator, then is expanded by our turbogenerator. This produces the
shaft horsepower to turn the generator and produce electricity. Of
course, you can have the turbine power a generator, pump, or whatever
you require.

(c) The expanded working fluid then goes through a condenser to
return the vapor to a liquid state. The condenser requires some
method of cooling fluid, typically water which is provided from a
cooling tower, or ground based geothermal (the ground has a constant
temperature of 15 deg C or less temperature). The liquid is then
pumped back into the evaporator unit to complete the cycle. Only
environmentally friendly working fluid is used in the system.

So, the basic system has a evaporator, turbogenerator unit and
condenser. The temperature difference between the evaporator and
condenser heat and cooling flows must be at least 125 deg F, or about
65 deg C (difference).

Our heat rate is about 40,000 BTU / kilowatt electricity which is
about 8-11 percent efficient. This system is geared towards waste heat
- so it's free power.

It's possible to use steam or steam condensed (condensate) hot water
to put into the evaporator (boiler) to run the system if that is
available on site.

ORDER NOTES AND TERMS

Prices are in US Dollars unless otherwise indicated and are subject to
change. When you are ready to order, please request a formal invoice
and wire instructions.

Order Terms For Large Orders Above $50,000 USD: 40 percent down, 40
percent at a progress payment time period, balance at time before
shipment to customer.

Order Time: From time of deposit on equipment the mfg. time is around
4-6 months depending on orders in process. For custom builds, this
time will vary.

To run completed unit, you will need to provide hot fluid (water, oil,
etc.) to run through the evaporator heat exchanger. You will also
need condenser cold fluid, which may be provided by an air cooling
tower, ground source geothermal, or cold water from another source.

NON-REFUNDABLE DEPOSIT: Once an order is placed, 30 percent is
non-refundable if customer cancels. Customer will be returned balance
of funds when the next position is ordered and sale is completed.

BIOMASS ENERGY:

These ORC units are perfect for biomass energy.

ENGINE EXHAUST HIGH EFFICIENCY HEAT EXCHANGERS

Engine Waste Heat Chart:

http://www.infinityturbine.com/ORC/DG_KW_Chart.html

If you have a engine generator set and want to use the waste heat in
our ORC equipment, you can use the coolant liquid directly, however
you must convert the exhaust heat into a thermal liquid. To do this
you will need a heat recovery unit. There are very efficient (up to
95 percent) units from the following:

Sven Persson

<[e-mail]>

Website:

http://www.airec.se/

For example: QSK60-G4 Cummins QSK60 Series Diesel Generator Set
1600KW/1875KVA (1875KVA-2250KVA)
Heat Rejection to Coolant: 850 kWm x 3412 kWm/btu / (30,000 btu/kWe)
= 97 kWe available ORC power production
Heat Rejection to Exhaust: 1,180 kWm x 3412 kWm/btu / (30,000 btu/kWe)
x 95 percent efficiency = 127 kWe available ORC power production
Total Waste Heat to Power ORC Production: 224 kWe
Heat Exchanger from Airec: AirCompact 70 - 160/C
Price Each For Heat Exchanger: Euro 4,500 Ex-works (shipping not
included) Sweden.

INDUSTRIAL HEAT EXCHANGERS:

http://www.cainind.com/

Diesel and Gas Cogeneration, Boiler Exhaust. For engines,
retrofitting any engine or turbine, large or small, regarding
combustion exhaust economizers, exhaust gas heat recovery silencers,
and waste heat packaged steam generators. For boilers, rectangular or
cylindrical designed exhaust economizers, recovering exhaust heat
from: atmospheric boilers, Scotch marine boilers, water tube boilers,
any boiler size, any fuel type, any pressure.

Contact Cain Industries

P.O. Box 189
W194 N11826 McCormick Drive
Germantown, Wisconsin 53022
USA
Phone: [phone]
Toll Free: 1 800 558-8690

Fax: [phone]
Sales:

[e-mail]

Engineering:

[e-mail]

Purchasing:

[e-mail]

REFRIGERANT - WORKING FLUID: Honeywell R245fa - Please contact
Honeywell directly

http://www.honeywell-orc.com/

$12.00/lb is the basic pricing for delivered material in North America
(except Alaska, Hawaii).

For delivery in Europe we would need to add freight to this number.

Packaging is as follows;

45.4kg/100lb Cyl
453.6kg/1000lb HT
907.2kg/2000lb Ton

PUBLICATIONS:

We offer many publications available for sale. You may order online
and via credit card. All publications are from US GOV research and
development, and have been purchased from the US Government (they
provide paper documents which we scan into .pdf format). For a list of
all documents, please visit:

http://www.infinityturbine.com/publications/All_Publications/All_Publications.ht
ml

2012 USA FEDERAL TAX CREDITS:
30 percent of the cost of the renewable energy facility (please
consult with your CPA or tax expert regarding any potential credits
and your access to those credits)

Source:THE AMERICAN RECOVERY AND REINVESTMENT ACT OF 2009 – FEBRUARY 12, 2009

Treasury Department Energy Grants in Lieu of Tax Credits. Under
current law, taxpayers are allowed to claim a production tax credit
for electricity produced by certain renewable energy facilities and an
investment tax credit for certain renewable energy property. These
tax credits help attract private capital to invest in renewable energy
projects. Current economic conditions have severely undermined the
effectiveness of these tax credits. As a result, the bill would allow
taxpayers to receive a grant from the Treasury Department in lieu of
tax credits. This grant will operate like the current-law investment
tax credit. The Treasury Department will issue a grant in an amount
equal to thirty percent (30%) of the cost of the renewable energy
facility within sixty days of the facility being placed in service or,
if later, within sixty days of receiving an application for such
grant.

30 Percent for Solar Thermal:

http://www.energystar.gov/index.cfm?c=tax_credits.tx_index

USA Tax Credits By State:

http://www.dsireusa.org/incentives/

VISITS and DEMO:

http://www.infinityturbine.com/ORC/Visits_and_Demo.html

NEW FOR 2012:

Spring 2012: Nano Fluid Additive: We have not done any extensive
experimenting with this, however based on reports from NIST (U.S. Gov)
it appears as though this additive to R134a can increase heat transfer
between 50-250 percent. How this effects the flow of hot liquid to
the evaporator, or the flow to the condenser, has yet to be
determined. This only works with shell and tube type heat exchangers.

Now - 2012: We are now offering a 400 kw high speed (20,000 rpm) AC
generator. The generator does not need a gearbox. It has magnetic
bearings and has a estimated lifetime of 14 years.

Now - 2012: Infinity Turbine Applications Design and Engineering
Program. We are now offering a simple program on Filemaker, which
allows you to input data to get flow rates, btu heat flows, and a host
of other features. This program is under development. The Filemaker
solution requires that you purchase and install Filemaker on your
computer (Windows or Mac). Price: $10,000 USD. Support is not
included, but will be available from our support staff at $5,000 per
year. Updates are included for the first year.

Now - 2012: Infinity Turbine is now offering a large ITxa turbine
with magnetic coupling.

SHIPPING:

We can ship USPS, or air freight (FedEx, UPS, DHL, or other carrier).
For most air freight, we will need your tax ID number, VAT number or
FedEx account number so that duties are charged to the buyer for
import duties.

Export HS Codes:

HS Code: 840619 Steam and other vapor turbines ex marine propulsion

Reference Document:

http://www.usitc.gov/publications/docs/tata/hts/bychapter/1002c84.pdf

CE Certification: Please inquire at time of order.

Our specialty is distributed energy and developing power systems for
business that have unique power opportunities by utilizing waste heat.

Please let me know if you have any additional questions.

Best Regards,

Greg Giese
President
Global Energy and Infinity Turbine LLC
Headquarters: Madison, Wisconsin, and Denver, Colorado USA
Satellite Locations in Vancouver, BC, Canada.
TEL [phone]

http://www.infinityturbine.com

http://www.CO2Turbine.com
