WIRING INFORMATION 2004 Suzuki Verona

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED.BLACK and RED/WHITE

Ignition Harness

12V IGNITION WIRE

PINK

Ignition Harness

12V ACCESSORY WIRE

PINK/BLUE

Ignition Harness

SECOND ACCESSORY WIRE

YELLOW/WHITE

Ignition Harness

STARTER WIRE

PURPLE/WHITE

Ignition Harness

POWER DOOR LOCK (-)

LT.BLUE/WHITE

Module Left Of Steering Column

POWER DOOR UNLOCK (-)

LT.BLUE

Module Left Of Steering Column

PARKING LIGHTS (+)

PURPLE (LEFT)
BROWN/WHITE (RIGHT)

Harness In Driver’s Kick Panel

PARKING LIGHTS (-)

WHITE

At Headlight Switch

DOOR TRIGGER (-)

WHITE

Module Left Of Steering Column

TRUNK TRIGGER (-)

PINK/BLACK

Module Left Of Steering Column

HOOD TRIGGER (-)

PINK/BLACK

Module Left Of Steering Column

TRUNK RELEASE (+)

BROWN/BLACK or BROWN

Module Left Of Steering Column

FACTORY ALARM ARM

Arms with factory remote only

FACTORY ALARM DISARM (-)

LT.BLUE

Module Left Of Steering Column

TACHOMETER WIRE

WHITE

At ECM Next To Battery

BRAKE WIRE (+)

LT.BLUE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/WHITE

Harness At Steering Column

LEFT FRONT WINDOW UP

ORANGE/WHITE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLUE/WHITE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BROWN

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

LT.BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GREEN

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

PURPLE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

LT.GREEN

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

BLACK/BLUE

Harness In Driver’s Kick From Driver Door

This vehicle is equipped with an Immobilizer system that must be bypassed when installing a remote start system.
