ALFA ROMEO SPIDER VELOCE 1985

background image

WIRING DIAGRAMS

Fig. 1: Engine Compartment & Fuse Block

1985 Alfa Romeo Spider Veloce

For cdr101@wp.pl x x x x

Copyright © 1998 Mitchell Repair Information Company, LLC

Sunday, April 02, 2006 11:43AM

background image

WIRING DIAGRAMS

Fig. 2: Rear Compartment (p. 2)

1985 Alfa Romeo Spider Veloce

For cdr101@wp.pl x x x x

Copyright © 1998 Mitchell Repair Information Company, LLC

Sunday, April 02, 2006 11:43AM
