VOLKSWAGEN BEETLE 1998 2002

background image

Copyright 2002-2004 Triple S Customs

V

V

O

O

L

L

K

K

S

S

W

W

A

A

G

G

E

E

N

N

B

B

E

E

E

E

T

T

L

L

E

E

1

1

9

9

9

9

8

8

-

-

2

2

0

0

0

0

2

2

V

V

E

E

H

H

I

I

C

C

L

L

E

E

W

W

I

I

R

R

I

I

N

N

G

G










background image

Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION 1998 Volkswagen Beetle

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

RED/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK

Ignition Harness

12V ACCESSORY WIRE

BLACK/RED

Ignition Harness

POWER DOOR LOCK (-)

YELLOW/LT.BLUE

At Switch Inside Driver’s Door

POWER DOOR UNLOCK (-)

WHITE/GREEN

At Switch Inside Driver’s Door

Unlock requires a double pulse. The first pulse unlocks the driver’s door and disarms the factory security. The second pulse unlocks the rest of
the doors.
PARKING LIGHTS (+)

GRAY/PURPLE

At Headlight Switch

DOOR TRIGGER (-)

BROWN/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

REAR HATCH TRIGGER (-)

BROWN/BLACK

At Anti-theft Module Under Dash On Left
Side Of Steering Column

HOOD TRIGGER (-)

BROWN/RED

At Anti-theft Module Under Dash On Left
Side Of Steering Column

FACTORY ALARM ARM

Arms With Lock

FACTORY ALARM DISARM

Disarms With Unlock

TRUNK RELEASE (negative trigger on
models with power windows and 5-wire on
models without power windows)

Models with power windows:
BROWN/PURPLE
Models without power windows: RED/BLUE

At Anti-theft Module Under Dash On Left
Side Of Steering Column

TACHOMETER WIRE

GREEN/YELLOW

At Ignition Coil

BRAKE WIRE (+)

RED/BLACK

Harness In Driver’s Kick Panel

HORN TRIGGER (-)

BLACK/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

LEFT FRONT WINDOW UP

Not recommended

LEFT FRONT WINDOW DOWN

Not recommended

RIGHT FRONT WINDOW UP

Not recommended

RIGHT FRONT WINDOW DOWN

Not recommended

This vehicle may be equipped with a factory Immobilizer system. This must be bypassed when installing a remote start system.


WIRING INFORMATION 1999 Volkswagen Beetle

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

RED/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK

Ignition Harness

12V ACCESSORY WIRE

BLACK/RED

Ignition Harness

POWER DOOR LOCK (-)

YELLOW/LT.BLUE

At Switch Inside Driver’s Door

POWER DOOR UNLOCK (-)

WHITE/GREEN

At Switch Inside Driver’s Door

Unlock requires a double pulse. The first pulse unlocks the driver’s door and disarms the factory security. The second pulse unlocks the rest of
the doors.
PARKING LIGHTS (+)

GRAY/PURPLE

At Headlight Switch

DOOR TRIGGER (-)

BROWN/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

REAR HATCH TRIGGER (-)

BROWN/BLACK

At Anti-theft Module Under Dash On Left
Side Of Steering Column

HOOD TRIGGER (-)

BROWN/RED

At Anti-theft Module Under Dash On Left
Side Of Steering Column

FACTORY ALARM ARM

Arms With Lock

FACTORY ALARM DISARM

Disarms With Unlock

TRUNK RELEASE (negative trigger on
models with power windows and 5-wire on
models without power windows)

Models with power windows:
BROWN/PURPLE
Models without power windows: RED/BLUE

At Anti-theft Module Under Dash On Left
Side Of Steering Column

TACHOMETER WIRE

GREEN/YELLOW

At Ignition Coil

BRAKE WIRE (+)

RED/BLACK

Harness In Driver’s Kick Panel

HORN TRIGGER (-)

BLACK/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

LEFT FRONT WINDOW UP

Not recommended

LEFT FRONT WINDOW DOWN

Not recommended

RIGHT FRONT WINDOW UP

Not recommended

RIGHT FRONT WINDOW DOWN

Not recommended

This vehicle may be equipped with a factory Immobilizer system. This must be bypassed when installing a remote start system.


background image

Copyright 2002-2004 Triple S Customs

3

WIRING INFORMATION 2000 Volkswagen Beetle

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

RED/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK

Ignition Harness

12V ACCESSORY WIRE

BLACK/RED

Ignition Harness

POWER DOOR LOCK (-)

YELLOW/LT.BLUE

At Switch Inside Driver’s Door

POWER DOOR UNLOCK (-)

WHITE/GREEN

At Switch Inside Driver’s Door

Unlock requires a double pulse. The first pulse unlocks the driver’s door and disarms the factory security. The second pulse unlocks the rest of
the doors.
PARKING LIGHTS (+)

GRAY/PURPLE

At Headlight Switch

DOOR TRIGGER (-)

BROWN/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

REAR HATCH TRIGGER (-)

BROWN/BLACK

At Anti-theft Module Under Dash On Left
Side Of Steering Column

HOOD TRIGGER (-)

BROWN/RED

At Anti-theft Module Under Dash On Left
Side Of Steering Column

FACTORY ALARM ARM

Arms With Lock

FACTORY ALARM DISARM

Disarms With Unlock

TRUNK RELEASE (negative trigger on
models with power windows and 5-wire on
models without power windows)

Models with power windows:
BROWN/PURPLE
Models without power windows: RED/BLUE

At Anti-theft Module Under Dash On Left
Side Of Steering Column

TACHOMETER WIRE

GREEN/YELLOW

At Ignition Coil

BRAKE WIRE (+)

RED/BLACK

Harness In Driver’s Kick Panel

HORN TRIGGER (-)

BLACK/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

LEFT FRONT WINDOW UP

Not recommended

LEFT FRONT WINDOW DOWN

Not recommended

RIGHT FRONT WINDOW UP

Not recommended

RIGHT FRONT WINDOW DOWN

Not recommended

This vehicle may be equipped with a factory Immobilizer system. This must be bypassed when installing a remote start system.


WIRING INFORMATION 2001 Volkswagen Beetle

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

RED/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK

Ignition Harness

12V ACCESSORY WIRE

BLACK/RED

Ignition Harness

POWER DOOR LOCK (-)

YELLOW/LT.BLUE

At Switch Inside Driver’s Door

POWER DOOR UNLOCK (-)

WHITE/GREEN

At Switch Inside Driver’s Door

Unlock requires a double pulse. The first pulse unlocks the driver’s door and disarms the factory security. The second pulse unlocks the rest of
the doors.
PARKING LIGHTS (+)

GRAY/PURPLE

At Headlight Switch

DOOR TRIGGER (-)

BROWN/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

REAR HATCH TRIGGER (-)

BROWN/BLACK

At Anti-theft Module Under Dash On Left
Side Of Steering Column

HOOD TRIGGER (-)

BROWN/RED

At Anti-theft Module Under Dash On Left
Side Of Steering Column

FACTORY ALARM ARM

Arms With Lock

FACTORY ALARM DISARM

Disarms With Unlock

TRUNK RELEASE (negative trigger on
models with power windows and 5-wire on
models without power windows)

Models with power windows:
BROWN/PURPLE
Models without power windows: RED/BLUE

At Anti-theft Module Under Dash On Left
Side Of Steering Column

TACHOMETER WIRE

GREEN/YELLOW

At Ignition Coil

BRAKE WIRE (+)

RED/BLACK

Harness In Driver’s Kick Panel

HORN TRIGGER (-)

BLACK/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

LEFT FRONT WINDOW UP

Not recommended

LEFT FRONT WINDOW DOWN

Not recommended

RIGHT FRONT WINDOW UP

Not recommended

RIGHT FRONT WINDOW DOWN

Not recommended

This vehicle may be equipped with a factory Immobilizer system. This must be bypassed when installing a remote start system.

background image

Copyright 2002-2004 Triple S Customs

4

WIRING INFORMATION 2002 Volkswagen Beetle

WIRE

COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

RED/BLACK

Ignition Harness

12V IGNITION WIRE

BLACK

Ignition Harness

12V ACCESSORY WIRE

BLACK/RED

Ignition Harness

POWER DOOR LOCK (-)

YELLOW/LT.BLUE

At Switch Inside Driver’s Door

POWER DOOR UNLOCK (-)

WHITE/GREEN

At Switch Inside Driver’s Door

Unlock requires a double pulse. The first pulse unlocks the driver’s door and disarms the factory security. The second pulse unlocks the rest of
the doors.
PARKING LIGHTS (+)

GRAY/PURPLE

At Headlight Switch

DOOR TRIGGER (-)

BROWN/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

REAR HATCH TRIGGER (-)

BROWN/BLACK

At Anti-theft Module Under Dash On Left
Side Of Steering Column

HOOD TRIGGER (-)

BROWN/RED

At Anti-theft Module Under Dash On Left
Side Of Steering Column

FACTORY ALARM ARM

Arms With Lock

FACTORY ALARM DISARM

Disarms With Unlock

TRUNK RELEASE (negative trigger on
models with power windows and 5-wire on
models without power windows)

Models with power windows:
BROWN/PURPLE
Models without power windows: RED/BLUE

At Anti-theft Module Under Dash On Left
Side Of Steering Column

TACHOMETER WIRE

GREEN/YELLOW

At Ignition Coil

BRAKE WIRE (+)

RED/BLACK

Harness In Driver’s Kick Panel

HORN TRIGGER (-)

BLACK/YELLOW

At Anti-theft Module Under Dash On Left
Side Of Steering Column

LEFT FRONT WINDOW UP

Not recommended

LEFT FRONT WINDOW DOWN

Not recommended

RIGHT FRONT WINDOW UP

Not recommended

RIGHT FRONT WINDOW DOWN

Not recommended

This vehicle may be equipped with a factory Immobilizer system. This must be bypassed when installing a remote start system.
