nose cone 13 req'd

align intakes to these marks

wing 2 req'd

Boundry layer spliter

2 Req'd

Rear canopy deck 1 Req'd

Canopy deck 1 Req'd

Fuse top 1 Req'd

F

u

se

lage s

ide 2 R

eq'

d

Canopy 13 Req'd

nose top

Canard 2 reqd

Rear fuselage Diagonal 2 Req'd

Intake side 2 REq'd

Intake top 2 Req'd

NOTE: Reinforce all joints with 1/4 balsa triangle or strips of scrap foam before sanding contours int airplane.

Fuselage Bottom 1 Req'd

Align Inner Fuse sides with marks.

Nose Former Location

1/8" x 1/4" Hardwood Fin Stiffner 2 Req'd

1/8" Ply Spar Joiner 2 Req'd

align intake top to these marks

Nose bulkhead 1 Req'd

Cut out for Fin Stiffners

1

2

3

4

5

6

1

2

3

4

5

6

Specs:

3D Foamy

Loading

Area

Radio

Weight

4-5 Chanel

WWW.3DFOAMY.COM

Thrust 14-24 oz.

14-18 oz.

X-29 Park Jet

294 in2 (incl. canards)

6.9-8.8 oz/ft2

Copyright © 2004 3DFoamy.com.

All rights reserved.

Designed and Drawn by Chris Reiter

& Levi Jordan Updated: 11/28/2004
