Exterior Lighting - Headlamp Assembly

Mondeo 2007.5 (02/2007-)

Print

Removal and Installation

Removal

NOTE: Removal steps in this procedure may contain installation details.

Installation

1. Torque: 4 Nm

2.

CAUTIONS:

Take extra care not to scratch the headlamp lens.

Take extra care not to damage the edges of the component.

1.

CAUTION: Take extra care when installing the headlamp assembly as the fixings are easily damaged.

To install, reverse removal procedure

2. Adjust headlamps.

Refer to:

Headlamp Adjustment

(417-01 Exterior Lighting, General Procedures).
